Channels| 4 |
| Physical dimensions (Height) |
10.43in (265 mm) |
| Physical dimensions (Width) |
10.43in (265 mm) |
| Physical dimensions (Depth) |
4.90in (125 mm) |
| Operating voltage |
9-16 VDC |
| Water and dust rating |
IP67 |
| Operating temperature range |
4 deg to 149 deg F (-20 deg to 65 deg C) |
| Warranty |
3 years |
| Audio |
| Amplifier class |
Class D |
| Rated continuous (RMS) power (14.4 V input @ 4 Ohm less than 1% THD) |
50 W x 4/150 W x 2 (Bridged) |
| Rated continuous (RMS) power (14.4 V input @ 2 Ohm less than 1% THD) |
75 W x 4 |
| Signal-to-Noise Ratio, referred to 1 W (A-weighted, 20 Hz - 20 kHz noise bandwidth): Analog Inputs |
Greater than 70 dB |
| Frequency response (+0, -1dB) |
20 Hz-20 kHz |
| Input sensitivity @ RCA inputs |
Switchable from 200 mV-2 V RMS (Low) to 800 mV-8 V RMS (High) |
| Current consumption (Standby) |
Less than 1mA |
| Current consumption (Idle) |
700-750mA |
| Fuse rating |
35A |
| Recommended fuse type(s) |
AFS, AGU or MaxiFuse |
| Min. copper power/Ground wire gauge |
4 AWG wire |
| Protection circuits |
Input under/over voltage
Over temperature
Output short circuit |
