Optimized for high-powered operation, M6 marine subwoofers can be installed in various applications and are built to withstand the rigors of marine use.
Size| 10 in |
| Color |
Black |
| Physical dimensions (Diameter) |
10.75in (273 mm) |
| Physical dimensions (Depth) |
7.53in (191 mm) |
| Weight |
13.2 lbs (6.0 kg) |
| Speaker type |
Infinite Baffle or Enclosed-use Subwoofer |
| Continuous power handling (RMS) |
250 W |
| Sensitivity (SPL @ 1 W/1 m) |
(IB): 86.1 dB, (W): 86.4 dB |
| Nominal impedance |
4 Ohms |
| Recommended amplifier power (RMS) |
75-250 W |
| Cone material |
Injection-molded, mica-filled polypropylene |
| Warranty |
3 years |
| Speaker connections |
Spade Connectors |
| Mounting Dimensions |
| Mounting diameter clearance |
6.98in (177 mm) |
| Frontal grille protrusion |
0.55in (14 mm) |
| Mounting hole |
10.5625in (268 mm) |
| Bolt hole circle |
11.46in (291 mm) |
| Driver displacement |
0.099 cu ft (2.80 L) |
| Free Air Resonance (FS)
Parameters |
(IB): 43.76 Hz, (W): 34.58 Hz |
| Electrical Q (Qes) |
(IB): 0.907, (W): 0.522 |
| Total Q (Qts) |
(IB): 0.840, (W): 0.496 |
| Equivalent Compliance (Vas) |
(IB): 0.98 cu ft (27.75 L), (W): 1.22 cu ft (34.49 L) |
| One-way linear excursion (Xmax; specs are derived via one-way voice coil overhang method with no correction factors applied) |
(IB/W): 0.52in (13 mm) |
| Reference Efficiency (NO) |
0.28% |
| Effective piston area (SD) |
(IB/W): 50.11 in sq (0.0323 m sq) |
| DC resistance (RE) |
(IB): 4.543 Ohms, (W): 3.619 Ohms |
