DC Voltage (V)| 600.0mV, 6000mV/6.000V, 60.00V, 600.0V |
| AC Voltage (V) |
600.0mV, 6000mV/6.000V, 60.00V, 600.0V |
| DC Current (A) |
600.0uA, 6000uA, 60.00mA, 600.0mA, 6.000A, 10.00A |
| AC Current (A) |
600.0uA, 6000uA, 60.00mA, 600.0mA, 6.000A, 10.00A |
| Resistance |
600.0, 6000/6.000k, 60.00k, 600.0k, 60.00M |
| Capacitance (F) |
9.999nF, 99.99nF, 999.9nF, 9.999uF, 99.99uF, 999.9uF, 9.999mF |
| Frequency (Hz) |
10.00Hz-1.000MHz |
| Temperature ( degF) |
-40 degF to 1832 degF |
| Temperature ( degC) |
-40 degC to 1000 degC |
| Overload Protection |
600V rms |
| CAT Rating |
CAT 111 600V |
