| Detector Type |
640 x 512 |
| Internal Memory |
2 GB Internal Storage / Optional microSD™ Card (up to 128 GB) |
| Size |
227 76.8 60.5 mm (9 3 2.4 in) |
| Weight |
Without Batteries: 452 g; With Batteries 572 g |
| SYSTEM OVERVIEW |
| Eye Relief |
16 mm |
| Color (housing) |
Gray / Black |
| Lens System |
18 mm |
| Optical Magnification |
1x |
| Display Focus |
Manual |
| Core Technology |
BOSON 12 µm Vox Microbolometer |
| CONNECTIONS & COMMUNICATIONS |
| Bluetooth |
BLE 4.1+ |
| USB |
USB-C; Power In; Video Out; Video and Image File Transfer |
| Geo Positioning [GPS] |
Yes |
| Wifi |
Video Streaming, File Transfer |
| ENVIRONMENTAL |
| Mounting |
¼-20 Tripod Mount |
| IMAGING & OPTICAL |
| Digital Zoom |
1X , 2X , 4X,8x |
| Field of View |
24° 18° |
| Refresh Rate |
9 Hz |
| Detection Range Performance [1.8 m man] |
710 M |
| METER DATA |
| Auto Power Off |
Yes |
| Display |
Quad-VGA (1280x960) High definition display |
| POWER |
| Battery Life |
Up to 4.5 hours at 20°C |
| Battery Type |
6x CR123A 3V Lithium Battery |
| UI-UX |
| Temperature Imaging Modes |
White Hot; Black Hot; Iron Bow; Rainbow; Graded Fire; Lava |
| Viewing Modes |
Scouting, Picture-in-Picture |
| Picture While Recording |
Yes |
| Real Time Clock |
Yes |
| DateTime Stamp |
Yes |
| Magnetic Compass |
Yes |
| Accelerometer |
Yes |
