Frequency| Ultra High-Definition ClearVü: 0.8 MHz (800 kHz), CHIRP range: 760-880 kHz
Ultra High-Definition SideVü: 1.2 MHz (1,200 kHz), CHIRP range: 1,060-1,170 kHz |
| Power |
500 W |
| Beamwidth |
Ultra High-Defintion ClearVü: 0.74 deg x 46 deg
Ultra High-Defintion SideVü: 0.44 deg x 55 deg |
| Maximum depth |
200 feet Ultra High-Definition ClearVü
125 feet to each side Ultra High-Definition SideVü, 250 feet total, at a maximum depth of 30 feet |
| Depth/Speed/Temperature |
Depth and Temperature |
| Number of pins |
12-pin |
| Cable length |
20 ft. |
| Supported deadrise/Transom angles |
Up to 25 deg deadrise |
