Nominal Voltage| 12V DC |
| Amperage Operating Current |
175mA (closed)
4mA (open) |
| Terminal Stud Torque |
140 in-lb (15.82 Nm) |
| Continuous Rating |
120A |
| Intermittent Rating |
210A (5 Min) |
| Cable Size to Meet Ratings |
1 AWG (50mm2) |
| Charge Sense Connect |
13.0V (3 sec) |
| Charge Sense Disconnect |
12.75V (10 sec) |
| Disconnect Time |
5 sec, 15 min, 30 min, 1 hr, 1.5 hr, 2hr, or 4hr |
| Input Voltage Range |
9.5-16V |
| Low Voltage Disconnect |
11.0V (10 sec)
11.5V (10 sec)
12.0V (10 sec) |
| Maximum Cable Size |
1/0 AWG (50mm2) |
| Stud Material |
Tinned Copper |
| Terminal Ring Diameter Clearance |
1.12in (28.45 mm) |
| Terminal Stud Size |
3/8-16 (M10) |
| Over Voltage Lockout |
16.0V (5 sec) |
