Description
FLIR Ocean Pro Marine Thermal Monocular
Model: 15002-0202
- Up to 500 m visibility, even in the dark
- Wide 32° field of view for maximum coverage and faster area sweeps
- Rugged and reliable with IP67 rating and 2 m drop protection
- Easy-to-use menu, requiring minimal training
- Wireless video streaming through Scout Pro App (iOS only)
- Navigate at night with confidence
- Avoid obstacles, floating debris and navigate safer
- Locate navigation aids
- Find people or pets in the water
FLIR Ocean Scout Pro provides exceptional imagery by day or night using a high-resolution 640 x 480 thermal sensor with a fast 30 Hz refresh rate and high-resolution viewfinder. Combined, these features give Ocean Scout Pro outstanding long-range performance with the ability to detect a human-sized target at 500-meters. A wide 32° field of view enables rapid area scanning, locating people in the water, or spotting navigation aids and hazards.
The Ocean Scout Pro includes a tactical storage pouch compatible with MOLLE webbing, USB-C charge/interface cable, wrist lanyard, two rubber eyecups, and a quick start guide. An internal lithium-ion battery provides up to 6 hours of runtime. The USB-C cable provides charging and enables file transfer to a connected PC.
Specifications
| General |
| Field of View (FOV) |
32° |
| Focal length |
19 mm |
| F-number |
f/ 1.0 |
| Focus |
Fixed focus |
| Human detection range |
500 m (540 yards) |
| Minimum focus distance |
4 m (13 ft) |
| Detector frame rate |
30 Hz |
| Display frame rate |
60 Hz |
| Thermal sensitivity, NETD |
Less than 38 mK @ 30°C (86°F) |
| Detector Resolution |
640 480, vox microbolometer |
| Image processing |
FLIR proprietary Digital Detail Enhancement™ |
| Color (housing) |
Silver |
| Drop rating |
2 m (6 ft 7 in) |
| IP rating |
IP67 |
| User interface |
| Zoom |
2x, 4x, 6x, 8x |
| Modes |
White Hot, Black Hot, Sepia, and Heat |
| Disable radio and Wi-Fi |
Physical On/Off switch |
| Image presentation |
| Built-in display |
XGA 1024 768 |
| Video |
XGA 1024 768 |
| Power |
| Batttery life |
Up to 6 hours |
| Battery type |
Internal Li-Ion cell |
| Charging time |
2 h at 80% |
| Physical |
| Size (L x W x H) |
19.2 cm 6.4 cm 6.4 cm (7.5 in 2.5 in 2.5 in) |
| Weight (incl. battery) |
498 g (1 lb 2 oz) |
| Tripod mounting |
UNC 1/4-20 |
| Image storage |
| Media gallery |
Scout Pro App (iOS only) |
| Storage media |
Embedded flash |
| Image storage capacity |
Greater than 1000 |
| Image storage mode |
IR |
| File formats |
Standard JPEG |
| Video recording |
Yes |
| Non-radiometric IR video recording |
MPEG4 AVC (ITU-T H.264) |
| Storage capacity |
16 GB |
| Video streaming |
Yes |
| Non-radiometric IR video streaming |
Wi-Fi/RTSP (MPEG4 AVC (ITU-T H.264)) |
| USB streaming |
UVC (YUV422 no overlay) |
| Wireless connectivity |
| Bluetooth |
BLE |
| Streaming |
Wi-Fi |
| Warranty and service |
| Warranty |
support.flir.com/oceanscout-pro |
