| Total Output Current |
40A |
| Input AC Current |
7.5A @ 100V A
|
| Maximum Output Voltage |
16V DC |
| Nominal Voltage |
12V DC |
| Ignition Protected |
Yes |
| Number of Outputs |
1 negative
3 positive |
| Stud Size |
M6 |
| Universal AC Input Voltage |
115-230V AC |
| AC Input Frequency |
45-65Hz |
| Output Voltage Accuracy |
0.05V |
| Typical Float Voltage |
13.5V DC |
| Maximum Operating Temperature |
70° C |
| Minimum Storage Temperature |
-30° C |
| Maximum Storage Temperature |
80° C |
| Battery Types |
AGM
Flooded Lead Acid
Gel
TPPL |
| Recommended for Battery Bank Sizes |
330Ah Maximum
60Ah Minimum |
| Screw Terminal Torque |
10 in-lb (1.13 Nm) M3
15 in-lb (1.69 Nm) M4 |
| Stud Torque |
80 in-lb (9.04 Nm) |
| Dimension H x W x D |
13.03in x 8.46in x 3.66in |
| Warranty |
5 Year |
