DRS12ANXT Doppler Radar Pedestal - Less Antenna and Cable100 Watt Solid-State Doppler Radar with Target Analyzer and Fast Target Tracking, less antenna and cable RezBoost Beam SharpeningFor the first time Furuno's exclusive RezBoost™ technology is used in one of our Radar units, with impressive performance. With RezBoost™ set to MAX, the sharpness of a much larger open array antenna can be achieved.Bird Mode gives you the inside scoop on schools of fish!The DRS-NXT series features an enhanced Bird Mode that helps you identify birds gathering around schools of fish at the sea surface. Bird Mode adjusts the gain and sea settings automatically for optimal visibility.The NXT step with doppler Radar technologyThe Furuno NXT Radar is the next step in Radar evolution; a Solid-State Radar with pulse compression, Target Analyzer™ and Fast Target Tracking™ utilizing Doppler technology. Combined with FURUNO exclusive RezBoost™ technology for beam sharpening, NXT packs the performance of a larger Radar in a more compact package.Target Analyzer function utilizing Doppler technologyNXT was the first Radar in the world to use the new Furuno exclusive Target Analyzer™ function, where targets that are approaching your vessel automatically change color. Green targets are targets that stay stationary, or are moving away from you, while red targets are moving towards your vessel. Target Analyzer™ works independent of vessel speed, both your own vessels and target vessels, with minor limitations. Echoes dynamically change colors as targets approach, or get farther away from your vessel. Target Analyzer™ can increase safety, as well as improve situational awareness.Fast Target TrackingOnce a target has been selected, a speed and course vector is displayed in seconds. With accurate tracking information, estimation of other vessel's course and speed is greatly simplified. With Doppler technology, any vessel approaching yours will automatically display a target vector, as well as sound an alarm.This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Read more less

DRS12AX 12kW UHD Digital Radar with Pedestal 15M Cable & 3.5' Open Array AntennaPushing the boundaries of what is possible with conventional Radar technology, DRS12AX "X-Class" marks yet another leap forward for Furuno. Improved in almost all aspects, DRS12AX "X-Class" Radar features improved short range detection, as well as an impressive long range detection of up to 96 nautical miles.The redesigned pedestal unit is 20% lighter than previous models and features an updated motor for significantly lower noise levels. Combined with an updated smart-connector cable, installation and maintenance is simpler than ever before.Fast Target Tracking™ function adopted from our commercial Radar FAR3000, is also available on the DRS12AX "X-Class." Target course and speed vectors are displayed instantly with the press of a button. Target vectors increase situational awareness and can increase overall safety on your vessel.Features: 12kW Power Output Enhanced target detection, both short and long range Minimum detection range of just 20 m Fast Target Tracking™ Bird Mode Pedestal unit 20% lighter than previous unit, updated with new, low noise motor No PSU required, decreasing total costs Easy installation without the need to open pedestal unit Smart-connector cable  3.5ft Antenna 15M Cable 96NM Range Compatible with NavNet TZtouch, NavNet TZtouch2 and TZtouch3 (not compatible with NavNet 3D or earlier NavNet models) The DRS12AX is a 24V system; a converter will be required for use with 12V power systems This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Power - Output: 12kW Array Size (Inches): 42" Box Dimensions: 8"H x 17"W x 17"L WT: 64.6 lbs

Read more less

Furuno DRS25AX 25kW X-Band Radar Pedestal OnlyModel: DRS25AX 25kW Power Output Enhanced target detection, both short and long range Minimum detection range of just 20 m Fast Target TrackingTM Bird Mode New pedestal unit 20% lighter than previous unit, updated with new, low noise motor No PSU required, decreasing total costs Easy installation without the need to open pedestal unit New smart-connector cable The DRS25AX is a 24V system; a converter will be required for use with 12V power systems Compatible with NavNet TZtouch and NavNet TZtouch2 (not compatible with NavNet 3D or earlier NavNet models) Pushing the boundaries of what is possible with conventional Radar technology, DRS25AX X-Class" marks yet another leap forward for FURUNO. Improved in almost all aspects

Read more less

DRS25AX 25kW UHD Digital Radar Less Antenna and Cable25kW UHD Digital Radar for TZtouch and TZtouch2,  DRS25AX "X-Class", a whole new class of Radar!Pushing the boundaries of what is possible with conventional Radar technology, DRS25AX "X-Class" marks yet another leap forward for Furuno. Improved in almost all aspects, DRS25AX "X-Class" Radar features improved short range detection, as well as an impressive long range detection of up to 96 nautical miles.The redesigned pedestal unit is 20% lighter than previous models and features an updated motor for significantly lower noise levels. Combined with an updated smart-connector cable, installation and maintenance is simpler than ever before.Fast Target Tracking™ function adopted from our commercial Radar FAR3000, is also available on the DRS25AX "X-Class." Target course and speed vectors are displayed instantly with the press of a button. Target vectors increase situational awareness and can increase overall safety on your vessel.Features: 25kW Powe Enhanced target detection, both short and long range Minimum detection range of just 20 m Fast Target Tracking™ Bird Mode Pedestal unit 20% lighter than previous unit, updated with new, low noise motor No PSU required, decreasing total costs Easy installation without the need to open pedestal unit Smart-connector cable Choice of 3.5'/4'/6' Antenna Requires Signal/Power Cable Compatible with NavNet TZtouch and NavNet TZtouch2 (not compatible with NavNet 3D or earlier NavNet models) The DRS25AX is a 24V system; a converter will be required for use with 12V power systems This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Power - Output: 25kW Box Dimensions: 16"H x 18"W x 20"L WT: 41 lbs UPC: 611679368379

Read more less

Furuno DRS6AX 6kw UHD Digital Radar with 4 feet Antenna and 15M CableModel: DRS6AX/4 6kW Power Output Enhanced target detection, both short and long range Minimum detection range of just 20 m Fast Target TrackingTM Bird Mode New pedestal unit, 20% lighter than previous DRS6A unit, updated low noise motor No PSU required, decreasing total costs Easy installation without the need to open pedestal unit New smart-connector cable The DRS6AX is a 24V system; a converter will be required for use with 12V power systems Compatible with NavNet TZtouch and NavNet TZtouch2 (not compatible with NavNet 3D or earlier NavNet models) Pushing the boundaries of what is possible with conventional Radar technology, DRS6A X-Class marks yet another leap forward for FURUNO. Improved in almost all aspects, DRS6A X-Class Radar features improved short range detection, as well as an impressive long range detection of up to 120 nautical miles.The newly redesigned pedestal unit is 20% lighter than previous DRS6A model and features an updated motor for significantly lower noise levels. Combined with an updated smart-connector cable, installation and maintenance is simpler than ever before.Fast Target TrackingTM function adopted from our commercial Radar FAR3000, is also available on the DRS6A X-Class. Target course and speed vectors are displayed instantly with the press of a button. Target vectors increase situational awareness and can increase overall safety on your vessel.SpecificationsAntenna rotation speed24/36/48 rpm range coupled or 24rpm fixed Beam width 1.9d Horizontal 22d Vertical Range scales 0.0625 to 120 nm Waterproofing IP56 Power supply 24vDC 4.0A What's in the Box: 001-376-480-00 15m Cable RSB134-112 Pedestal XN12A/4 4 feet Antenna

Read more less

DRS6AX 6kW UHD Digital Radar with Pedestal, 4' Open Array Antenna & 15M CableDRS6AX "X-Class" a whole new class of Radar!Pushing the boundaries of what is possible with conventional Radar technology, DRS6AX "X-Class" marks yet another leap forward for Furuno. Improved in almost all aspects, DRS6AX "X-Class" Radar features improved short range detection, as well as an impressive long range detection of up to 120 nautical miles.The redesigned pedestal unit is 20% lighter than previous DRS6AX model and features an updated motor for significantly lower noise levels. Combined with an updated smart-connector cable, installation and maintenance is simpler than ever before.Fast Target Tracking™ function adopted from our commercial Radar FAR3000, is also available on the DRS6AX "X-Class." Target course and speed vectors are displayed instantly with the press of a button. Target vectors increase situational awareness and can increase overall safety on your vessel.Features: 6kW Power Output Enhanced target detection, both short and long range Minimum detection range of just 20M Fast Target Tracking™ Bird Mode Pedestal unit, 20% lighter than previous DRS6A unit, updated low noise motor No PSU required, decreasing total costs Easy installation without the need to open pedestal unit Smart-connector cable  Antenna - XN12A/4 is a 4' Open Array Antenna with a horizontal beam width of 1.85 degrees  15M Cable Compatible with NavNet TZtouch and NavNet TZtouch2 and NavNet TZtouch3 (not compatible with NavNet 3D or earlier NavNet models) The DRS6AX is a 24V system; a converter will be required for use with 12V power systems This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Power - Output: 6kW Array Size (Inches): 48" Box Dimensions: 8"H x 17"W x 17"L WT: 45.6 lbs

Read more less

Furuno DRS6AX 6kw UHD Digital Radar with 3.5 feet Antenna and 15M CableModel: DRS6AX/3 6kW Power Output Enhanced target detection, both short and long range Minimum detection range of just 20 m Fast Target TrackingTM Bird Mode New pedestal unit, 20% lighter than previous DRS6A unit, updated low noise motor No PSU required, decreasing total costs Easy installation without the need to open pedestal unit New smart-connector cable Choice of 3.5 feet/4 feet/6 feet Antenna Sold Seperately Compatible with NavNet TZtouch and NavNet TZtouch2 (not compatible with NavNet 3D or earlier NavNet models) The DRS6AX is a 24V system; a converter will be required for use with 12V power systems Pushing the boundaries of what is possible with conventional Radar technology, DRS6A X-Class marks yet another leap forward for FURUNO. Improved in almost all aspects, DRS6A X-Class Radar features improved short range detection, as well as an impressive long range detection of up to 120 nautical miles.The newly redesigned pedestal unit is 20% lighter than previous DRS6A model and features an updated motor for significantly lower noise levels. Combined with an updated smart-connector cable, installation and maintenance is simpler than ever before.Fast Target TrackingTM function adopted from our commercial Radar FAR3000, is also available on the DRS6A X-Class. Target course and speed vectors are displayed instantly with the press of a button. Target vectors increase situational awareness and can increase overall safety on your vessel.SpecificationsAntenna rotation speed24/36/48 rpm range coupled or 24rpm fixed Beam width 2.3d Horizontal 22d Vertical Range scales 0.0625 to 120 nm Waterproofing IP56 Power supply 24vDC 4.0A What's in the Box: 001-376-480-00 15m Cable RSB134-112 Pedestal Xn10A/3.5 3.5 feet Antenna

Read more less

DRS6AX 6kW UHD Digital Radar with Pedestal, 3.5' Open Array Antenna & 15M Cable DRS6AX "X-Class" a whole new class of Radar!Pushing the boundaries of what is possible with conventional Radar technology, DRS6AX "X-Class" marks yet another leap forward for Furuno. Improved in almost all aspects, DRS6AX "X-Class" Radar features improved short range detection, as well as an impressive long range detection of up to 120 nautical miles.The redesigned pedestal unit is 20% lighter than previous DRS6AX model and features an updated motor for significantly lower noise levels. Combined with an updated smart-connector cable, installation and maintenance is simpler than ever before.Fast Target Tracking™ function adopted from our commercial Radar FAR3000, is also available on the DRS6AX "X-Class." Target course and speed vectors are displayed instantly with the press of a button. Target vectors increase situational awareness and can increase overall safety on your vessel.Features: 6kW Power Output Enhanced target detection, both short and long range Minimum detection range of just 20M Fast Target Tracking™ Bird Mode Pedestal unit, 20% lighter than previous DRS6A unit, updated low noise motor No PSU required, decreasing total costs Easy installation without the need to open pedestal unit Smart-connector cable  Open Array Antenna - XN10A/3.5 has a 2.2 horizontal beam width. Its range is 48 nautical miles 15M Cable Compatible with NavNet TZtouch and NavNet TZtouch2 and NavNet TZtouch3 (not compatible with NavNet 3D or earlier NavNet models) The DRS6AX is a 24V system; a converter will be required for use with 12V power systems This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Power - Output: 6kW Array Size (Inches): 42" Box Dimensions: 8"H x 17"W x 17"L WT: 44.6 lbs

Read more less

Furuno TZT16X NavNet TZtouch3 Chart Plotter, 16 All-Glass IPS Display FULL HD (1920x1080)Model: TZT16X New TZ MAPS for highly-detailed navigation and fishing charts Built-in Dual Channel 1kW TruEcho CHIRPTM & CW Fish Finder Built-in 230kHz or 455kHz CHIRP Side-Scan Powerful hexacore processor for rapid response Explore the future of navigation with NavNet TZtouchXL - extra-large

Read more less

TZT16X 16" Multi-Touch Multi-Function DisplayThe 16” TZT16X features a super-wide all-glass display with exceptional clarity and brightness. The all-glass design allows these powerful MFDs to be mounted side-by-side for a seamless and stylish all-glass appearance to enhance both the functionality and sophistication of the helm.The TZT16X incorporates a powerful internal 1kW dual channel TruEcho CHIRP™ Fish Finder* designed to operate across a wide range of frequencies. For those who want to go even deeper, the 2kW/3kW DFF3-UHD TruEcho CHIRP™ Network Fish Finder delivers the ability to penetrate the deepest waters to find a catch. Also, with the BT-5 Booster Box, users can boost that output power up to 5 or 10 kW to take advantage of high-power transducer options that will unveil the deepest waters like users never experienced before.Features: 16 in. all glass display  TZ MAPS for highly detailed navigation and fishing charts Purchase and update charts directly from MFD with an internet connection Powerful hexacore processor for rapid response Video converter kits stream compatible sonar video data directly to TZtouchXL MFD Furuno’s exclusive Fish-It, Drift-It, & Follow-It features save time and fuel and increase fish catch Built-in Dual Channel 1kW TruEcho CHIRP™ & CW Fish Finder Built-in 235kHz or 455kHz CHIRP Side-Scan Built-In CHIRP Side-ScanFuruno’s CHIRP Side-Scan for NavNet TZT16X scans both port and starboard, illuminating the shape of the bottom structure in high definition. CHIRP Side-Scan 6 reveals the shape of fish targets and fish-hoarding structure on each side of the vessel. CHIRP from 235kHz or 445kHz center frequencies with thru-hull, paired, or transom mount transducer options.TZ MAPSOne of the most exciting TZtouchXL features is a chart offering called TZ MAPS. Not only are these some of the most detailed charts in the industry, but TZ MAPS users are in complete control of the chart content they want to download, such as raster or vector charts, satellite photos, and bathymetric data. Custom user objects can be shared with other registered TZ MAPS users through TimeZero's moderated service. Since custom objects reside on their chart layer on the TZtouchXL MFD, they can easily be displayed or hidden as desired. Additionally, for the first time, customers can purchase and update charts directly on their TZtouchXL MFD!BathyVisionOne of the most groundbreaking aspects of TZ MAPS is called BathyVision, providing amazingly detailed bathymetric data that can be configured to an incredible resolution of a mere 3 inches between contours! That's 3 times better than any other bathymetric chart currently on the market. BathyVision data, along with custom depth shading, can easily be overlaid on TZ MAPS navigation charts to create the ultimate "Fishing Charts"!AI RoutingTZ MAPS unlocks the ability to utilize the powerful AI Routing function that intelligently plans out routes, taking into consideration the boat's draft and navigational obstacles. AI Routing takes traditional auto-routing to another level by automatically creating suggested routes based on varying navigational conditions.Risk Visualizer & AI Avoidance RouteWhen connected to an NXT radar, two powerful safety features are unlocked: the Risk Visualizer and the AI Avoidance Route tool. Risk Visualizer provides a 360° visual representation of the potential collision risks of approaching objects around the vessel. Dynamic icons are automatically created for targets with the highest probability of collision, ensuring the captain has the necessary information to maintain safe distances when passing. The AI Avoidance Route function processes all available information provided to dynamically provide a safe route around those hazards, which can be sent to a Furuno NavPilot autopilot with a single tap.Enhanced User Interface for Ease of Use & CustomizabilityIn addition to offering all the great features that make NavNet super simple to operate, NavNet TZtouchXL MFDs also deliver BIG power and versatility! Users can now configure their MFD in many ways, thanks to an increased number of Page Builder configurations from four (4) to ten (10) custom combinations. Additionally, users can now custom-build a 6-way screen split of various components and sensors.Match all those great screen layout options with enhanced Edge-Swipe feature access for the smoothest, easiest, and very best user experience Furuno has ever delivered! This is all driven by the most system memory and the highest level of processing power Furuno has ever integrated into a NavNet MFD. Specifications:Display Unit: Type: Color TFT multi-touch IPS LCD Screen Size: 15.6" Wide Screen Resolution: FHD 1920 x 1080 Screen Brightness: 900 cd/m2 (typical) Display Colors: 16,770,000 colors (Chart Plotter), 64 colors (Radar/Fish Finder) Language: Bulgarian, Chinese, Danish, English (USA/UK), Finnish, French, German, Greek, Italian, Japanese, Norwegian, Portuguese, Russian, Spanish, Swedish, Turkish, Polish GPS/WAAS: Receiver Type: GPS: 72 channels, SBAS: 1 channel (C/A mode, WAAS) Receiving Frequency: L1 (1575.42 MHz) Time to First Fix: 100 s (cold start) Accuracy: 10 m (GPS), 7 m (MSAS), 3 m (WAAS) Position Update Interval: 100 ms or 10 Hz Chartplotter: Cartography: TZ MAPS, MM3 Vector, and CMOR capable (U.S. only) Memory Capacity: 30,000 user points, 100,000 points for ship's tracks, 200 planned routes (500 points per route) Alarms: Anchor Watch, XTE, Depth*, Speed, Sea Surface Temperature*, Trip Distance, Fuel Gauge* (*external data required) Radar: Display Modes: Head-up, North-up*   *Heading input required.  Echo Trails: Interval: 15 s, 30 s, 1 min, 3 mins, 6 mins, 15 mins, 30 mins, and continuous (Heading input required)  Target Tracking: 100 ARPA Targets (Radar dependent) with fully automatic target acquisition (Heading input required)  Radar Alarms: Guard Zone, CPA/TCPA, Video, Azimuth, Heading Line Fishfinder: Transmit Frequency*: CW: 50/200 kHz, CHIRP: 40 kHz to 240 kHz (Low, Medium, and High) Transducer: 300/600 W or 1 kW*   *Matching box MB1100 required for some transducers Display Range: 2 to 1,200 m; shift 0 to 1,200 m (1,200-2,400m / 4,000-8,000ft)  Extension Mode: ACCU-FISH™, A-Scope, Auto (Fishing/Cruising), Bottom Discrimination, TruEcho CHIRP™ (with compatible transducer)  Picture Advance: 8 steps: x4, x2, x1, 1/2, 1/4, 1/8, 1/16, stop  Fish Finder Alarms: Fish School, Fish School for the bottom lock Side-Scan:  Transmit Frequency*: CHIRP: 220-240KHz/445-465KHz Transducer: 225kHz: 225T-PR904, 225T-SS904. 225T-TM904 / 455kHz: 455T-PR903, 455T-SS903. 455T-TM903  Display Range: 750 feet to each side  Display Colors: Green, Blue, Amber, White  Display Screen Sizes: Full Screen, 1/2 Screen, 1/4 Screen, 1/6 Screen Full Screen, 1/2 Screen, 1/4 Screen, 1/6 Screen  Direct Connect to MFD: Direct connect to TZ10X, TZT13X, TZT16X only; may be networked with TZT22X/TZT24X Interface: NMEA200: 1 Port Input: 065280, 126992/993/996, 127237/245/250/251/257/488/489/505, 128259/267, 129025/026/029/330/038/039/040/041/291/538/540, 129793/794/798/801/802/808/809/810, 130306/310/311/312/313/314/316/576/577/578, 130817/818/820/822/823/826/827/828/880 Output: 126992/993/996, 127250/251/257/258, 128259/267/275, 129025/026/029/033/283/284/285, 130306/310/311/312/313/314/316 NMEA0183: 1 Serial Output Port Output: AAM, APB, BOD, DBT, DPT, GGA, GLL, GNS, GSA, GSV, RMB, RMC, RTE, TTM, VDM, VTG, WPL, XTE, ZDA LAN: 1 Port (1000 BASE-T) USB: 1 Port (USB 3.0) for touch monitor and control unit: 1 Port USB touch output for HDMI device Video I/O: Input: 1 port (NTSC/PAL) and 1 port HDMI 1920 x 1080p or less (progressive only); Output: 1 port (HDMI 1080p) AUX I/O: 2 Ports (Event Switch and External Power Switch) SD Card Slot: 1 Slot (Micro SDXC, rear) Wireless LAN: IEEE802.11b/g/n, Transmit frequency: 2.412 to 2,462 GHz, 11dBm max Transducer Connection: 1 Port 12 pin for CHIRP/CW, 1 Port 12 pin for Side-Scan Environment: Temperature (IEC60945)-15°C to +55° C Relative Humidity: 93% or less at +40° C Waterproofing: IP56 Power:12-24 VDCThis product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Screen Size: 16" Touchscreen: Yes Box Dimensions: 13"H x 16"W x 19"L WT: 17.3 lbs Brochure (pdf)

Read more less

Furuno FR8065 12.1 in Color Radar 6kw 72nm open array Model: FR8065 12.1 in SVGA color LCD with echo colors of 32 levels Wide viewing angle LCD for great visibility from any direction One-touch auto-adjust settings for Gain/Sea clutter/Rain clutter Optional 48 rpm high-speed antenna rotation displays information clearly in narrow passages and on high-speed vessels Superior short range target detection capability Advanced auto modes to automatically adjust gain, tuning and AC rain/sea for delivering the best available pictures True motion echo trail Display Modes: Head-up, Course-up, North-up, True View, True Trail Up to three programmable radar settings can be selected to give the best radar performance in different sea conditions State of the art signal processing and UHDTM digital radar technology! The 12.1 in color radar FR8005 series features state of the art signal processing, which makes it easier to identify targets in heavy rain and poor visibility. The FR8005 radar can discern between rain and surface reflections, providing the ability to find and track the movement of rain clouds as well as removing unnecessary echoes. For tracking the movement of other vessels at sea, "True Motion Trails " can be displayed as well as AIS/TT target-tracking with a zoom display function. When the vessel is in motion, the radar echoes move smoothly on the main display thanks to the "True View Mode." Target-Tracking Zoom Display Function Even during rainfalls or severe weather conditions, radar echoes are clearly displayed, and unnecessary echoes can be removed instantly with ease. Compared with current radars (FR8002 series) the technology for removing sea, rain and snow clutter has been greatly enhanced utilizing FURUNO's state of the art knowledge in digital signal processing. When using the Target mode, vessels close by and vessels on intersecting courses are automatically displayed zoomed in. These targets will remain displayed for as long as they pose any concern. Target Trails are also displayed, making it easy for the user to determine the movements of individual vessels. True Trail Mode When using the True Trail Mode, moving objects will show up on the main screen with a colorful trail. These trails make it possible to see the movement of nearby vessels in the blink of an eye. True View Mode The radar echoes move smoothly on the main display thanks to the "True View Mode". The True View Mode is based on the head-up mode. During the radar sweep, the echoes move according to the heading of your ship. Since the echoes move in real-time, the discrepancy between an observed target and what is displayed on the radar screen is greatly reduced. Full-Screen Mode and Off-Center Mode Make use of the whole display surface with the Full-Screen mode, giving you more information when making important decisions. When combining Full-Screen mode with Off-Center mode any target or point of interest can be observed in detail. The overlay information can be turned off, to observe targets obstructed by the text as well as providing an unobstructed radar view. Target Tracking and AIS Display The Target Tracking (TT) feature continously tracks and provides positional information for up to ten targets. An AIS device-equipped FR8005 series radar can track target heading, name, speed and direction of movement. With AIS it is possible to identify and track the movement of other vessels in heavy fog, during nighttime and otherwise difficult conditions. Another benefit is that with AIS you can identify obscured targets that the radar signals cannot reach, giving you more time to act. AIS can display up to 100 targets simultaneously, TT can display up to 10 different targets simultaneously. Requires either XN12A4 or XN13A6 Antenna Specifications Maximum Range Scale 72 NM range Discrimination 25 m Bearing Discrimination 1.9 deg XN12A4 1.35 deg AN13A6 Minimum Detection Range 25m Antenna Length 4 feet ( XN12A4 ) 6 feet ( XN13A6 ) Rotation Speed 24 RPM Wind Load 100Kn Horizontal Beam Width 1.9 deg XN12A4 1.35 deg XN13A6 Vertical Beam Width 22 deg Screen Size 12.1 in Color LCD Screen Resolution 800V x 600H Interface Input: NMEA0183 Ver. 1.5/2.0/3.0/4.0, AD-10 format Output: NMEA0183 Ver. 1.5/2.0/3.0/4.0 Input Voltage 24vDC Dimensions Display: 12.6 in W x 12.6 W x 6.8 in D without bracket, bracket adds 1 in to height What's in the Box: RDP154 Display Bracket and Knobs Sun Cover Power Cord Owners Manual Operators Guide Installation Manual RSB0070-085A Gear Box 6Kw 15m Signal Cable

Read more less

Furuno FCV1150 12.1 Color FishfinderModel: FCV1150 High-brightness 12.1 inch LCD with AR coated glass filter and anti-polarized sunglass filter Postprocessing Gain Control applied to all echoes displayed on the screen White Edge bottom discrimination feature Heaving compensation available for stable echo presentation even in rough seas Furuno Digital Filter (FDF) delivers crystal clear target presentation Adjustable operating frequency and selectable output power The FCV1150 is a color digital sounder designed for a variety of professional fishing operations. It's high-brightness 12.1 inch color LCD with AR coated glass filter provides superior

Read more less

FCV1150 12.1" Color FishfinderThe FCV1150 is a color digital sounder designed for a variety of professional fishing operations. It's high-brightness 12.1" color LCD with AR coated glass filter provides superior, glare-free viewing even in direct sunlight.The FCV1150 employs Furuno Free Synthesizer (FFS) technology which permits a wide selection of operating frequencies from 28 to 200kHz. If a Furuno transducer is used, operating frequency is automatically set in the menu, and can be shifted manually at any time. This feature is useful for vessels targeting many different species of fish, and may also be used to eliminate interference that may be caused by nearby ships with transducers operating at the same frequency. Output power is selectable among 1,2 or 3 kW.A wide variety of display modes and functions are available that provide captains with simple and intuitive information for virtually any fishing requirement including Single (HF/LF), Dual, Single + Zoom, Zoom (Bottom Lock, Bottom Zoom or Marker Zoom), Mix Mode, Nav Data and A-Scope. Additionally, two custom display modes may be programmed by the operator. The FCV1150 can be interfaced with a Furuno Satellite Compass to compensate for heaving caused by the movement of the ocean, providing unwavering, stable detection even in rough seas.Faster Transmission Rate: The rate of transmission has been greatly increased by more than 30% compared with current conventional fish finders. As a result, more detailed information about underwater conditions can be gained in the same sounding interval. The FCV1150 also incorporates new transmission technique that automatically switches the echo transmission rate according to the depth of the sounding area. Transmission speed is raised in shallow waters and lowered in deep waters, providing more detailed detection of seabed and targets.Quick Gain Setting: The Gain setting for all of the echoes on the screen can be adjusted by rotating the Gain knob. Because all of the visible echoes on the screen are adjusted with the Gain settings, the correct setting for virtually any situation can be quickly and easily determined.White Edge: The top of the seabed is displayed in white to show seabed structure. This function also helps to discriminate between bottom fish and seabed. Standard Features: High-brightness 12.1" LCD with AR coated glass filter and anti-polarized sunglass filter Postprocessing Gain Control applied to all echoes displayed on the screen White Edge bottom discrimination feature Heaving compensation available for stable echo presentation even in rough seas Furuno Digital Filter (FDF) delivers crystal clear target presentation Adjustable operating frequency and selectable output power Power Requirements: 12-24 VDC, 50W max 100/110/220/230 VAC with optional rectifier This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Screen Size: 12.1" Transducer Type: Not Included Included Transducer: No Box Dimensions: 14"H x 18"W x 18"L WT: 28 lbs UPC: 611679309082 Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

Furuno MU152HD LCD Display 15 Color LCD MonitorModel: MU152HDThe FURUNO MU152HD is a multi-purpose marine LCD that features Furuno's unmatched quality and reliability that you depend on. The MU152HD employs an extremely bright (1

Read more less

Furuno DRS6ANXT Solid-State Doppler Radar with Target Analyzer and Fast Target TrackingModel: DRS6ANXT Solid-State pulse compression Doppler Radar Revolutionary Target AnalyzerTM function instantly identifies hazardous targets Fast Target TrackingTM and Auto Target Acquire function, up to 100 target RezBoostTM beam sharpening to increase the resolution Bird Mode to find the best fishing grounds by tracking birds The Furuno NXT Radar is the next step in Radar evolution; a Solid-State Radar with pulse compression, Target AnalyzerTM and Fast Target TrackingTM utilizing Doppler technology. Combined with FURUNO exclusive RezBoostTM technology for beam sharpening, NXT packs the performance of a larger Radar in a more compact package.NXT is the first radar in the world to use the new Furuno exclusive Target AnalyzerTM function, where targets that are approaching your vessel automatically change color. Green targets are targets that stay stationary, or are moving away from you, while red targets are moving towards your vessel. Target AnalyzerTM works independent of vessel speed, both your own vessels and target vessels, with minor limitations. Echoes dynamically change colors as targets approach, or get farther away from your vessel. Target AnalyzerTM can increase safety, as well as improve situational awareness.Once a target has been selected, a speed and course vector is displayed in seconds. With accurate tracking information, estimation of other vessel's course and speed is greatly simplified. With Doppler technology, any vessel approaching yours will automatically display a target vector, as well as sound an alarm.For the first time Furuno's exclusive RezBoostTM technology is used in one of our Radar units, with impressive performance. With RezBoostTM set to MAX, the sharpness of a 2 degree beam width can be achieved.*Cable Sold Separately Effective 06/20/2022*SpecificationsAntenna Size ( Sold Seperately)3.5, 4 or 6 foot Band X Power usage 12-24vDC Range 72nm Antenna type Open array Beam width 3.5 feet antenna 2.3 degrees4 feet antenna 1.9 degrees6 feet antenna 1.4 degrees Power output 25 watt What's in the Box:RSB137-119 Pedestal

Read more less

DRS6ANXT Solid-State Doppler Radar Open Array - Add Cable & Array AntennaThe DRS6ANXT leverages the same pulse compression and Doppler frequency shift sensing technologies featured in the DRS4DNXT, as well as offering the same simplified connection with TZtouch and TZtouch2, and TZtouch3.Target AnalyzerTarget Analyzer may be one of the most innovative and revolutionary features available in the NXT family, automatically changing the color of targets approaching your boat to clearly show potential hazards. Green echoes represent stationary targets, land, or approaching targets moving at a velocity of less than 3 knots. Echoes dynamically turn red when targets are approaching your vessel at a speed of 3 knots or faster. It works the same when you are following another vessel. If the target is getting closer at a speed of 3 knots or more, the echo will be depicted in red. Incredibly, Target Analyzer works independently of one's own ship speed!Target TrackingInterpreting and tracking threats is easier than ever with NXT radar. Using Furuno's advanced Doppler technology, NXT Radars acquire and track targets in virtually every sweep. Almost instantly, you'll see the target's speed and course vector, and if the target is hazardous, it will also be displayed in red, making it easier to identify and predict its course. The NXT Radar's incredible ARPA signal processor tracks and displays up to 100 targets! The entire target theater can be viewed, monitored, and tracked simultaneously, at any range. For an even more detailed display, target trails and Furuno's unique True Trail feature can be utilized, allowing you to graphically see the direction in which a target is moving, independent of your own vessel's motion.Bird ModeBird Mode is another standard feature found in NXT Radars. With a single selection on the MFD, the Radar automatically adjusts settings for echo enhancement to help locate birds. Of course, finding birds is an important step to zeroing in on the bite.RezBoost The resolution of NXT Radars is already impressive, but we've taken it a step further by incorporating our exclusive RezBoost beam sharpening technology. With RezBoost set to maximum, NXT Radars offer enhanced target separation, in addition to its impressive long-range target detection.*NEED TO ORDER YOUR SIGNAL, POWER CABLE, AND ANTENNA SEPARATELYThis product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Brochure (pdf)

Read more less

NavNet TZtouch3 19" MFD with 1kW Dual Channel CHIRP™ SounderGo on a power trip with Furuno! Furuno listened to you and worked tirelessly to make NavNet TZtouch3 the easiest MFD on the market to use, with all of the power you’ve wanted and more. These 12-inch, 16-inch, and 19-inch MFDs feature a quad-core processor for lightning-fast response, a built-in GPS receiver (TZT12F & TZT16F only), and an internal 1kW TruEcho CHIRP™ Fish Finder, making them ready  for action right out of the box. For those looking for even more power, simply add the all-new 2/3kW Deep Impact TruEcho CHIRP™ Amplifier or the power-packed 100W/200W NXT Solid-State Doppler Radars. Use the PIN Code Lock feature to secure your NavNet TZtouch3 data by requiring a four-digit password to be entered at startup.Features: Built-in Dual Channel 1kW TruEcho CHIRP™ 19” multi-touch IPS displays DI-FFAMP – optional high-power TruEcho CHIRP™ Fish Finder Amplifier, designed to work exclusively with NavNet TZtouch3. This 2kW or 3kW TruEcho CHIRP™ Fish Finder amp gets you down to the deepest waters to find your catch. You can even connect a 5kW or 10kW transducer! (BT-5 required) High-power 100W or 200W Solid-State Doppler Radar options, with Target Analyzer™, Fast Target Tracking™, Bird Mode and Rain Mode Quad-screen display configuration allows for presentation of 1, 2, 3, or 4 different functions IPS LCD provides superior viewability from virtually any angle Compatible with NavNet TZtouch2 Networks Create your routes at home, using TZ Navigator, a web browser*, or TZ iBoat iOS App. Then you can sync  your data from the cloud to your TZtouch3 system. (*Cloud.MyTimezero.com raster planning charts for US only) TZ First Mate App keeps track of your catch & location  Synchronize data with a tablet or smartphone Add Autopilot, Instruments, Radar, AIS, Multi-Beam Sonar, and a variety of other sensors to your NavNet TZtouch3 network Full Autopilot control from MFD, when connected to the NAVpilot-300/711C Compatible with CZone digital switching Free weather data, using NavCenter Weather or optionally connect BBWX4 SiriusXM Weather Receiver This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Screen Size: 19" Transducer Included: No Cartography Brand: Furuno Touchscreen: Yes Box Dimensions: 11"H x 16"W x 24"L WT: 25 lbs UPC: 611679389206 Brochure (pdf)

Read more less

NavNet TZtouch2 Black Box Chartplotter/FishfinderTotal Control, Simply RefinedWith the ability to drive multiple monitors with full HD HDMI video output in any combination of monitor aspect ratios (4:3 and 4:3, 16:9 and 4:3, or 16:9 and 16:9), a refined graphical user interface, and a built-in RezBoost Fish Finder, Furuno's NavNet TZtouch2 Black Box is a beauty to behold and use. Whether you are searching for hot fishing grounds, plotting your next route, or using your Radar to navigate through fog, NavNet TZtouch2 delivers smooth operation with familiar touch gestures.Simply Refined, Simply BeautifulFollowing in the footsteps of the original NavNet TZtouch, TZtouch2 features a refined user interface that is all about usability. Elegantly designed, NavNet TZtouch2 allows you to build a navigation suite that is not only functional, but offers a luxurious look and feel. Taps, swipes, pinches, and custom multi touch gestures are instantly transformed into action, giving you full control of every component connected to your network.Incredibly easy-to-use controller and graphical user interfaceThe optional MCU005 NavNet TZtouch2 Black Box controller enhances the built-in Multi Touch graphical user interface, and sets a new benchmark for "easy to use" in the marine electronics industry. This interface is not only intuitive, but is as easy to use as the phone in your pocket. The combination of an ergonomically designed, logical controller, along with a touch-screen Graphical User Interface, make operation simple. With taps, slides and swipes, you will be up and using your TZtouch2 in no time at all. Menus and other features slide out from each of the sides of the screen, ensuring that the most important tasks are literally right at your fingertips.The available MCU004 Remote Control option features a large rotary knob which can be utilized for zooming in/out, while the joy stick allows you to pan around the chart and move the cursor on the screen. The MCU004 remote has 8 dedicated buttons that operate different functions, such as Edge Swiping, Home, Stand By/Auto for Autopilot control, MOB, and Center on vessel.Powerful Fish Finder with built-in Furuno featuresThe built-in Fish Finder is a dual-frequency (50/200kHz), 600W/1kW power output sounder. It includes Furuno’s unique Bottom Discrimination and AccuFish modes, and also incorporates another new Furuno proprietary Fish Finder technology, called RezBoost. RezBoost is a revolutionary new feature that utilizes Furuno’s exclusive digital signal processing protocol to produce fantastic target resolution and separation, without the need to change out your transducer, or purchase expensive broadband transducers. With RezBoost, you can now achieve target separation and resolution that was previously limited to Furuno commercial-grade Fish Finders.Freedom to build the helm of your dreamsNavNet TZtouch2 is a component-based system that utilizes Furuno’s award winning network products. You can add a variety of UHD Radars, from a 4kW NXT Dome up to a 25kW X-Class Open Array. As with NavNet TZtouch, you can integrate, display, and control the NavPilot Autopilot, and Furuno’s FI70 Instrument. Both of these products have displays that match TZtouch2, giving your helm a beautiful all-glass finish. Additional sensors that can be added to the network include AIS, Weather Fax, Sirius/XM Satellite Weather, Fusion Marine Stereo, and IP Cameras, as well as NMEA2000 and Furuno CAN bus devices. It even includes one NMEA0183 output port to send data to legacy systems.Remotely view and control your bridge with apps for your smartphone and tablet Engineered to utilize the latest technology, NavNet TZtouch opens the door to cutting edge WiFi features, such as tablet and smartphone apps, points of interest (POI), real time weather data, software updates and more. Take full control of your NavNet in a whole new way. The TZtouch Remote app allows you to operate your system remotely with your smartphone or tablet over WiFi, when connected to the network.MapMedia Raster and Vector Chart LibraryFreely choose the charts that fit your individual needs and preference. MapMedia's NOAA Raster and Vector charts for the U.S. Coasts, Gulf of Mexico, Alaska and Hawaii come pre-loaded. In addition, MapMedia brings you free satellite photos and detailed fishing bathymetric charts that can be download for the U.S. Outside of the U.S., "C-MAP" and "Datacore by Navionics" vector cartography can be purchased and downloaded to your NavNet with ease. MapMedia cartography integrates cutting edge algorithms with high resolution image processing techniques to deliver a fusion of digital navigation charts and satellite photography. Satellite PhotoFusion™ offers a birds-eye view without obstruction of critical dataYou can load any two ultra-wide high-resolution satellite photo areas at your convenience. Land areas (zero depth) are completely opaque, so these areas are displayed as high-resolution satellite photos on the chart. As the depth increases, the satellite photography becomes more transparent. This allows you to see where the shallows end and the deeper water begins, while still allowing the raster or vector chart to be visible.Free & easy-to-use marine weather forecastsThe weather tool is completely free and easy to use, giving you unlimited access to weather forecasts worldwide 24 hours a day provided by NavCenter. Select geographic coverage, data type, period of time, and then choose how to receive the file. NavNet TZtouch2 provides up to 16 days of weather forecasting.This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Read more less

Furuno SC70 Satellite Compass Model: SC70 Provides highly accurate heading data of 0.4 deg for autopilot, Radar, ARPA, Scanning Sonar, Current Indicator, Chart Plotter, ECDIS and Autopilots Ideal for small to medium boats requiring highly accurate heading Utilizes GNSS such as GPS, Galileo and GLONASS for high Precision SBAS compatible (EGNOS,WAAS,MSAS) Provide precise data for SOG, COG, ROT and L/L Eliminating the problem of not having enough satellites at hand by using multiple types of satellites Speed on 3 axis (bow, stern and longitudinal) for safe navigating and berthing IMO Type-approved as THD, GPS and ROTI. Complying with the IEC, ISO requirements Easily integrated into the existing shipboard network via Ethernet Rapid follow-up rate 40 deg/s (twice the IMO high speed craft requirement, 20 deg/s) Maintenance free and no recurring cost as there are no mechanical parts Super short starting time - 90 seconds Once the power is on, it takes about 90 seconds to start (the starting time will slightly differ depending on the equipment location) Easy to retrofit by using existing antenna cabling for SC-50/55/60/110/120. (The LAN_CNV option kit is necessary) Precision pitch/roll data in Analog and Digital formats for vessel stabilization, Sonar, etc. The SC70 is the latest satellite compass built on FURUNO's commercial-grade technology platform. These satellite compasses prove their value by increasing the accuracy of other devices, such as Radar, ARPA, Scanning Sonar, Current Indicator, Chart Plotter, ECDIS and Autopilots. They provide a highly accurate heading input to these other technologies by utilizing the very latest GNSS (Global Navigation Satellite System). This satellite system is comprised of GPS, Galileo and GLONASS to ensure the highest precision and a continuous coverage. The SC70 provides a variety of data, including GPS Positioning, SOG (Speed Over Ground), COG (Course Over Ground), ROT (Rate Of Turn) and 3-axis speed (bow, stern and longitudinal). All of these data assist with critical maneuvers, such as berthing. The compasses is maintenance free - a great asset for any vessel. What's in the Box: Box 1 - SC701 Junction Box Box 2 - SC702 Display Box 3 - SC703 Antenna Unit

Read more less

Furuno TZT19F 19 TZtouch3 Chart Plotter/Fish FinderModel: TZT19F Go on a power trip with the most powerful MFD series available EASY to use; because finding your happy place shouldn't be difficult! The return of Hybrid Control Protect your livelihood with new PIN CODE security Never lose waypoints

Read more less

DRS12AX 12kW UHD Digital Radar - Less Antenna and CablePushing the boundaries of what is possible with conventional Radar technology, DRS12AX "X-Class" marks yet another leap forward for Furuno. Improved in almost all aspects, DRS12AX "X-Class" Radar features improved short range detection, as well as an impressive long range detection of up to 96 nautical miles.The redesigned pedestal unit is 20% lighter than previous models and features an updated motor for significantly lower noise levels. Combined with an updated smart-connector cable, installation and maintenance is simpler than ever before.Fast Target Tracking™ function adopted from our commercial Radar FAR3000, is also available on the DRS12AX "X-Class." Target course and speed vectors are displayed instantly with the press of a button. Target vectors increase situational awareness and can increase overall safety on your vessel.Features: 12kW Power Output Enhanced target detection, both short and long range Minimum detection range of just 20 m Fast Target Tracking™ Bird Mode Pedestal unit 20% lighter than previous unit, updated with new, low noise motor No PSU required, decreasing total costs Easy installation without the need to open pedestal unit Smart-connector cable Choice of 3.5'/4'/6' Antenna Requires Signal/Power Cable Compatible with NavNet TZtouch and NavNet TZtouch2 (not compatible with NavNet 3D or earlier NavNet models) The DRS12AX is a 24V system; a converter will be required for use with 12V power systems This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Power - Output: 12kW Box Dimensions: 16"H x 17"W x 19"L WT: 42 lbs UPC: 0611679368362

Read more less

Furuno 165T-PM542LM High-Power Pocket Mount Combination TransducerModel: 165T-PM542LM DFF3D operating frequency 165 kHz Built-in motion sensor Built in temp sensor Low-CHIRPS from 30 kHz to 60 kHz, Beamwidth 19 deg to 10 deg (10 deg to 5 deg fore-aft) Medium-CHIRPS from 80 kHz to 130 kHz, Beamwidth 13 deg to 8 deg All of these elements are built into an Airmar PM542 Urethane housing 12M Cables. Two cables for Low & Medium CHIRP, 7 pin connector and a pigtail cable for the DFF3D Pocket Mount Combo Transducer Low/Medium TruEcho CHIRP for FCV1900/FCV1900B (30-60 kHz and 80-130 kHz), DI-FFAMP, and DFF3D Multi-Beam Sonar (165 kHz) only

Read more less

Furuno DRS6AX 6kw Open array Pedestal Only, No CableModel: DRS6AX 6kW Power Output Enhanced target detection, both short and long range Minimum detection range of just 20 m Fast Target TrackingTM Bird Mode New pedestal unit, 20% lighter than previous DRS6A unit, updated low noise motor No PSU required, decreasing total costs Easy installation without the need to open pedestal unit Choice of 3.5 feet/4 feet/6 feet Antenna Sold Seperately The DRS6AX is a 24V system; a converter will be required for use with 12V power systems Compatible with NavNet TZtouch and NavNet TZtouch2 (not compatible with NavNet 3D or earlier NavNet models) Pushing the boundaries of what is possible with conventional Radar technology, DRS6A X-Class marks yet another leap forward for FURUNO. Improved in almost all aspects, DRS6A X-Class Radar features improved short range detection, as well as an impressive long range detection of up to 120 nautical miles.The newly redesigned pedestal unit is 20% lighter than previous DRS6A model and features an updated motor for significantly lower noise levels. Combined with an updated smart-connector cable, installation and maintenance is simpler than ever before.Fast Target TrackingTM function adopted from our commercial Radar FAR3000, is also available on the DRS6A X-Class. Target course and speed vectors are displayed instantly with the press of a button. Target vectors increase situational awareness and can increase overall safety on your vessel.Requires Antenna and cable Sold SeperatelySpecificationsAntenna rotation speed24/36/48 rpm range coupled or 24rpm fixed Beam width XN10A: 2.3d Horizontal 22d VerticalXN12A: 1.9d Horizontal 22d VerticalXN13A: 1.4d Horizontal 22d Vertical Range scales 0.0625 to 120 nm Waterproofing IP56 Power supply 24vDC 4.0A What's in the Box:RSB134-112 Pedestal

Read more less

6kW UHD Digital Radar  - Less Antenna and CableDRS6AX "X-Class", a whole new class of Radar!Pushing the boundaries of what is possible with conventional Radar technology, DRS6AX "X-Class" marks yet another leap forward for FURUNO. Improved in almost all aspects, DRS6AX "X-Class" Radar features improved short range detection, as well as an impressive long range detection of up to 120 nautical miles.The redesigned pedestal unit is 20% lighter than previous DRS6AX model and features an updated motor for significantly lower noise levels. Combined with an updated smart-connector cable, installation and maintenance is simpler than ever before.Fast Target Tracking™ function adopted from our commercial Radar FAR3000, is also available on the DRS6AX "X-Class." Target course and speed vectors are displayed instantly with the press of a button. Target vectors increase situational awareness and can increase overall safety on your vessel.Features: 6kW Power Output Enhanced target detection, both short and long range Minimum detection range of just 20M Fast Target Tracking™ Bird Mode Pedestal unit, 20% lighter than previous DRS6A unit, updated low noise motor No PSU required, decreasing total costs Easy installation without the need to open pedestal unit New smart-connector cable Choice of 3.5', 4' or 6' Antenna Compatible with NavNet TZtouch and NavNet TZtouch2 (not compatible with NavNet 3D or earlier NavNet models) The DRS6AX is a 24V system; a converter will be required for use with 12V power systems Requires a signal/power cable Specifications: Power - Output: 6kW Box Dimensions: 16"H x 17"W x 19"L WT: 22 lbs UPC: 611679364463

Read more less

Furuno NAVPILOT711C ColorFor Yamaha HelmMasterModel: NAVPILOT 711C/OB-HMThe NavPilot 711C/OB-HM is a complete NavPilot 711C/OB system with all of the necessary components, cables and gateways to connect to a Yamaha Helm Master system (not included).FishHunter mode is a unique feature of FURUNO's NavPilot series. Find a fish target with your FURUNO sonar/sounder or bird target with your FURUNO radar and feed it to the NavPilot The NavPilot will activate the FishHunter mode to perform square, zigzag, circle, orbit, spiral or figure-eight maneuvers around the specified target at a user selected distance. This feature can also be used for Man Overboard (MOB).With Fantum Feedback, NAVpilot outboard/sterndrive installations no longer require use of a physical rudder feedback unit. NAVpilot software clears the path to a simplified installation, while also delivering enhanced steering control.SpecificationsNavPilot 711C/OBYamaha HelmMaster Pack

Read more less

Furuno TZTBBX TZTTouchXL Black BoxModel: TZTBBXExplore the future of navigation with the Black Box NavNet TZtouchXL TZTBBX and enhance the functionality and style of your helm. NavNet TZtouchXL delivers the ability to tailor the helm to meet the captain's exact needs, with magnetron or Solid-State Doppler Radars, high-powered Fish Finders, AIS, Autopilot, and Deep Water Multibeam Sonar options, and more!NavNet TZtouchXL delivers new features like TZ MAPS with BathyVision, the most advanced and capable electronic charts in the world. The TZ Maps engine draws upon a worldwide database of high-resolution information to create crisp, clear navigation with a variety of color themes and fishing charts with fully editable color palettes. TZ Maps deliver a timeless navigation experience at any magnification. It sounds incredible, and it is - you have to see it to believe it!You asked for the simplest interface possible, and we were listening. We've delivered the most intuitive UI available, bar-none, and you'll be navigating with all the power and simplicity you demand. If you swipe your phone, you can operate TZtouchXL. With edge-swipe features and single-tap menu options, you're never more than a tap or swipe away from what you want to see or do, because NavNet TZouchXL provides the easiest and most powerful MFD on the planet.With TZ MAPS, navigators control what map data they want to download, such as incredibly wide chart areas, satellite photos, and bathymetric data. Purchase incredibly wide chart areas directly from the MFD! Custom depth color shading and bathymetric data overlays create navigational charts of unmatched detail and clarity, rendered with a variety of color themes to provide an electronic charting experience that goes far beyond any premium chart service before it. You can create your own custom objects or make updates to charted objects, such as buoys, so when they move from their previously charted positions, they can be updated on the system on the fly. Custom user objects can be shared with other registered TZ MAPS users through TimeZero's new moderated service, and can be turned on and off in the Layers menu, available with a single edge swipe up from the bottom of the display. Purchase of any TZ MAPS area also unlocks added functionality, such as powerful AI Routing that intelligently plans out routes, taking into consideration the boat's draft as well as charted depths and navigational obstacles. The purchase of any TZ MAPS chart unlocks those charts in the free TZ iBoat app for mobile devices such as a phone or tablet, providing you with a free home planning app that will transfer your points and routes directly to the TZtouchXL. With a free TimeZero account, waypoints and routes can be easily backed up or retrieved from the cloud with just a few taps, ensuring all the data you've worked so hard to create remains safe and secure.BathyVision for TZ MAPS provides truly 'off the charts' bathymetric data with contour lines that can be configured with a single tap. When we say configurable, we're talking down to a resolution of a mere 3 inches between contours - that's 3x better than any other bathymetric chart currently on the market. Bathymetric data is rendered from the same high-resolution database used for TZ MAPS' custom depth shading and can be overlaid onto the navigation charts to create fishing charts unlike any seen before.Create your routes at home using TZ Navigator, a web browser*, or the TZ iBoat iOS App, then download them to your TZtouchXL MFD from the cloud. You can also backup all of the events on your MFD and retrieve them at home, because your data is synchronized automatically & securely. TZ Cloud saves all of your marks, routes, boundaries, photos, and catch data - with a free TimeZero account, all of your data can be backed up or retrieved with just a few taps. The purchase of any TZ MAPS chart directly from the MFD also unlocks those charts in the free TZ iBoat app for mobile devices such as a phone or tablet and TZ Pro navigation software, providing the only home planning solution you'll ever need.Furuno's CHIRP Side-Scan for NavNet TZtouchXL scans both port and starboard, illuminating the shape of bottom structure in high definition. CHIRP Side-Scan reveals the shape of fish targets and fish-hoarding structure to each side of your vessel. CHIRP from 230kHz or 445kHz center frequencies with thru-hull, paired, or transom mount transducer options. CHIRP Side-Scan is built into the TZT10X/13X/16X, and can be accessed by any TZtouchXL MFD on the network.We've raised the bar for sportfishing enthusiasts once again with an MFD series designed to cater to the needs of avid anglers. The NavNet TZtouchXL series includes all the features fishermen desire, including exclusive, never-before-seen features in recreational navigation devices. The TZT10X, TZT13X, and TZT16X feature a built-in 1kW TruEchoTM CHIRP or CW Fish Finder as well as built-in 230kHz or 455kHz CHIRP Side-Scan to show fish and fish-hoarding structure in great detail port to starboard, providing crucial insights for successful fishing trips. The TZT22X and TZT24X have full control across the NavNet network, and you can tailor the system with a wide array of high-powered Fish Finders for deep dropping.Normal down-sounding Fish Finders have a beam angle of 40? or less. But with the DFF3D Multibeam Sonar, you'll see a 120-degree swath, offering seafloor coverage up to 3X water depth. Plus, with the power of the DFF3D, you can see fish directly below the boat 300m (nearly 1,000ft). The DFF3D's versatile operating modes give you a better understanding of fish targets than any normal Fish Finder can deliver. The 3D sounder history provides an intuitive and easy-to-understand 3D image of the seafloor, along with fish school icons - useful when selecting a fishing hot spot or assessing the seabed condition. Triple-Beam mode tells you not only the depth but also the direction (port/down/starboard) of fish targets. Cross Section display the real-time sea column echo in a 120? swath, and Side-Scan displays the shape and structure of targets both port and starboard.Looking for an added element of control? The vertically-oriented MCU006 and horizontal MCU006H are capable of controlling any TZtouchXL MFD in the network. Both feature a comfortable RotoKeyTM and ten dedicated dual-purpose buttons that operate different functions, including the ability to access the Edge Swiping functionality that makes the NavNet TZtouch series so easy to use.What's in the Box: TZTBBX - TZT XL Black Box Unit FUSE 5A 512G TZ Maps Chart Card Screw x 4 2m Power Cable 5m Network Cable Installation Manual Operator's Guide

Read more less

NavNet TZtouchXL Black Box ChartplotterPowerful TechnologyExplore the future of navigation with the Black Box NavNet TZtouchXL TZTBBX and enhance the functionality and style of your helm. NavNet TZtouchXL delivers the ability to tailor the helm to meet the captain's exact needs, with magnetron or Solid-State Doppler Radars, high-powered Fish Finders, AIS, Autopilot, and Deep Water Multibeam Sonar options, and more!NavNet TZtouchXL delivers features like TZ MAPS with BathyVision, the most advanced and capable electronic charts in the world. The TZ Maps engine draws upon a worldwide database of high-resolution information to create crisp, clear navigation with a variety of color themes and fishing charts with fully editable color palettes. TZ Maps delivers a timeless navigation experience at any magnification. It sounds incredible, and it is - you have to see it to believe it!Effortless ControlYou asked for the simplest interface possible, and we were listening. We’ve delivered the most intuitive UI available, bar-none, and you’ll be navigating with all the power and simplicity you demand. If you swipe your phone, you can operate TZtouchXL. With edge-swipe features and single-tap menu options, you’re never more than a tap or swipe away from what you want to see or do because NavNet TZouchXL provides the easiest and most powerful MFD on the planet.See more with TZ MAPSWith TZ MAPS, navigators control what map data they want to download, such as incredibly wide chart areas, satellite photos, and bathymetric data. Purchase incredibly wide chart areas directly from the MFD! Custom depth color shading and bathymetric data overlays create navigational charts of unmatched detail and clarity, rendered with a variety of color themes to provide an electronic charting experience that goes far beyond any premium chart service before it. You can create your custom objects or make updates to charted objects, such as buoys, so when they move from their previously charted positions, they can be updated on the system on the fly. Custom user objects can be shared with other registered TZ MAPS users through TimeZero's moderated service, and can be turned on and off in the Layers menu, available with a single edge swipe up from the bottom of the display. Purchase of any TZ MAPS area also unlocks added functionality, such as powerful AI Routing that intelligently plans out routes, taking into consideration the boat's draft as well as charted depths and navigational obstacles. The purchase of any TZ MAPS chart unlocks those charts in the free TZ iBoat app for mobile devices such as a phone or tablet, providing you with a free home planning app that will transfer your points and routes directly to the TZtouchXL. With a free TimeZero account, waypoints and routes can be easily backed up or retrieved from the cloud with just a few taps, ensuring all the data you’ve worked so hard to create remains safe and secure.Experience 'off-the-charts' bathymetric data with BathyVisionBathyVision for TZ MAPS provides truly ‘off the charts’ bathymetric data with contour lines that can be configured with a single tap. When we say configurable, we’re talking down to a resolution of a mere 3 inches between contours - that's 3x better than any other bathymetric chart currently on the market. Bathymetric data is rendered from the same high-resolution database used for TZ MAPS’ custom depth shading and can be overlaid onto the navigation charts to create fishing charts unlike any seen before.The Benchmark for RadarHowever you spend your time on the water, you need a Radar you can rely on to keep you safe. Whether you choose the time-tested X-Class magnetron option or NXT Solid-State Doppler models, Furuno Radar delivers power and clarity like you’ve never seen and provides the assurance that you’re navigating with the most reliable and feature-packed equipment on the planet. From the compact DRS2DNXT/DRS4DNXT domes to the high-power 200-watt DRS25ANXT open array, you’ll quickly become accustomed to the dynamic features that only Furuno provides, like Target Analyzer™ that alert you to potentially hazardous targets, Fast Target Tracking that displays a speed and course vector in seconds, best-in-the-business Bird Mode to track elusive flocks and even individual birds feeding on baitfish, and Rain Mode that can pick out and display in different colors the targets you need to see through even the nastiest of squalls. Plus, TZtouchXL introduces Radar features, like Risk Visualizer™ and AI Avoidance Route™, that help keep you safe on the water.Risk Visualizer™ and AI Avoidance Route™Risk Visualizer™ is a unique function of Furuno Radars that provides a visual representation of potential collision risks of approaching objects around the vessel. Unlike CPA/TCPA alarms which indicate only the risks visible on the ship’s current course, Risk Visualizer™ assesses all objects 360° around the vessel. Dynamic icons are automatically created for targets with the highest collision probability, ensuring the captain has the information needed to maintain safe distances when passing.The AI Avoidance Route™ feature available with TZ MAPS takes all the information provided by the Radar and instantly determines and provides a safe route around those hazards. Never lose waypoints, routes, or settings again with TZ CloudCreate your routes at home using TZ Navigator, a web browser*, or the TZ iBoat iOS App, then download them to your TZtouchXL MFD from the cloud. You can also backup all of the events on your MFD and retrieve them at home, because your data is synchronized automatically & securely. TZ Cloud saves all of your marks, routes, boundaries, photos, and catch data - with a free TimeZero account, all of your data can be backed up or retrieved with just a few taps. The purchase of any TZ MAPS chart directly from the MFD also unlocks those charts in the free TZ iBoat app for mobile devices such as a phone or tablet and TZ Pro navigation software, providing the only home planning solution you'll ever need. Built-In CHIRP Side-ScanFuruno’s CHIRP Side-Scan for NavNet TZtouchXL scans both port and starboard, illuminating the shape of the bottom structure in high definition. CHIRP Side-Scan reveals the shape of fish targets and fish-hoarding structure on each side of your vessel. CHIRP from 230kHz or 445kHz center frequencies with thru-hull, paired, or transom mount transducer options. CHIRP Side-Scan is built into the TZT10X/13X/16X and can be accessed by any TZtouchXL MFD on the network.A Dream Machine for Fishing FanaticsWe've raised the bar for sportfishing enthusiasts once again with an MFD series designed to cater to the needs of avid anglers. The NavNet TZtouchXL series includes all the features fishermen desire, including exclusive, never-before-seen features in recreational navigation devices. The TZT10X, TZT13X, and TZT16X feature a built-in 1kW TruEcho™ CHIRP or CW Fish Finder as well as built-in 230kHz or 455kHz CHIRP Side-Scan to show fish and fish-hoarding structure in great detail port to starboard, providing crucial insights for successful fishing trips. The TZT22X and TZT24X have full control across the NavNet network, and you can tailor the system with a wide array of high-powered Fish Finders for deep dropping.Deep Water Multibeam SonarNormal down-sounding Fish Finders have a beam angle of 40Ëš or less. But with the DFF3D Multibeam Sonar, you'll see a 120-degree swath, offering seafloor coverage up to 3X water depth. Plus, with the power of the DFF3D, you can see fish directly below the boat 300m (nearly 1,000ft). The DFF3D's versatile operating modes give you a better understanding of fish targets than any normal Fish Finder can deliver. The 3D sounder history provides an intuitive and easy-to-understand 3D image of the seafloor, along with fish school icons - useful when selecting a fishing hot spot or assessing the seabed condition. Triple-Beam mode tells you not only the depth but also the direction (port/down/starboard) of fish targets. Cross Section displays the real-time sea column echo in a 120Ëš swath, and Side-Scan displays the shape and structure of targets both port and starboard. Total ControlLooking for an added element of control? The vertically-oriented MCU006 and horizontal MCU006H are capable of controlling any TZtouchXL MFD in the network. Both feature a comfortable RotoKey™ and ten dedicated dual-purpose buttons that operate different functions, including the ability to access the Edge Swiping functionality that makes the NavNet TZtouch series so easy to use.Specifications: Chart Type: 3D Data or C-Map or Raster or Vector or TZ MAPS Display Size: Supplied Separately Display Type: Supplied Separately Power Usage: 12-24 VDC This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Read more less

Furuno FA170 Class A AIS Model: FA170 Class A AIS Transponder w, 4.3 Color LCD Display

Read more less

Class A AIS TransponderFuruno's FA170 is a Class A AIS Transponder with a 4.3" Color LCD Display. It displays symbols for AIS-equipped vessels, AIS-SARTs, coastal stations, and other aids to navigation within the VHF range. AIS data can be output to ECDIS, Radar, or other navigational equipment for collision avoidance support.The FA170 includes 6 in/out ports, 3 input-only ports, one LAN port, and one alarm output (contact closure) port. The unit is BAM (Bridge Alert Management) ready, meeting the specific requirements for BAM as specified in IMO MSC.302 (87). An optional Pilot Plug is available.This compact unit can store up to 2,048 AIS targets and AIS sarts. Selecting a target from the list generates a pop-up window where detailed information is displayed. You can also create an AIS message or send a name request to the target ship.When dangerous targets are detected, the FA170 provides a Dangerous Target list. The FA170 is also capable of exchanging short, safety-related messages with a specified MMSI or all AIS-equipped vessels via VHF channels. The FA170 can store up to 20 transmitters and 20 received messages.Features: Class A AIS Transponder with 4.3" Color LCD Display Displays Information about AIS-equipped ships, as well as coastal stations and Aids to Navigation within VHF coverage Outputs AIS data to ECDIS, Radar, and other navigational equipment Sufficient output ports for dual configuration of ECDIS and Radar Systems LAN Interface available for simple and efficient network integration BAM (Bridge Alert Management) is ready Optional available Pilot Plug Receives AIS-SART signals for assisting in streamlining SAR activities This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: AIS Class: A GPS Included: Yes Function: Receive/Transmit Display Included: Yes Antenna Included: Yes Box Dimensions: 13"H x 14"W x 19"L WT: 18.5 lbs UPC: 611679364449 Owner's Manual (pdf)Brochure (pdf)

Read more less

Furuno 12.1 Portrait-Style Radar

Read more less

FR-12 Color LCD Marine Radar Display - 12"The FR-12 12.1" Color LCD Radars are Marine Radar displays consisting of a dedicated vertical display unit that can be freely combined with Furuno’s extensive DRS Series Antennas to meet a wide variety of detection needs. These Radars feature the latest technologies including Risk Visualizer™, a new function that provides visual information on potential collision areas and movement of all surrounding vessels, as well as Echo Average, Target Analyzer™, Fast Target Tracking™, RezBoost™, and many other great functions to help you keep track of any target for your navigation and operations such as Custom AIS, User-Programmable function keys and Multi-language support.Compatible with Furuno’s powerful antenna line-upThe FR-12 is compatible with any of the DRS Series Antennas, allowing for a variety of configurations. By selecting the detection range (power output), screen size, and antenna type and size based on what you want to accomplish, you can build the Radar that best meets your needs. Compatible DRS antennas:Radome type: Model DRS2D-NXT Model DRS4D-NXT Model DRS4DL+Open Array type: Model DRS6A-NXT Model DRS12A-NXT Model DRS25A-NXT Model DRS6A X-Class Model DRS12A X-Class Model DRS25A X-Class Risk Visualizer™ Risk Visualizer™ is a technology that shows potential collision areas based on the current position and movement of all surrounding vessels. Thanks to the on-screen display, it is easy to get a quick and intuitive overview of the situation around your ship. Additionally, color-coded alerts according to the threat of a collision, from green (normal) to red (hazardous), will help you assess the level of danger and plan your next move. This is our first commercial mid-range Radar to incorporate this feature, which contributes to the continuous improvement of safety at sea.Fast Target Tracking™Fast Target Tracking™ is a technology that instantaneously displays a vector indicating the speed and heading of the target. The targets are automatically tracked from the beginning, making it possible to immediately calculate the target's trajectory and display the velocity vector. Target Analyzer™Target Analyzer™ is a technology that analyzes targets and identifies the dangerous ones that are likely to collide with your ship, using different colors according to the degree of danger. The display of potentially dangerous targets in different colors allows an operator to understand threats to safe navigation at a glance.Echo AverageEcho Average is a feature that attenuates irregular echoes, such as reflections from the sea surface and precipitation, and stabilizes echoes from fishing gear and other vessels. It makes it easier to see what you want to see, even in poor weather conditions such as high waves, precipitation, or dense fog.Radar overlay on charts/Share points and linesThe FR-12 can show Radar echoes overlaid on MapMedia MM3D charts. Additionally, when connected to the GP-3700/F* via Ethernet, marks, and lines can be displayed.Specifications: Peak Output Power: Depending on the selected Antenna Unit (See DRS Antennas) Type: Compatible Antenna Unit: DRS4DL+, DRS2D/4D/6A/12A/25A-NXT, DRS6A/12A/25A X-Class Range Scales: 0.0625 to 36 NM (DRS4DL+), 0.0625 to 48 NM (DRS2D/4D-NXT), 0.0625 to 72 NM (DRS6A-NXT), 0.0625 to 96 NM (DRS6A/12A/25A X-Class, DRS12A/25A-NXT) Display Unit:  12.1-inch color LCD Display Mode: Head-up, Course-up, North-up, True motion, Stern-up Other Mode/Functions: Risk Visualizer™, Target Analyzer™, Target Tracking™, True Echo Trail, Echo Average, Sub Display Unit, AIS Display, Radar overlay on charts Power Supply/Consumption Current: FR-12: 12-24 VDC: 1.7-0.9 A This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Brochure (pdf)

Read more less

NavNet TZtouch3 16" MFD with 1kW Dual Channel CHIRP™ Sounder & Internal GPS Go on a power trip with Furuno! Furuno listened to you and worked tirelessly to make NavNet TZtouch3 the easiest MFD on the market to use, with all of the power you’ve wanted and more. These 12-inch, 16-inch, and 19-inch MFDs feature a quad-core processor for lightning-fast response, a built-in GPS receiver (TZT12F & TZT16F only), and an internal 1kW TruEcho CHIRP™ Fish Finder, making them ready  for action right out of the box. For those looking for even more power, simply add the all-new 2/3kW Deep Impact TruEcho CHIRP™ Amplifier or the power-packed 100W/200W NXT Solid-State Doppler Radars. Use the PIN Code Lock feature to secure your NavNet TZtouch3 data by requiring a four-digit password to be entered at startup.Features: Built-in Dual Channel 1kW TruEcho CHIRP™ Built-in GPS Receiver 16” multi-touch IPS displays DI-FFAMP – optional high-power TruEcho CHIRP™ Fish Finder Amplifier, designed to work exclusively with NavNet TZtouch3. This 2kW or 3kW TruEcho CHIRP™ Fish Finder amp gets you down to the deepest waters to find your catch. You can even connect a 5kW or 10kW transducer! (BT-5 required) High-power 100W or 200W Solid-State Doppler Radar options, with Target Analyzer™, Fast Target Tracking™, Bird Mode and Rain Mode Quad-screen display configuration allows for presentation of 1, 2, 3, or 4 different functions IPS LCD provides superior viewability from virtually any angle Compatible with NavNet TZtouch2 Networks Create your routes at home, using TZ Navigator, a web browser*, or TZ iBoat iOS App. Then you can sync  your data from the cloud to your TZtouch3 system. (*Cloud.MyTimezero.com raster planning charts for US only) TZ First Mate App keeps track of your catch & location  Synchronize data with a tablet or smartphone Add Autopilot, Instruments, Radar, AIS, Multi-Beam Sonar, and a variety of other sensors to your NavNet TZtouch3 network Full Autopilot control from MFD, when connected to the NAVpilot-300/711C Compatible with CZone digital switching Free weather data, using NavCenter Weather or optionally connect BBWX4 SiriusXM Weather Receiver This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Cartography Brand: Furuno Transducer Included: No Touchscreen: Yes Screen Size: 16" Box Dimensions: 11"H x 15"W x 21"L WT: 23 lbs UPC: 611679389190 Brochure (pdf)

Read more less

Furuno TZT16F 16 TZtouch3 Chart Plotter/Fish FinderModel: TZT16F Go on a power trip with the most powerful MFD series available EASY to use; because finding your happy place shouldn't be difficult! The return of Hybrid Control Protect your livelihood with new PIN CODE security Never lose waypoints

Read more less

Furuno TZT13X NavNet TZtouch3 Chart Plotter, 13 All-Glass IPS Display FULL HD (1920x1080)Model: TZT13X New TZ MAPS for highly-detailed navigation and fishing charts Built-in Dual Channel 1kW TruEcho CHIRPTM & CW Fish Finder Built-in 230kHz or 455kHz CHIRP Side-Scan Powerful hexacore processor for rapid response Explore the future of navigation with NavNet TZtouchXL - extra-large

Read more less

TZT13X 13" Hybrid Touch Multi-Function DisplayThe hybrid control 13” TZT13X incorporates all of NavNet TZtouchXL's multi-touch capabilities with Furuno’s RotoKey™ control knob and dedicated buttons, making navigation intuitive and easy under any sea conditions.The TZT13X incorporates a powerful internal 1kW dual channel TruEcho CHIRP™ Fish Finder* designed to operate across a wide range of frequencies. For those who want to go even deeper, the 2kW/3kW DFF3-UHD TruEcho CHIRP™ Network Fish Finder delivers the ability to penetrate the deepest waters to find a catch. Also, with the BT-5 Booster Box, users can boost that output power up to 5 or 10 kW to take advantage of high-power transducer options that will unveil the deepest waters like users never experienced before.Features: 13 in. display with hybrid controls TZ MAPS for highly detailed navigation and fishing charts Purchase and update charts directly from MFD with an internet connection Powerful hexacore processor for rapid response Video converter kits stream compatible sonar video data directly to TZtouchXL MFD Furuno’s exclusive Fish-It, Drift-It, & Follow-It features save time and fuel and increase fish catch Built-in Dual Channel 1kW TruEcho CHIRP™ & CW Fish Finder Built-in 235kHz or 455kHz CHIRP Side-Scan Built-In CHIRP Side-ScanFuruno’s CHIRP Side-Scan for NavNet TZT13X scans both port and starboard, illuminating the shape of the bottom structure in high definition. CHIRP Side-Scan 6 reveals the shape of fish targets and fish-hoarding structure on each side of the vessel. CHIRP from 235kHz or 445kHz center frequencies with thru-hull, paired, or transom mount transducer options.TZ MAPSOne of the most exciting TZtouchXL features is a chart offering called TZ MAPS. Not only are these some of the most detailed charts in the industry, but TZ MAPS users are in complete control of the chart content they want to download, such as raster or vector charts, satellite photos, and bathymetric data. Custom user objects can be shared with other registered TZ MAPS users through TimeZero's moderated service. Since custom objects reside on their chart layer on the TZtouchXL MFD, they can easily be displayed or hidden as desired. Additionally, for the first time, customers can purchase and update charts directly on their TZtouchXL MFD!BathyVisionOne of the most groundbreaking aspects of TZ MAPS is called BathyVision, providing amazingly detailed bathymetric data that can be configured to an incredible resolution of a mere 3 inches between contours! That's 3 times better than any other bathymetric chart currently on the market. BathyVision data, along with custom depth shading, can easily be overlaid on TZ MAPS navigation charts to create the ultimate "Fishing Charts"!AI RoutingTZ MAPS unlocks the ability to utilize the powerful AI Routing function that intelligently plans out routes, taking into consideration the boat's draft and navigational obstacles. AI Routing takes traditional auto-routing to another level by automatically creating suggested routes based on varying navigational conditions.Risk Visualizer & AI Avoidance RouteWhen connected to an NXT radar, two powerful safety features are unlocked: the Risk Visualizer and the AI Avoidance Route tool. Risk Visualizer provides a 360° visual representation of the potential collision risks of approaching objects around the vessel. Dynamic icons are automatically created for targets with the highest probability of collision, ensuring the captain has the necessary information to maintain safe distances when passing. The AI Avoidance Route function processes all available information provided to dynamically provide a safe route around those hazards, which can be sent to a Furuno NavPilot autopilot with a single tap.Enhanced User Interface for Ease of Use & CustomizabilityIn addition to offering all the great features that make NavNet super simple to operate, NavNet TZtouchXL MFDs also deliver BIG power and versatility! Users can now configure their MFD in many ways, thanks to an increased number of Page Builder configurations from four (4) to ten (10) custom combinations. Additionally, users can now custom-build a 6-way screen split of various components and sensors.Match all those great screen layout options with enhanced Edge-Swipe feature access for the smoothest, easiest, and very best user experience Furuno has ever delivered! This is all driven by the most system memory and the highest level of processing power Furuno has ever integrated into a NavNet MFD. Specifications:Display Unit: Type: Color TFT multi-touch IPS LCD Screen Size: 13.3" Wide Screen Resolution: FHD 1920 x 1080 Screen Brightness: 900 cd/m2 (typical) Display Colors: 16,770,000 colors (Chart Plotter), 64 colors (Radar/Fish Finder) Language: Bulgarian, Chinese, Danish, English (USA/UK), Finnish, French, German, Greek, Italian, Japanese, Norwegian, Portuguese, Russian, Spanish, Swedish, Turkish, Polish GPS/WAAS: Receiver Type: GPS: 72 channels, SBAS: 1 channel (C/A mode, WAAS) Receiving Frequency: L1 (1575.42 MHz) Time to First Fix: 100 s (cold start) Accuracy: 10 m (GPS), 7 m (MSAS), 3 m (WAAS) Position Update Interval: 100 ms or 10 Hz Chartplotter: Cartography: TZ MAPS, MM3 Vector, and CMOR capable (U.S. only) Memory Capacity: 30,000 user points, 100,000 points for ship's tracks, 200 planned routes (500 points per route) Alarms: Anchor Watch, XTE, Depth*, Speed, Sea Surface Temperature*, Trip Distance, Fuel Gauge* (*external data required) Radar: Display Modes: Head-up, North-up*   *Heading input required.  Echo Trails: Interval: 15 s, 30 s, 1 min, 3 mins, 6 mins, 15 mins, 30 mins, and continuous (Heading input required)  Target Tracking: 100 ARPA Targets (Radar dependent) with fully automatic target acquisition (Heading input required)  Radar Alarms: Guard Zone, CPA/TCPA, Video, Azimuth, Heading Line Fishfinder: Transmit Frequency*: CW: 50/200 kHz, CHIRP: 40 kHz to 240 kHz (Low, Medium, and High) Transducer: 300/600 W or 1 kW*   *Matching box MB1100 required for some transducers Display Range: 2 to 1,200 m; shift 0 to 1,200 m (1,200-2,400m / 4,000-8,000ft)  Extension Mode: ACCU-FISH™, A-Scope, Auto (Fishing/Cruising), Bottom Discrimination, TruEcho CHIRP™ (with compatible transducer)  Picture Advance: 8 steps: x4, x2, x1, 1/2, 1/4, 1/8, 1/16, stop  Fish Finder Alarms: Fish School, Fish School for the bottom lock Side-Scan:  Transmit Frequency*: CHIRP: 220-240KHz/445-465KHz Transducer: 225kHz: 225T-PR904, 225T-SS904. 225T-TM904 / 455kHz: 455T-PR903, 455T-SS903. 455T-TM903  Display Range: 750 feet to each side  Display Colors: Green, Blue, Amber, White  Display Screen Sizes: Full Screen, 1/2 Screen, 1/4 Screen, 1/6 Screen Full Screen, 1/2 Screen, 1/4 Screen, 1/6 Screen  Direct Connect to MFD: Direct connect to TZ10X, TZT13X, TZT16X only; may be networked with TZT22X/TZT24X Interface: NMEA200: 1 Port Input: 065280, 126992/993/996, 127237/245/250/251/257/488/489/505, 128259/267, 129025/026/029/330/038/039/040/041/291/538/540, 129793/794/798/801/802/808/809/810, 130306/310/311/312/313/314/316/576/577/578, 130817/818/820/822/823/826/827/828/880 Output: 126992/993/996, 127250/251/257/258, 128259/267/275, 129025/026/029/033/283/284/285, 130306/310/311/312/313/314/316 NMEA0183: 1 Serial Output Port Output: AAM, APB, BOD, DBT, DPT, GGA, GLL, GNS, GSA, GSV, RMB, RMC, RTE, TTM, VDM, VTG, WPL, XTE, ZDA LAN: 1 Port (1000 BASE-T) USB: 1 Port (USB 3.0) for control unit Video I/O: Input: 1 port (NTSC/PAL) AUX I/O: 2 Ports (Event Switch and External Power Switch) SD Card Slot: 1 Slot (Micro SDXC, rear) Wireless LAN: IEEE802.11b/g/n, Transmit frequency: 2.412 to 2,462 GHz, 11dBm max Transducer Connection: 1 Port 12 pin for CHIRP/CW, 1 Port 12 pin for Side-Scan Environment: Temperature (IEC60945)-15°C to +55° C Relative Humidity: 93% or less at +40° C Waterproofing: IP56 Power:12-24 VDCThis product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Screen Size: 13" Touchscreen: Yes Box Dimensions: 15"H x 15"W x 21"L WT: 19.6 lbs UPC: 611679404251 Brochure (pdf)

Read more less

Furuno 165T/275LHW-12P Pocket Mount Combo Wide Beam Transducer for DFF3D with 12-Pin ConnectorModel: 165T/275LHW-12P DFF3D operating frequency 165 kHz Low-CHIRPS from 42 kHz to 65 kHz, Beamwidth 25 deg to 16 deg High-CHIRPS from 150 kHz to 250 kHz, Beamwidth 25 deg 12M Cables. Pigtail cable for DFF1-UHD, 7 pin connector and 12 pin connector for DFF3D Recommended for a DFF1-UHD and DFF3D installation Built-in motion sensor Built in temp sensor This is a new size housing (12 LX 5 W X 3.5 H) that contains DFF3D elements along with CHIRP elements.

Read more less

Furuno 165T/275LHW Pocket Mount Combo Wide Beam Transducer for DFF3DModel: 165T/275LHW DFF3D operating frequency 165 kHz Low-CHIRPS from 42 kHz to 65 kHz, Beamwidth 25 deg to 16 deg High-CHIRPS from 150 kHz to 250 kHz, Beamwidth 25 deg 12M Cables. Pigtail cable for DFF1-UHD, 7 pin connector and a pigtail cable for the DFF3D Recommended for a DFF1-UHD and DFF3D installation Built-in motion sensor Built in temp sensor This is a new size housing (12 LX 5 W X 3.5 H) that contains DFF3D elements along with CHIRP elements.
