| Mechanical / Environmental |
| Casing |
ABS Plastic |
| Operating Temp |
-15°C to +55°C |
| water ingress |
IPx2 |
| Weight |
1060g |
| dimensions (overall) |
281mm (W) x 232mm (H) x 65.5mm (D) |
| Electrical |
| Operating voltage |
9 - 31.2 V DC |
| Power consumption |
45W (Max) |
| Low power standby mode |
yes |
| Protection |
reverse polarity and temporary over-voltage to 36V |
| Alarm output current |
capable of driving 10A relay coil |
| Processor |
iMX61 quad core |
| RAM |
DDR3 1GB |
| Storage |
8GB Flash |
| Conformity |
CE, C-Tick, HDMI |
| Interfaces |
| ethernet |
3 ports total - 1 & 2 are PoE (RJ45 socket) |
| NMEA 2000 |
1 port on rear (Micro-C male) |
| Video input |
2 ports on rear (BNC female. NTCS or PAL format) |
| Video output |
1024x768 (XGA 4:3), 1280x720 (HD 16:9), |
| USB |
mass storage, keyboard and mouse (Type A socket) |
| SD |
32GB (Full size SD card socket) |
| NMEA 0183 baud rate |
4800, 9600, 19200, & 38400 (via proprietary cable) |
| NMEA 0183 via RS232 |
1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200 |
| charting support |
Navionics, CMAP, Insight, NV Charts on SD |
