7057Push Button Thermal with Quick Connect Terminals20A Ideal for 24-hour circuit protection Incorporated into Blue Sea Systems' Waterproof Circuit Breaker panels and main Battery Main Distribution Panels Push to reset operation "Trip Free" design cannot be held "ON" during fault current condition Ignition protected - Safe for installation aboard gasonline powered boats With male quick connect terminals WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 20a Box Dimensions: 1"H x 3"W x 5"L WT: 0.03 lbs UPC: 632085070571

Read more less

Single Pole Small Case 2" Flat Rocker Circuit BreakerPN:   7404Amperage:   20 AmpFeatures: Color actuator indicates "OFF" position "Trip Free" design cannot be held "ON" during fault current condition Specifications    Circuit Breaker Type Magnetic Hydraulic - Trip Free Maximum Voltage 250 Volts AC / 80 Volts DC Rated Switch Cycles 10,000@rated amperage and voltage WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 20a Box Dimensions: 1"H x 3"W x 5"L WT: 0.2 lbs UPC: 632085074043

Read more less

187 - Series Thermal Circuit Breakers - Panel Mount60 Amp Circuit BreakerPN:  7040Features: Combines switching and circuit protection into a single device All components meet SAE J1171 external ignition protection requirements Clear, single lever operation "Trip Free" design cannot be held "ON" during fault current condition Waterproof Recessed mounting holes for clean appearance Self-trimming case eliminates the need for mounting panels or trim bezels Round case permits easy installation with standard sized hole saw Large clearance around terminal studs accept heavy gauge wire lugs Robust 5/16 terminals provide high torque connections Large lever with vertical/horizontal orientation provides indication of trip status Ignition protected - safe for installation aboard gasoline powered boats Specifications   Circuit Breaker Class: Type III - Switchable / Manual Reset - Trip Free Type: Thermally Responsive Bi-Metal Blade Case Material: Thermoset Polyester Voltage Rating: 48 Volts DC Maximum Interrupt Rating: 5,000 Amperes @12 Volts DC   3,000 Amperes @24 Volts DC   1,500 Amperes @42 Volts DC Operating Temperature Range: -25C° to +82C° WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 60a Box Dimensions: 2"H x 5"W x 8"L WT: 0.5 lbs UPC: 632085070403

Read more less

7230 AC/DC Single Pole Magnetic World Circuit Breaker - 50AMPC / DC Single Pole Magnetic World Circuit BreakerThe World Circuit Breaker meets all American Boat and Yacht Council (ABYC) Standards, is UL 1077 Recognized, TUV Certified, CE marked for Europe, and CSA Certified for Canada.Color:   WhiteAmperage:   50 AmpDelay:   StandardFeatures: The industry standard circuit breaker for Blue Sea Systems electrical panels Combines switching and circuit protection into a single device Single pole Quick Trip models are designed specifically for electronics protection "Trip Free" design cannot be held "ON" during fault current condition WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 50a Box Dimensions: 2"H x 3"W x 5"L WT: 0.2 lbs UPC: 632085072308

Read more less

7458 UL-489 Circuit Breaker - 30A Flat RockerSuitable for use when UL-489 specifications are required (Navy, Army, or Coast Guard vessels, and other vessels covered under CFR 46).Specifications: Amperage: 30A AC Actuator Style: Flat Rocker Poles: 1 Maximum Voltage: 240V AC Circuit Breaker Type: Magnetic Hydraulic - Trip Free Terminal Type:  #10-32 Screw Tin-Plated Brass  Interrupt Capacity: 5000A Specifications: Amperage: 30a Box Dimensions: 2"H x 4"W x 5"L WT: 0.55 lbs UPC: 632085074586

Read more less

285-Series Thermal Circuit Breaker Surface Mount, 50A Drop-in replacement for 185-series Circuit Breakers Visible reset lever shows open condition "Trip Free" - cannot be held closed after tripWARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 50a Box Dimensions: 2"H x 5"W x 8"L WT: 0.3 lbs UPC: 632085171834 Brochure (pdf)

Read more less

7445 UL-489 Circuit Breaker - 50A Flat RockerSuitable for use when UL-489 specifications are required (Navy, Army, or Coast Guard vessels, and other vessels covered under CFR 46).Specifications: Amperage: 50A DC Actuator Style: Flat Rocker Poles: 1 Maximum Voltage: 80V DC Circuit Breaker Type: Magnetic Hydraulic - Trip Free Terminal Type:  #10-32 Screw Tin-Plated Brass  Interrupt Capacity: 10000A Specifications: Amperage: 50a Box Dimensions: 2"H x 3"W x 5"L WT: 0.25 lbs UPC: 632085074456

Read more less

A-Series White Toggle Circuit Breaker - Single Pole 2.5A Meets American Boat and Yacht Council (ABYC) standards The industry standard circuit breaker for Blue Sea Systems" electrical panels Combines swtiching and circuit protection into a single device "Trip Free" design cannot be held "ON" during fault current condition Specifications: Amperage: 2.5A AC / 2.5A DC Color: White Actuator Style: Toggle Poles: 1 Maximum Voltage: 250V AC / 65V DC Circuit Breaker Type: Magnetic Hydraulic - trip free Interrupt Capacity: 3000A @ 120V AC / 1500A @ 250V AC [TUV] / 3000A @ 250V AC [UL 1077] / 7500A @ 65V DC Minimum Operating Temperature: -40° C Maximum Operating Temperature: 85° C Mounting Screw: #6-32 Stainless Steel Mounting Screw Torque: 6 in-lb (0.68 Nm) Screw Terminal Torque: 14 in-lb (1.58 Nm) Switching Cycles: 10000 Terminal Screw: #10-32 Stainless Steel Weight: 0.17lb (0.08 kg) WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 2.5a Box Dimensions: 1"H x 3"W x 5"L WT: 0.4 lbs UPC: 632085071974

Read more less

C-Series Flat Rocker Circuit Breaker - Single Pole - 50AFeatures: Rocker actuator is flush in the "ON" position, eliminating the risk of accidential switching Color actuator indicates "OFF" position Provides overcurrent protection for inverters, bow thrusters, and windlasses Combines switching and circuit protection into a single device "Trip Free" - cannot be held closed after trip Ignition protectedsafe for installation aboard gasoline powered boats Specifications: Amperage: 50A AC / 50A DC Actuator Style: Flat Rocker Poles: 1 Maximum Voltage: 240V AC / 48V DC Circuit Breaker Type: Magnetic Hydraulic - trip free Terminal Stud Torque: 35 in-lb (3.95 Nm) Interrupt Capacity: 3000A @ 120V AC / 3500A @ 240V AC / 5000A @ 32V DC Minimum Operating Temperature: -40° C Maximum Operating Temperature: 85° C Mounting Screw: #6-32 Stainless Steel Mounting Screw Torque: 6 in-lb (0.68 Nm) Switching Cycles: 10000 Terminal Stud: 1/4-20 Tin-Plated Brass Weight: 0.38lb (0.17 kg) WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 50a Box Dimensions: 2"H x 2"W x 4"L WT: 0.4 lbs UPC: 632085075460

Read more less

Circuit Breaker ModuleThe 707 Circuit Breaker Module offers provision for three circuit breakers ideal for medium duty loads, like waste treatment systems and electric toilets. It is designed to separate these loadings from the main DC panel, thus avoiding unnecessary voltage spikes. Contained in the Contour lock double module, it is supplied standard with 1 x 50A and 2 x 25A B Series Circuit Breakers. Extra circuit breakers are available.WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

187 - Series Thermal Circuit Breakers - Surface Mount100 Amp Circuit BreakerPN:  7144Features: Combines switching and circuit protection into a single device All components meet SAE J1171 external ignition protection requirements Clear, single lever operation "Trip Free" design cannot be held "ON" during fault current condition Waterproof Recessed mounting holes for clean appearance Large clearance around terminal studs accept heavy gauge wire lugs Robust 5/16 terminals provide high torque connections Large lever with vertical/horizontal orientation provides indication of trip status Ignition protected - safe for installation aboard gasoline powered boats Specifications   Circuit Breaker Class: Type III - Switchable / Manual Reset - Trip Free Type: Thermally Responsive Bi-Metal Blade Case Material: Thermoset Polyester Voltage Rating: 48 Volts DC Maximum Interrupt Rating: 5,000 Amperes @12 Volts DC   3,000 Amperes @24 Volts DC   1,500 Amperes @42 Volts DC Operating Temperature Range: -25C° to +82C° WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 100a Box Dimensions: 2"H x 3"W x 8"L WT: 0.2 lbs UPC: 632085171445

Read more less

C-Series Toggle Single PolePN: 7353Poles: 1Color: WhiteAmperage: 20AFeatures: Provides overcurrent protection for inverters, bow thrusters, and windlasses Combines switching and circuit protection into a single device "Trip Free" - cannot be held closed after trip WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 20a Box Dimensions: 2"H x 3"W x 5"L WT: 0.3 lbs UPC: 632085073534

Read more less

Push Button Reset Only Screw Terminal Circuit Breaker - 5 AmpsFeatures: Branch circuit breakers (can also be used for 24-hour circuit protection) Quick connect terminal style circuit breakers are incorporated into Blue Sea Systems WeatherDeck Waterproof Circuit Breaker Panels, Dual Battery Bank Main Distribution Panels, and 360 Distribution Panels Compact design enables high density circuit protection configurations Push-to-reset operation "Trip Free" design cannot be held "ON" during fault current condition Ignition protected - Safe for installation aboard gasoline powered boats Optional Push Button Waterproof Boot protects circuit breaker in wet environments, replaces dress nut mounting on circuit breakers and resists discoloration and cracking Specifications: Amperage: 5A Maximum Voltage: 32V DC Mounting: Panel Mount 3/8-27 UNS Circuit Breaker Type: Thermal trip, manual push-button reset only Terminal Type: #8 Screw Interrupt Capacity: 3000A @ 14.7V / 2500A @ 28V Minimum Operating Temperature: -10° C Maximum Operating Temperature: 60° C Screw Terminal Torque: 6 in-lb (0.68 Nm) Weight: 0.09lb (0.04 kg)WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 5a Box Dimensions: 1"H x 3"W x 5"L WT: 0.1 lbs UPC: 632085021306

Read more less

A-Series Raised Rocker Circuit Breaker - Double Pole - 30AFeatures: Color actuator indicates "OFF" position "Trip Free" design cannot be held "ON" during fault current condition International ON/OFF symbols support vertical or horizontal mounting Specifications: Amperage: 30A AC / 30A DC Actuator Style: Raised Rocker Poles: 2 Maximum Voltage: 120V AC / 240V AC / 32V DC Circuit Breaker Type: Magnetic Hydraulic - trip free Interrupt Capacity: 3000A @ 240V AC / 1500A @ 240V AC[TUV] / 5000A @ 32V DC Minimum Operating Temperature: -40° C Maximum Operating Temperature: 85° C Mounting Screw: #6-32 Stainless Steel Mounting Screw Torque: 6 in-lb (0.68 Nm) Screw Terminal Torque: 14 in-lb (1.58 Nm) Switching Cycles: 10000 Terminal Screw: #10-32 Stainless Steel Weight: 0.38lb (0.17 kg) WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 30a Box Dimensions: 2"H x 4"W x 5"L WT: 0.35 lbs UPC: 632085075743

Read more less

Thermal AC/DC Circuit Breaker - 20 AmpThermal AC/DC Circuit Breakers are designed to protect an electrical circuit from damage caused by excess current. Vibration and shock resistant these push-to-reset circuit breakers are an economical alternative to magnetic breakers. Unlike sacrificial fuses they have the advantage of being resettable after tripping. Panel mounted compact design. Constructed of molded Bakelite with quick connect, terminal style, stamped brass contacts. Optional Thermal Breaker Boot (420839) provides additional protection in wet environments. 5-30A @ 125-250VAC. 32VDC.Features: Panel Depth: 3/16" Amps: 20 WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 20a Box Dimensions: 1"H x 4"W x 6"L WT: 0.1 lbs UPC: 035514420488

Read more less

Thermal AC/DC Circuit Breaker - 10 AmpThermal AC/DC Circuit Breakers are designed to protect an electrical circuit from damage caused by excess current. Vibration and shock resistant these push-to-reset circuit breakers are an economical alternative to magnetic breakers. Unlike sacrificial fuses they have the advantage of being resettable after tripping. Panel mounted compact design. Constructed of molded Bakelite with quick connect, terminal style, stamped brass contacts. Optional Thermal Breaker Boot (420839) provides additional protection in wet environments. 5-30A @ 125-250VAC. 32VDC.Features: Panel Depth: 3/16" Amps: 10 WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 10a Box Dimensions: 1"H x 4"W x 6"L WT: 0.1 lbs UPC: 035514420464

Read more less

A-Series Flat Rocker Circuit Breaker - Single Pole - 2.5A Rocker actuator is flush in the "ON" position, eliminating the risk of accidential switching Color actuator indicates "OFF" position "Trip Free" design cannot be held "ON" during fault current condition 2 different actuator styles available Prevents accidental switching of 24 hour circuits International ON/OFF symbols support vertical or horizontal mounting Specifications: Amperage: 2.5A DC / 2.5A AC Actuator Style: Flat Rocker Poles: 1 Max Voltage:250V AC / 32V DC Circuit Breaker Type: Magnetic Hydraulic - Trip Free Interrupt Capacity: 3000A @ 125V AC / 1500A @ 250V AC / 5000A @ 32V DC Minimum Operating Temperature: -40° C Maximum Operating Temperature: 85° C Mounting Screw: #6-32 Stainless Steel Mounting Screw Torque: 6 in-lb (0.68 Nm) Screw Terminal Torque 14 in-lb (1.58 Nm) Switching Cycles: 10000 Terminal Screw: #10-32 Stainless Steel Weight: 0.21lb (0.1 kg) WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 2.5a Box Dimensions: 1"H x 3"W x 5"L WT: 0.2 lbs UPC: 632085073992

Read more less

7240 A-Series Double Pole Toggle - 40AMP - WhitePoles: 2Color: WhiteAmperage: 40AMPFeatures: Meets American Boat and Yacht Council (ABYC) standards UL 1077 recognized, TUV certified, CE marked for Europe and CSA certified for Canada The industry standard circuit breaker for Blue Sea Systems electrical panels Combines switching and circuit protection into a single device Used as AC Main circuit protection "Trip Free" design cannot ben held "ON" during fault current condition WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 40a Box Dimensions: 2"H x 3"W x 5"L WT: 0.4 lbs UPC: 632085072407

Read more less

7058Push Button Thermal with Quick Connect Terminals25A Ideal for 24-hour circuit protection Incorporated into Blue Sea Systems' Waterproof Circuit Breaker panels and main Battery Main Distribution Panels Push to reset operation "Trip Free" design cannot be held "ON" during fault current condition Ignition protected - Safe for installation aboard gasonline powered boats With male quick connect terminals WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 25a Box Dimensions: 1"H x 3"W x 5"L WT: 0.3 lbs UPC: 632085070588

Read more less

A-Series Toggle Double PolePN: 7236Poles: 2Color: BlackAmperage: 20AFeatures: Meets American Boat and Yacht Council (ABYC) standards UL 1077 recognized, TUV certified, CE marked for Europe and CSA certified for Canada The industry standard circuit breaker for Blue Sea Systems electrical panels Combines switching and circuit protection into a single device Used as AC Main circuit protection "Trip Free" design cannot be held "ON" during fault current condition WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 20a Box Dimensions: 3"H x 3"W x 4"L WT: 0.4 lbs UPC: 632085072360

Read more less

Single Pole Small Case 2" Flat Rocker Circuit BreakerPN:   7406Amperage:   30 AmpFeatures: Color actuator indicates "OFF" position "Trip Free" design cannot be held "ON" during fault current condition Specifications    Circuit Breaker Type Magnetic Hydraulic - Trip Free Maximum Voltage 250 Volts AC / 80 Volts DC Rated Switch Cycles 10,000@rated amperage and voltage WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 30a Box Dimensions: 1"H x 2"W x 4"L WT: 0.1 lbs UPC: 632085074067

Read more less

7155 Short Stop Circuit Breaker - 30A Corrosion Resistant Material IP 64 Water Resistant Boot Push to Reset Only Interrupt Capacity: 2,500A @ 28VDC Red insulating boot included in retail package Specifications Amperage: 30A DC Maximum Voltage: 28V DC Interrupt Capacity: 2500A @ 28V DC Minimum Operating Temperature: -10º C Maximum Operating Temperature: 60º C Screw Terminal Torque: 24 in-lb (2.71 Nm) Terminal Stud: #10-32" WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 30a Box Dimensions: 2"H x 3"W x 7"L WT: 0.1 lbs UPC: 632085071554

Read more less

ST CLB Circuit Breaker Block - 6 Position w/Negative BusFeatures Quick connect clips allow circuit breakers to snap easily into place Tin-plated copper busses and screw terminals Clear insulating cover with square format label recesses, satisfies ABYC/USCG insulation requirements Easy to open clip on cover Breakouts allow wire access in two directions Accepts ring terminals Optional push button waterproof boots or dress nuts can be installed over cover Specifications:Circuits: 6Maximum Amperage: 100A (per block) 32A (per circuit)Maximum Voltage: 32V DCMounting: #8 Screw (M4) or #8 NutNegative Bus: YesSource: Common SourceMinimum Operating Temperature: -10° CMaximum Operating Temperature: 60° CMounting Centers: 5.63"(143 mm)Screw Terminal Type: #8-32 Screws with Captive Star Lock WasherHeight: 6.69"(169.93 mm)Weight: 0.75lb (0.34 kg)WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 100/32a Box Dimensions: 3"H x 5"W x 11"L WT: 0.9 lbs UPC: 632085050528 Brochure (pdf)

Read more less

AC / DC Single Pole Magnetic World Circuit BreakerThe World Circuit Breaker meets all American Boat and Yacht Council (ABYC) Standards, is UL 1077 Recognized, TUV Certified, CE marked for Europe, and CSA Certified for Canada.PN:   7229Color:   RedAmperage:   50 AmpDelay:   StandardFeatures: The industry standard circuit breaker for Blue Sea Systems electrical panels Combines switching and circuit protection into a single device Single pole Quick Trip models are designed specifically for electronics protection "Trip Free" design cannot be held "ON" during fault current condition Specifications    Circuit Breaker Type Magnetic Hydraulic - Trip Free Maximum Voltage 277 Volts AC / 65 Volts DC Rated Switch Cycles 10,000@rated amperage and voltage WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 50a Box Dimensions: 1"H x 3"W x 4"L WT: 0.2 lbs UPC: 632085072292

Read more less

30A Panel Mount Mini Circuit BreakerThis 30A Panel Mount Mini Circuit Breaker is a 2-in-1 circuit breaker/disconnect switch that incorporates traditional battery disconnect switching (non-engine) and circuit protection. Trolling motor circuit switching applications are what this switch is best used for.Applications: Protects electrical circuits from short-circuit events and over-current loads, preventing wire insulation overheating and subsequent destruction Automatic Circuit Protection and Manual On/Off Switching combine dual functionality in one reliable and compact solution Allows for circuit isolation and maintenance of load circuits by providing convenient switching and integral circuit protection capable of mounting adjacent to battery systems regardless of the location Features: IP66 sealed against dust and water Intrusion to ensure reliable circuit protection for the life of the electrical system installation  42 Vdc rating - easily supports 12, 24, and 36V DC applications. Ideal for trolling motor switching applications High electrical and manual switching endurance delivers 2,000 cycles at full current High interrupt current - safely protects circuits connected to large paralleled battery banks with significant available power 4-year warranty - Egis stands behind its product's ability to meet the user's needs Specifications: Continuous Current Amps: 30 Max Voltage: 42 CE Marked: Yes Interrupt Current @14 VDC (Amps): 3,000 Cycle Switching Endurance: 4,000 Ingress Protection Rating: IP66 Focal FeaturesEasy ON/OFF Rotary SwitchEasy to operate and visually recognize switch position.Stainless Steel Self- Locking Hardware Corrosion and vibration resistance for harsh environment applications.Weatherproof ConstructionSealed against dust and moisture penetration. High temp rated for all installation locations.Compact SizeFit more circuit switching/protection on a smaller panel!Proudly Made in the USAMade in the USA of high-quality components.Ignition ProtectedProtects against inadvertent shorts from positive terminals to adjacent grounded surfacesWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 30a Box Dimensions: 3"H x 4"W x 5"L WT: 0.3 lbs UPC: 850053879357 Quick Guide (pdf)

Read more less

50A Panel Mount Mini Circuit BreakerThis 50A Panel Mount Mini Circuit Breaker is a 2-in-1 circuit breaker/disconnect switch that incorporates traditional battery disconnect switching (non-engine) and circuit protection. Trolling motor circuit switching applications are what this switch is best used for.Applications: Protects electrical circuits from short-circuit events and over-current loads, preventing wire insulation overheating and subsequent destruction Automatic Circuit Protection and Manual On/Off Switching combine dual functionality in one reliable and compact solution Allows for circuit isolation and maintenance of load circuits by providing convenient switching and integral circuit protection capable of mounting adjacent to battery systems regardless of the location Features: IP66 sealed against dust and water Intrusion to ensure reliable circuit protection for the life of the electrical system installation  42 Vdc rating - easily supports 12, 24, and 36V DC applications. Ideal for trolling motor switching applications High electrical and manual switching endurance delivers 2,000 cycles at full current High interrupt current - safely protects circuits connected to large paralleled battery banks with significant available power 4-year warranty - Egis stands behind its product's ability to meet the user's needs Specifications: Continuous Current Amps: 50 Max Voltage: 42 CE Marked: Yes Interrupt Current @14 VDC (Amps): 3,000 Cycle Switching Endurance: 3,000 Ingress Protection Rating: IP66 Focal FeaturesEasy ON/OFF Rotary SwitchEasy to operate and visually recognize switch position.Stainless Steel Self- Locking Hardware Corrosion and vibration resistance for harsh environment applications.Weatherproof ConstructionSealed against dust and moisture penetration. High temp rated for all installation locations.Compact SizeFit more circuit switching/protection on a smaller panel!Proudly Made in the USAMade in the USA of high-quality components.Ignition ProtectedProtects against inadvertent shorts from positive terminals to adjacent grounded surfacesWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 50a Box Dimensions: 3"H x 3"W x 6"L WT: 0.3 lbs UPC: 850053879371 Quick Guide (pdf)

Read more less

8072 Panel Blank Single A-Series Features: Mounts A-Series Single Pole Toggle Circuit Breakers Slate grey matches standard panel color Mounts A-Series double pole toggle circuit breaker 1/8" aluminum 5052 alloy Accepts Blue Sea Systems' label "Power On" and "Reverse Polarity" LEDs WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

187 - Series Thermal Circuit Breakers - Panel Mount25 Amp Circuit BreakerPN:  7035Features: Combines switching and circuit protection into a single device All components meet SAE J1171 external ignition protection requirements Clear, single lever operation "Trip Free" design cannot be held "ON" during fault current condition Waterproof Recessed mounting holes for clean appearance Self-trimming case eliminates the need for mounting panels or trim bezels Round case permits easy installation with standard sized hole saw Large clearance around terminal studs accept heavy gauge wire lugs Robust 5/16 terminals provide high torque connections Large lever with vertical/horizontal orientation provides indication of trip status Ignition protected - safe for installation aboard gasoline powered boats Specifications   Circuit Breaker Class: Type III - Switchable / Manual Reset - Trip Free Type: Thermally Responsive Bi-Metal Blade Case Material: Thermoset Polyester Voltage Rating: 48 Volts DC Maximum Interrupt Rating: 5,000 Amperes @12 Volts DC   3,000 Amperes @24 Volts DC   1,500 Amperes @42 Volts DC Operating Temperature Range: -25C° to +82C° WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 25a Box Dimensions: 4"H x 5"W x 7"L WT: 0.5 lbs UPC: 632085070359

Read more less

ST CLB Circuit Breaker Block - 6 PositionFeatures Quick connect clips allow circuit breakers to snap easily into place Tin-plated copper busses and screw terminals Clear insulating cover with square format label recesses, satisfies ABYC/USCG insulation requirements Easy to open clip on cover Breakouts allow wire access in two directions Accepts ring terminals Optional push button waterproof boots or dress nuts can be installed over cover Specifications:Circuits: 6Maximum Amperage: 32A (per circuit) 40A (per jumped circuit group)Maximum Voltage: 32V DCMounting: #8 Screw (M4) or #8 NutSource: Independent SourceMinimum Operating Temperature: -10° CMaximum Operating Temperature: 60° CMounting Centers: 5.63"(143 mm)Screw Terminal Type: #8-32 Screws with Captive Star Lock WasherHeight: 6.69"(169.93 mm)Weight: 0.75lb (0.34 kg)WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 32/40a Box Dimensions: 3"H x 5"W x 11"L WT: 0.8 lbs UPC: 632085050504 Brochure (pdf)

Read more less

Single Pole Small Case 2" Flat Rocker Circuit BreakerPN:   7400Amperage:   5 AmpFeatures: Color actuator indicates "OFF" position "Trip Free" design cannot be held "ON" during fault current condition Specifications    Circuit Breaker Type Magnetic Hydraulic - Trip Free Maximum Voltage 250 Volts AC / 80 Volts DC Rated Switch Cycles 10,000@rated amperage and voltage WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 5a Box Dimensions: 1"H x 2"W x 3"L WT: 0.35 lbs UPC: 632085074005

Read more less

5026 ST Blade Fuse Block with Cover - 12 Circuit with Negative Bus Features: Clear insulating cover with label recesses accept Small Format Labels Cover Satisfies ABYC/USCG requirements for insulation Tin-plated copper buses and fuse clips give 30 Amperes rating per circuit Accepts ATO and ATC fast acting blade fuses 20 write-on circuit labels included WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Owner's Manual (pdf)

Read more less

Push Button Reset Only Screw Terminal Circuit Breaker - 3 AmpsFeatures: Branch circuit breakers (can also be used for 24-hour circuit protection) Quick connect terminal style circuit breakers are incorporated into Blue Sea Systems WeatherDeck Waterproof Circuit Breaker Panels, Dual Battery Bank Main Distribution Panels, and 360 Distribution Panels Compact design enables high density circuit protection configurations Push-to-reset operation "Trip Free" design cannot be held "ON" during fault current condition Ignition protected - Safe for installation aboard gasoline powered boats Optional Push Button Waterproof Boot protects circuit breaker in wet environments, replaces dress nut mounting on circuit breakers and resists discoloration and cracking Specifications: Amperage: 3A Maximum Voltage: 32V DC Mounting: Panel Mount 3/8-27 UNS Circuit Breaker Type: Thermal trip, manual push-button reset only Terminal Type: #8 Screw Interrupt Capacity: 3000A @ 14.7V / 2500A @ 28V Minimum Operating Temperature: -10° C Maximum Operating Temperature: 60° C Screw Terminal Torque: 6 in-lb (0.68 Nm) Weight: 0.09lb (0.04 kg)WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 3a Box Dimensions: 1"H x 3"W x 5"L WT: 0.1 lbs UPC: 632085021290

Read more less

285-Series Thermal Circuit Breaker Surface Mount, 40A Drop-in replacement for 185-series Circuit Breakers Visible reset lever shows open condition "Trip Free" - cannot be held closed after tripWARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 40a Box Dimensions: 1"H x 3"W x 4"L WT: 0.1 lbs UPC: 632085171827 Brochure (pdf)

Read more less

187 - Series Thermal Circuit Breakers - Surface Mount150 Amp Circuit BreakerPN:  7148Features: Combines switching and circuit protection into a single device All components meet SAE J1171 external ignition protection requirements Clear, single lever operation "Trip Free" design cannot be held "ON" during fault current condition Waterproof Recessed mounting holes for clean appearance Large clearance around terminal studs accept heavy gauge wire lugs Robust 5/16 terminals provide high torque connections Large lever with vertical/horizontal orientation provides indication of trip status Ignition protected - safe for installation aboard gasoline powered boats Specifications   Circuit Breaker Class: Type III - Switchable / Manual Reset - Trip Free Type: Thermally Responsive Bi-Metal Blade Case Material: Thermoset Polyester Voltage Rating: 48 Volts DC Maximum Interrupt Rating: 5,000 Amperes @12 Volts DC   3,000 Amperes @24 Volts DC   1,500 Amperes @42 Volts DC Operating Temperature Range: -25C° to +82C° WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 150a Box Dimensions: 2"H x 5"W x 8"L WT: 0.55 lbs UPC: 632085171483

Read more less

187 - Series Thermal Circuit Breakers - Panel Mount30 Amp Circuit BreakerPN:  7036Features: Combines switching and circuit protection into a single device All components meet SAE J1171 external ignition protection requirements Clear, single lever operation "Trip Free" design cannot be held "ON" during fault current condition Waterproof Recessed mounting holes for clean appearance Self-trimming case eliminates the need for mounting panels or trim bezels Round case permits easy installation with standard sized hole saw Large clearance around terminal studs accept heavy gauge wire lugs Robust 5/16 terminals provide high torque connections Large lever with vertical/horizontal orientation provides indication of trip status Ignition protected - safe for installation aboard gasoline powered boats Specifications   Circuit Breaker Class: Type III - Switchable / Manual Reset - Trip Free Type: Thermally Responsive Bi-Metal Blade Case Material: Thermoset Polyester Voltage Rating: 48 Volts DC Maximum Interrupt Rating: 5,000 Amperes @12 Volts DC   3,000 Amperes @24 Volts DC   1,500 Amperes @42 Volts DC Operating Temperature Range: -25C° to +82C° WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 30a Box Dimensions: 2"H x 5"W x 8"L WT: 0.45 lbs UPC: 632085070366

Read more less

5025 ST Blade Fuse Block with Cover - 6 Circuit with Negative Bus Features: Clear insulating cover with label recesses accept Small Format Labels Cover Satisfies ABYC/USCG requirements for insulation Tin-plated copper buses and fuse clips give 30 Amperes rating per circuit Accepts ATO and ATC fast acting blade fuses 20 write-on circuit labels included WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Owner's Manual (pdf)

Read more less

285-Series Thermal Circuit Breaker Surface Mount, 80A Drop-in replacement for 185-series Circuit Breakers Visible reset lever shows open condition "Trip Free" - cannot be held closed after tripWARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 80a Box Dimensions: 1"H x 3"W x 4"L WT: 0.1 lbs UPC: 632085171865 Brochure (pdf)

Read more less

AC / DC Single Pole Magnetic World Circuit BreakerThe World Circuit Breaker meets all American Boat and Yacht Council (ABYC) Standards, is UL 1077 Recognized, TUV Certified, CE marked for Europe, and CSA Certified for Canada.PN:   7220Color:   BlackAmperage:   30 AmpDelay:   StandardFeatures: The industry standard circuit breaker for Blue Sea Systems electrical panels Combines switching and circuit protection into a single device Single pole Quick Trip models are designed specifically for electronics protection "Trip Free" design cannot be held "ON" during fault current condition Specifications    Circuit Breaker Type Magnetic Hydraulic - Trip Free Maximum Voltage 277 Volts AC / 65 Volts DC Rated Switch Cycles 10,000@rated amperage and voltage WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 30a Box Dimensions: 1"H x 3"W x 5"L WT: 0.2 lbs UPC: 632085072209

Read more less

7202 AC/DC Single Pole Magnetic World Circuit Breaker - 5AMPC / DC Single Pole Magnetic World Circuit BreakerThe World Circuit Breaker meets all American Boat and Yacht Council (ABYC) Standards, is UL 1077 Recognized, TUV Certified, CE marked for Europe, and CSA Certified for Canada.Features: The industry standard circuit breaker for Blue Sea Systems electrical panels Combines switching and circuit protection into a single device Single pole Quick Trip models are designed specifically for electronics protection "Trip Free" design cannot be held "ON" during fault current condition WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 5a Box Dimensions: 1"H x 3"W x 5"L WT: 0.2 lbs UPC: 632085072025

Read more less

A-Series Toggle Double PolePN: 7241Poles: 2Color: BlackAmperage: 50AFeatures: Meets American Boat and Yacht Council (ABYC) standards UL 1077 recognized, TUV certified, CE marked for Europe and CSA certified for Canada The industry standard circuit breaker for Blue Sea Systems electrical panels Combines switching and circuit protection into a single device Used as AC Main circuit protection "Trip Free" design cannot be held "ON" during fault current condition WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 50a Box Dimensions: 3"H x 3"W x 4"L WT: 0.3 lbs UPC: 632085072414

Read more less

Push Button Reset Only Screw Terminal Circuit Breaker - 25 AmpsFeatures: Branch circuit breakers (can also be used for 24-hour circuit protection) Quick connect terminal style circuit breakers are incorporated into Blue Sea Systems WeatherDeck Waterproof Circuit Breaker Panels, Dual Battery Bank Main Distribution Panels, and 360 Distribution Panels Compact design enables high density circuit protection configurations Push-to-reset operation "Trip Free" design cannot be held "ON" during fault current condition Ignition protected - Safe for installation aboard gasoline powered boats Optional Push Button Waterproof Boot protects circuit breaker in wet environments, replaces dress nut mounting on circuit breakers and resists discoloration and cracking Specifications: Amperage: 25A Maximum Voltage: 32V DC Mounting: Panel Mount 3/8-27 UNS Circuit Breaker Type: Thermal trip, manual push-button reset only Terminal Type: #8 Screw Interrupt Capacity: 3000A @ 14.7V / 2500A @ 28V Minimum Operating Temperature: -10° C Maximum Operating Temperature: 60° C Screw Terminal Torque: 6 in-lb (0.68 Nm) Weight: 0.09lb (0.04 kg)WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 25a Box Dimensions: 1"H x 3"W x 5"L WT: 0.1 lbs UPC: 632085021351

Read more less

285-Series Thermal Circuit Breaker Surface Mount, 120A Drop-in replacement for 185-series Circuit Breakers Visible reset lever shows open condition "Trip Free" - cannot be held closed after tripWARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 120a Box Dimensions: 2"H x 5"W x 8"L WT: 0.35 lbs UPC: 632085171889 Brochure (pdf)

Read more less

Thermal AC/DC Circuit Breaker - 8 AmpThermal AC/DC Circuit Breakers are designed to protect an electrical circuit from damage caused by excess current. Vibration and shock resistant these push-to-reset circuit breakers are an economical alternative to magnetic breakers. Unlike sacrificial fuses they have the advantage of being resettable after tripping. Panel mounted compact design. Constructed of molded Bakelite with quick connect, terminal style, stamped brass contacts. Optional Thermal Breaker Boot (420839) provides additional protection in wet environments. 5-30A @ 125-250VAC. 32VDC.Features: Panel Depth: 3/16" Amps: 8 WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 8a Box Dimensions: 2"H x 4"W x 6"L WT: 0.1 lbs UPC: 035514420457

Read more less

7154 Short Stop Circuit Breaker - 25A Corrosion Resistant Material IP 64 Water Resistant Boot Push to Reset Only Interrupt Capacity: 2,500A @ 28VDC Red insulating boot included in retail package Specifications Amperage: 25A DC Maximum Voltage: 28V DC Interrupt Capacity: 2500A @ 28V DC Minimum Operating Temperature: -10º C Maximum Operating Temperature: 60º C Screw Terminal Torque: 24 in-lb (2.71 Nm) Terminal Stud: #10-32" WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 25a Box Dimensions: 2"H x 3"W x 7"L WT: 0.1 lbs UPC: 632085071547

Read more less

C-Series TogglePN: 7251Poles: 2Color: WhiteAmperage: 50AFeatures: 5,000 Ampere interrupt capacity to meet ABYC requirements for 120/240 Volt 50 Ampere main protection Double pole used as 120 volt AC main circuit breaker to switch hot to neutral Triple pole used as 240 volt AC main circuit breaker to switch lines (hot) and neutral Double and triple pole circuit breakers will trip all poles will trip if any one pole trips "Trip Free" design cannot be held ON during fault current condition WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 50a Box Dimensions: 4"H x 5"W x 6"L WT: 0.6 lbs UPC: 632085072513

Read more less

AC / DC Single Pole Magnetic World Circuit BreakerThe World Circuit Breaker meets all American Boat and Yacht Council (ABYC) Standards, is UL 1077 Recognized, TUV Certified, CE marked for Europe, and CSA Certified for Canada.PN:   7228Color:   BlackAmperage:   50 AmpDelay:   StandardFeatures: The industry standard circuit breaker for Blue Sea Systems electrical panels Combines switching and circuit protection into a single device Single pole Quick Trip models are designed specifically for electronics protection "Trip Free" design cannot be held "ON" during fault current condition Specifications    Circuit Breaker Type Magnetic Hydraulic - Trip Free Maximum Voltage 277 Volts AC / 65 Volts DC Rated Switch Cycles 10,000@rated amperage and voltage WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 50a Box Dimensions: 1"H x 3"W x 5"L WT: 0.15 lbs UPC: 632085072285

Read more less

AC / DC Single Pole Magnetic World Circuit BreakerThe World Circuit Breaker meets all American Boat and Yacht Council (ABYC) Standards, is UL 1077 Recognized, TUV Certified, CE marked for Europe, and CSA Certified for Canada.PN:   7224Color:   BlackAmperage:   40 AmpDelay:   StandardFeatures: The industry standard circuit breaker for Blue Sea Systems electrical panels Combines switching and circuit protection into a single device Single pole Quick Trip models are designed specifically for electronics protection "Trip Free" design cannot be held "ON" during fault current condition Specifications    Circuit Breaker Type Magnetic Hydraulic - Trip Free Maximum Voltage 277 Volts AC / 65 Volts DC Rated Switch Cycles 10,000@rated amperage and voltage WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 40a Box Dimensions: 1"H x 2"W x 4"L WT: 0.15 lbs UPC: 632085072247

Read more less

Push Button Reset Only Screw Terminal Circuit Breaker - 40 AmpsFeatures: Branch circuit breakers (can also be used for 24-hour circuit protection) Quick connect terminal style circuit breakers are incorporated into Blue Sea Systems WeatherDeck Waterproof Circuit Breaker Panels, Dual Battery Bank Main Distribution Panels, and 360 Distribution Panels Compact design enables high density circuit protection configurations Push-to-reset operation "Trip Free" design cannot be held "ON" during fault current condition Ignition protected - Safe for installation aboard gasoline powered boats Optional Push Button Waterproof Boot protects circuit breaker in wet environments, replaces dress nut mounting on circuit breakers and resists discoloration and cracking Specifications: Amperage: 40A Maximum Voltage: 32V DC Mounting: Panel Mount 3/8-27 UNS Circuit Breaker Type: Thermal trip, manual push-button reset only Terminal Type: #8 Screw Interrupt Capacity: 3000A @ 14.7V / 2500A @ 28V Minimum Operating Temperature: -10° C Maximum Operating Temperature: 60° C Screw Terminal Torque: 6 in-lb (0.68 Nm) Weight: 0.09lb (0.04 kg)WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 40a Box Dimensions: 1"H x 3"W x 5"L WT: 0.1 lbs UPC: 632085021375

Read more less
