Acoustic Window| Urethane |
| Hull Deadrise |
Up to 22 deg |
| Data Update Rate |
Depth 1X/second |
| Data Update Rate |
Speed 5X/second |
| Attitude Accuracy |
+/- 1 deg nominal after sensor calibration |
| Depth Frequency |
235 kHz |
| Minimum Depth Range |
0.5 m (1.6 feet) |
| Maximum Depth Range |
Up to 100 m (330 feet)-NMEA 2000(R) |
| Speed Range |
Up to 45 knots |
| Pressure Rating |
3 m (10 feet) |
| Pulse Rate |
20,000 p/nm* (5.6 Hz per knot)-*p/nm = pulses per nautical mile |
| Supply Voltage |
9 VDC to 16 VDC-per NMEA 2000 |
| Supply Current |
<200 mA-per NMEA 2000(R) |
| Wireless Protocol |
Bluetooth Low Energy (BLE) |
| Wireless Range |
Up to 30 feet depending on mount location |
| Standard Cable Length |
6 m (20 feet) DeviceNet-NMEA 2000(R) |
| Temperature Sensor Accuracy |
+/-0.5 degC (+/-1.8 degF) |
| Temperature Sensor Range |
-10 degC to 40 degC (14 degF to 104 degF) |
| NMEA 2000 Load Equivalency Number (LEN) |
3 |
