Airmar SS175C-0-L 0d TiltLow CHIRP With No ConnectorModel: SS175C-0-L Depth and fast-response water-temperature sensor 1 kW Low Frequency: 40 kHz to 60 kHz with maximum depth performance to 762 m (2500') = 32° to 21° beamwidth Great deep water performance High performance, low-profile thru-hull housing provides good resolution at speed when installed properly Stainless steel housing for use on stepped, planing or displacement hulls in fiberglass, wood or metal Recommended boat size: Up to 11 m (36') Also available in a bronze housing (B175L) model for use in fiberglass and wood hulls Exclusive Xducer ID® technology Airmar’s low profile Chirp-ready transducer models are the perfect addition to smaller boats such as center consoles. The low frequency band is the deep water performer delivering excellent coverage and tracking in deeper depths. The SS175L transducer delivers up to 20 kHz of total bandwidth in just one installation and delivers tremendous deep water performance.Tilted element transducers have the ceramic element fixed at either a 20°, 12° or 0° angle within the transducer housing. The transducer is installed almost flush to the hull and the tilted element corrects for the hull deadrise by orienting the beam directly down. This assures maximum echo returns to the transducer and more accurate depth readings.Specifications Weight 2.7 kg (6 lb) Hull Deadrise 0° to 7° hull deadrise Acoustic Window Urethane Hole Size 98 mm (3-7/8") Seven internal broadband ceramic assemblies

Read more less

Airmar SS175C-20-L 20d TiltLow CHIRP with with Si-Tex 8-PinModel: SS175C-20-L Depth and fast-response water-temperature sensor 1 kW Low Frequency: 40 kHz to 60 kHz with maximum depth performance to 762 m (2500') = 32° to 21° beamwidth Great deep water performance Stainless steel housing for use on stepped, planing or displacement hulls in fiberglass, wood or metal Recommended boat size: Up to 11 m (36') Also available in a bronze housing (B175L) model for use in fiberglass and wood hulls Exclusive Xducer ID® technology Airmar’s low profile Chirp-ready transducer models are the perfect addition to smaller boats such as center consoles. The low frequency band is the deep water performer delivering excellent coverage and tracking in deeper depths. The SS175L transducer delivers up to 20 kHz of total bandwidth in just one installation and delivers tremendous deep water performance.Because the transducer is installed almost flush to the hull, when the transducer is installed the tilt corrects for the hull deadrise and orients the ceramic element horizontally to assure maximum echo returns to the transducer.Specifications Weight 2.7 kg (6 lb) Hull Deadrise 16° to 24° hull deadrise Acoustic Window Urethane Hole Size 98 mm (3-7/8") Seven internal broadband ceramic assemblies

Read more less

Airmar SS175C-20-L 20d TiltLow CHIRP with Navico 9-PinModel: SS175C-20-L Depth and fast-response water-temperature sensor 1 kW Low Frequency: 40 kHz to 60 kHz with maximum depth performance to 762 m (2500') = 32° to 21° beamwidth Great deep water performance Stainless steel housing for use on stepped, planing or displacement hulls in fiberglass, wood or metal Recommended boat size: Up to 11 m (36') Also available in a bronze housing (B175L) model for use in fiberglass and wood hulls Exclusive Xducer ID® technology Airmar’s low profile Chirp-ready transducer models are the perfect addition to smaller boats such as center consoles. The low frequency band is the deep water performer delivering excellent coverage and tracking in deeper depths. The SS175L transducer delivers up to 20 kHz of total bandwidth in just one installation and delivers tremendous deep water performance.Because the transducer is installed almost flush to the hull, when the transducer is installed the tilt corrects for the hull deadrise and orients the ceramic element horizontally to assure maximum echo returns to the transducer.Specifications Weight 2.7 kg (6 lb) Hull Deadrise 16° to 24° hull deadrise Acoustic Window Urethane Hole Size 98 mm (3-7/8") Seven internal broadband ceramic assemblies

Read more less

Airmar SS175C-20-L 20d TiltLow CHIRP with Humminbird 14-PinModel: SS175C-20-L Depth and fast-response water-temperature sensor 1 kW Low Frequency: 40 kHz to 60 kHz with maximum depth performance to 762 m (2500') = 32° to 21° beamwidth Great deep water performance Stainless steel housing for use on stepped, planing or displacement hulls in fiberglass, wood or metal Recommended boat size: Up to 11 m (36') Also available in a bronze housing (B175L) model for use in fiberglass and wood hulls Exclusive Xducer ID® technology Airmar’s low profile Chirp-ready transducer models are the perfect addition to smaller boats such as center consoles. The low frequency band is the deep water performer delivering excellent coverage and tracking in deeper depths. The SS175L transducer delivers up to 20 kHz of total bandwidth in just one installation and delivers tremendous deep water performance.Because the transducer is installed almost flush to the hull, when the transducer is installed the tilt corrects for the hull deadrise and orients the ceramic element horizontally to assure maximum echo returns to the transducer.Specifications Weight 2.7 kg (6 lb) Hull Deadrise 16° to 24° hull deadrise Acoustic Window Urethane Hole Size 98 mm (3-7/8") Seven internal broadband ceramic assemblies

Read more less

Airmar SS175C-20-L 20d TiltLow CHIRP with Garmin 12-PinModel: SS175C-20-L Depth and fast-response water-temperature sensor 1 kW Low Frequency: 40 kHz to 60 kHz with maximum depth performance to 762 m (2500') = 32° to 21° beamwidth Great deep water performance Stainless steel housing for use on stepped, planing or displacement hulls in fiberglass, wood or metal Recommended boat size: Up to 11 m (36') Also available in a bronze housing (B175L) model for use in fiberglass and wood hulls Exclusive Xducer ID® technology Airmar’s low profile Chirp-ready transducer models are the perfect addition to smaller boats such as center consoles. The low frequency band is the deep water performer delivering excellent coverage and tracking in deeper depths. The SS175L transducer delivers up to 20 kHz of total bandwidth in just one installation and delivers tremendous deep water performance.Because the transducer is installed almost flush to the hull, when the transducer is installed the tilt corrects for the hull deadrise and orients the ceramic element horizontally to assure maximum echo returns to the transducer.Specifications Weight 2.7 kg (6 lb) Hull Deadrise 16° to 24° hull deadrise Acoustic Window Urethane Hole Size 98 mm (3-7/8") Seven internal broadband ceramic assemblies

Read more less

Airmar SS175C-20-L 20d TiltLow CHIRP with Raymarine 11-PinModel: SS175C-20-L Depth and fast-response water-temperature sensor 1 kW Low Frequency: 40 kHz to 60 kHz with maximum depth performance to 762 m (2500') = 32° to 21° beamwidth Great deep water performance Stainless steel housing for use on stepped, planing or displacement hulls in fiberglass, wood or metal Recommended boat size: Up to 11 m (36') Also available in a bronze housing (B175L) model for use in fiberglass and wood hulls Exclusive Xducer ID® technology Airmar’s low profile Chirp-ready transducer models are the perfect addition to smaller boats such as center consoles. The low frequency band is the deep water performer delivering excellent coverage and tracking in deeper depths. The SS175L transducer delivers up to 20 kHz of total bandwidth in just one installation and delivers tremendous deep water performance.Because the transducer is installed almost flush to the hull, when the transducer is installed the tilt corrects for the hull deadrise and orients the ceramic element horizontally to assure maximum echo returns to the transducer.Specifications Weight 2.7 kg (6 lb) Hull Deadrise 16° to 24° hull deadrise Acoustic Window Urethane Hole Size 98 mm (3-7/8") Seven internal broadband ceramic assemblies

Read more less

Airmar SS175C-20-L 20d TiltLow CHIRP with No ConnectorModel: SS175C-20-L Depth and fast-response water-temperature sensor 1 kW Low Frequency: 40 kHz to 60 kHz with maximum depth performance to 762 m (2500') = 32° to 21° beamwidth Great deep water performance Stainless steel housing for use on stepped, planing or displacement hulls in fiberglass, wood or metal Recommended boat size: Up to 11 m (36') Also available in a bronze housing (B175L) model for use in fiberglass and wood hulls Exclusive Xducer ID® technology Airmar’s low profile Chirp-ready transducer models are the perfect addition to smaller boats such as center consoles. The low frequency band is the deep water performer delivering excellent coverage and tracking in deeper depths. The SS175L transducer delivers up to 20 kHz of total bandwidth in just one installation and delivers tremendous deep water performance.Because the transducer is installed almost flush to the hull, when the transducer is installed the tilt corrects for the hull deadrise and orients the ceramic element horizontally to assure maximum echo returns to the transducer.Specifications Weight 2.7 kg (6 lb) Hull Deadrise 16° to 24° hull deadrise Acoustic Window Urethane Hole Size 98 mm (3-7/8") Seven internal broadband ceramic assemblies

Read more less

Airmar SS175C-0-L 0d TiltLow CHIRP With Mix-N-Match PlugModel: SS175C-0-L Depth and fast-response water-temperature sensor 1 kW Low Frequency: 40 kHz to 60 kHz with maximum depth performance to 762 m (2500') = 32° to 21° beamwidth Great deep water performance High performance, low-profile thru-hull housing provides good resolution at speed when installed properly Stainless steel housing for use on stepped, planing or displacement hulls in fiberglass, wood or metal Recommended boat size: Up to 11 m (36') Also available in a bronze housing (B175L) model for use in fiberglass and wood hulls Exclusive Xducer ID® technology Airmar’s low profile Chirp-ready transducer models are the perfect addition to smaller boats such as center consoles. The low frequency band is the deep water performer delivering excellent coverage and tracking in deeper depths. The SS175L transducer delivers up to 20 kHz of total bandwidth in just one installation and delivers tremendous deep water performance.Tilted element transducers have the ceramic element fixed at either a 20°, 12° or 0° angle within the transducer housing. The transducer is installed almost flush to the hull and the tilted element corrects for the hull deadrise by orienting the beam directly down. This assures maximum echo returns to the transducer and more accurate depth readings.Specifications Weight 2.7 kg (6 lb) Hull Deadrise 0° to 7° hull deadrise Acoustic Window Urethane Hole Size 98 mm (3-7/8") Seven internal broadband ceramic assemblies

Read more less

Airmar B175MW Medium Ultra-Wide 20 deg Tilted Element™ Thru-Hull - With Humminbird 9-Pin Mix-N-Match CableModel: B175C-20-MW-HB Fixed 20° tilted version for 16° to 24° hull deadrise Depth and fast-response water-temperature sensor 1 kW with depth tracking down to 400 m (1,300#39;) Medium frequency: 60-100 kHz 57° to 73° beamwidth (port/starboard) 16° average fore/aft 40 kHz of total bandwidth from one transducer Medium frequency for superior mid-depth performance and excellent fish-target separation Bronze housing for use on stepped, planing or displacement hull Low-profile, thru-hull housing yields good resolution at speed when installed properly Exclusive Xducer ID® technology AIRMAR’s innovative transducer designs have revolutionized the fishing world, and they continue to do so with the NEW Chirp-ready B175 Medium Ultra-Wide (MW) Tilted Element™ Thru-hull transducer. The B175MW takes transducer design and performance to a whole new level by using medium frequency (60-100 kHz) with an incredible ultra-wide beamwidth ranging from 57-73° port-starboard to 16° average fore-aft. Maximum coverage under the boat is achieved with this medium-frequency transducer, serving anglers who target pelagic species in the upper water column.Airmar’s new Medium Ultra-Wide models are perfect for seeking deeper species with a frequency band from 60-100 kHz. When paired with our other popular models such as the B275LHW, provides the angler with a broad set of frequencies (Low, Medium-Wide, High-Wide) to interrogate targets from deep to shallow.Specifications Power Rating 1 kW Housing Bronze Functions Depth, Temperature Hull Material Fiberglass or wood Max Vessel LOA Up to 11 m (36') Hole Size 95 mm (3-3/4") Mounting Style Tilted Element Thru-Hull Acoustic Window Urethane Cable-Length 9 m (30') Max Depth 400 m (1300') Medium Frequency 60-100 kHz Medium Frequency Beamwidth 57° to 73° (Port/Starboard) X 16° average (Fore/Aft) Water Temperature -10° to 40°C (14° to 104°F) Cable End Mix-N-Match What's in the Box: B175C-20-MW-MM 20d Tilt Medium CHIRP Ultra Wide MMC-9HB Humminbird 9-Pin Mix-n-Match Cable

Read more less

Airmar B175C-0-L Thru Hull 0 Deg Tilt Low CHIRP with Humminbird 9-Pin Mix-N-Match CableModel: B175C-0-L-HB Depth & fast-response water-temperature sensor Low—CHIRPS from 40 kHz to 75 kHz, 32° to 21° beamwidth Available in 0° or 12° tilted versions only 35 kHz of total bandwidth from one transducer Covers popular fishing frequency of 50 kHz plus everything else in the bandwidth Bronze transducer housing Boat Size: Up to 8 m (25’) Hull Type: Fiberglass or wood Exclusive Xducer ID® technology Depth & fast-response water-temperature sensor Hull Type: Wood, fiberglass and metal stepped, planing or displacement type hulls Fixed 0° tilted version for 0° to 7° hull deadrise Engine Type: Can be used with all propulsion types Rely on Airmar’s new broadband transducers for your ultimate fishing mission. Whether you’re a commercial fisherman, charter captain, or tournament angler, there’s a new game in town! Chirp transducers enable bottom detection down to 3,000m (10,000’) with 5 to 10 times greater detail and resolution so precise it’s possible to distinguish between individual baitfish, game fish, and underwater structures. One transducer delivers up to 20 kHz of total bandwidth in just one installation, saving customers time and money.A Tilted Element™ model in the Chirp Thru-Hull product line, the B175L Chirps across the following bandwidths:L Model - Low Frequency 40-60 kHz Acoutis Window Urethane Weight 2.7 kg (6 lb) What's in the Box: B175 Low Chirp, 1kW, 0° Tilt, M&M Transducer, DT MMC-HB Humminbird 9-Pin Mix-N-Match Cable,Airmar B175C-0-L Thru Hull 0 Deg Tilt Low CHIRP with Humminbird 9-Pin Mix-N-Match CableModel: B175C-0-L-HB Depth & fast-response water-temperature sensor Low—CHIRPS from 40 kHz to 75 kHz, 32° to 21° beamwidth Available in 0° or 12° tilted versions only 35 kHz of total bandwidth from one transducer Covers popular fishing frequency of 50 kHz plus everything else in the bandwidth Bronze transducer housing Boat Size: Up to 8 m (25’) Hull Type: Fiberglass or wood Exclusive Xducer ID® technology Depth & fast-response water-temperature sensor Hull Type: Wood, fiberglass and metal stepped, planing or displacement type hulls Fixed 0° tilted version for 0° to 7° hull deadrise Engine Type: Can be used with all propulsion types Rely on Airmar’s new broadband transducers for your ultimate fishing mission. Whether you’re a commercial fisherman, charter captain, or tournament angler, there’s a new game in town! Chirp transducers enable bottom detection down to 3,000m (10,000’) with 5 to 10 times greater detail and resolution so precise it’s possible to distinguish between individual baitfish, game fish, and underwater structures. One transducer delivers up to 20 kHz of total bandwidth in just one installation, saving customers time and money. A Tilted Element™ model in the Chirp Thru-Hull product line, the B175L Chirps across the following bandwidths: L Model - Low Frequency 40-60 kHz Acoutis Window Urethane Weight 2.7 kg (6 lb) What's in the Box: B175 Low Chirp, 1kW, 0° Tilt, M&M Transducer, DT MMC-HB Humminbird 9-Pin Mix-N-Match Cable

Read more less

Airmar B175C-0-L Thru Hull 0 Deg Tilt Low CHIRP with Si-Tex 8-Pin Mix-N-Match CableModel: B175C-0-L-BB Depth & fast-response water-temperature sensor Low—CHIRPS from 40 kHz to 75 kHz, 32° to 21° beamwidth Available in 0° or 12° tilted versions only 35 kHz of total bandwidth from one transducer Covers popular fishing frequency of 50 kHz plus everything else in the bandwidth Bronze transducer housing Boat Size: Up to 8 m (25’) Hull Type: Fiberglass or wood Exclusive Xducer ID® technology Depth & fast-response water-temperature sensor Hull Type: Wood, fiberglass and metal stepped, planing or displacement type hulls Fixed 0° tilted version for 0° to 7° hull deadrise Engine Type: Can be used with all propulsion types Rely on Airmar’s new broadband transducers for your ultimate fishing mission. Whether you’re a commercial fisherman, charter captain, or tournament angler, there’s a new game in town! Chirp transducers enable bottom detection down to 3,000m (10,000’) with 5 to 10 times greater detail and resolution so precise it’s possible to distinguish between individual baitfish, game fish, and underwater structures. One transducer delivers up to 20 kHz of total bandwidth in just one installation, saving customers time and money.A Tilted Element™ model in the Chirp Thru-Hull product line, the B175L Chirps across the following bandwidths:L Model - Low Frequency 40-60 kHz Acoutis Window Urethane Weight 2.7 kg (6 lb) What's in the Box: B175 Low Chirp, 1kW, 0° Tilt, M&M Transducer, DT MMC-BB Si-Tex 8-Pin Mix-N-Match Cable

Read more less

Airmar B175C-0-L Thru Hull 0 Deg Tilt Low CHIRP with Navico 9-Pin Mix-N-Match CableModel: B175C-0-L-9N Depth & fast-response water-temperature sensor Low—CHIRPS from 40 kHz to 75 kHz, 32° to 21° beamwidth Available in 0° or 12° tilted versions only 35 kHz of total bandwidth from one transducer Covers popular fishing frequency of 50 kHz plus everything else in the bandwidth Bronze transducer housing Boat Size: Up to 8 m (25’) Hull Type: Fiberglass or wood Exclusive Xducer ID® technology Depth & fast-response water-temperature sensor Hull Type: Wood, fiberglass and metal stepped, planing or displacement type hulls Fixed 0° tilted version for 0° to 7° hull deadrise Engine Type: Can be used with all propulsion types Rely on Airmar’s new broadband transducers for your ultimate fishing mission. Whether you’re a commercial fisherman, charter captain, or tournament angler, there’s a new game in town! Chirp transducers enable bottom detection down to 3,000m (10,000’) with 5 to 10 times greater detail and resolution so precise it’s possible to distinguish between individual baitfish, game fish, and underwater structures. One transducer delivers up to 20 kHz of total bandwidth in just one installation, saving customers time and money.A Tilted Element™ model in the Chirp Thru-Hull product line, the B175L Chirps across the following bandwidths:L Model - Low Frequency 40-60 kHz Acoutis Window Urethane Weight 2.7 kg (6 lb) What's in the Box: B175 Low Chirp, 1kW, 0° Tilt, M&M Transducer, DT MMC-9NL Navico 9-Pin Mix-N-Match Cable

Read more less

Airmar B175C-0-L Thru Hull 0 Deg Tilt Low CHIRP with Garmin 8-Pin Mix-N-Match CableModel: B175C-0-L-8G Depth & fast-response water-temperature sensor Low—CHIRPS from 40 kHz to 75 kHz, 32° to 21° beamwidth Available in 0° or 12° tilted versions only 35 kHz of total bandwidth from one transducer Covers popular fishing frequency of 50 kHz plus everything else in the bandwidth Bronze transducer housing Boat Size: Up to 8 m (25’) Hull Type: Fiberglass or wood Exclusive Xducer ID® technology Depth & fast-response water-temperature sensor Hull Type: Wood, fiberglass and metal stepped, planing or displacement type hulls Fixed 0° tilted version for 0° to 7° hull deadrise Engine Type: Can be used with all propulsion types Rely on Airmar’s new broadband transducers for your ultimate fishing mission. Whether you’re a commercial fisherman, charter captain, or tournament angler, there’s a new game in town! Chirp transducers enable bottom detection down to 3,000m (10,000’) with 5 to 10 times greater detail and resolution so precise it’s possible to distinguish between individual baitfish, game fish, and underwater structures. One transducer delivers up to 20 kHz of total bandwidth in just one installation, saving customers time and money.A Tilted Element™ model in the Chirp Thru-Hull product line, the B175L Chirps across the following bandwidths:L Model - Low Frequency 40-60 kHz Acoutis Window Urethane Weight 2.7 kg (6 lb) What's in the Box: B175 Low Chirp, 1kW, 0° Tilt, M&M Transducer, DT MMC-8G Garmin 8-Pin Mix-N-Match Cable

Read more less

Airmar B175C-0-L Thru Hull 0 Deg Tilt Low CHIRP with Humminbird 14-Pin Mix-N-Match CableModel: B175C-0-L-14HB Depth & fast-response water-temperature sensor Low—CHIRPS from 40 kHz to 75 kHz, 32° to 21° beamwidth Available in 0° or 12° tilted versions only 35 kHz of total bandwidth from one transducer Covers popular fishing frequency of 50 kHz plus everything else in the bandwidth Bronze transducer housing Boat Size: Up to 8 m (25’) Hull Type: Fiberglass or wood Exclusive Xducer ID® technology Depth & fast-response water-temperature sensor Hull Type: Wood, fiberglass and metal stepped, planing or displacement type hulls Fixed 0° tilted version for 0° to 7° hull deadrise Engine Type: Can be used with all propulsion types Rely on Airmar’s new broadband transducers for your ultimate fishing mission. Whether you’re a commercial fisherman, charter captain, or tournament angler, there’s a new game in town! Chirp transducers enable bottom detection down to 3,000m (10,000’) with 5 to 10 times greater detail and resolution so precise it’s possible to distinguish between individual baitfish, game fish, and underwater structures. One transducer delivers up to 20 kHz of total bandwidth in just one installation, saving customers time and money.A Tilted Element™ model in the Chirp Thru-Hull product line, the B175L Chirps across the following bandwidths:L Model - Low Frequency 40-60 kHz Acoutis Window Urethane Weight 2.7 kg (6 lb) What's in the Box: B175 Low Chirp, 1kW, 0° Tilt, M&M Transducer, DT MMC-14HBLX Humminbird 14-Pin Mix-N-Match Cable

Read more less

Airmar B175C-0-L Thru Hull 0 Deg Tilt Low CHIRP with Garmin 12-Pin Mix-N-Match CableModel: B175C-0-L-12G Depth & fast-response water-temperature sensor Low—CHIRPS from 40 kHz to 75 kHz, 32° to 21° beamwidth Available in 0° or 12° tilted versions only 35 kHz of total bandwidth from one transducer Covers popular fishing frequency of 50 kHz plus everything else in the bandwidth Bronze transducer housing Boat Size: Up to 8 m (25’) Hull Type: Fiberglass or wood Exclusive Xducer ID® technology Depth & fast-response water-temperature sensor Hull Type: Wood, fiberglass and metal stepped, planing or displacement type hulls Fixed 0° tilted version for 0° to 7° hull deadrise Engine Type: Can be used with all propulsion types Rely on Airmar’s new broadband transducers for your ultimate fishing mission. Whether you’re a commercial fisherman, charter captain, or tournament angler, there’s a new game in town! Chirp transducers enable bottom detection down to 3,000m (10,000’) with 5 to 10 times greater detail and resolution so precise it’s possible to distinguish between individual baitfish, game fish, and underwater structures. One transducer delivers up to 20 kHz of total bandwidth in just one installation, saving customers time and money.A Tilted Element™ model in the Chirp Thru-Hull product line, the B175L Chirps across the following bandwidths:L Model - Low Frequency 40-60 kHz Acoutis Window Urethane Weight 2.7 kg (6 lb) What's in the Box: B175 Low Chirp, 1kW, 0° Tilt, M&M Transducer, DT MMC-12G Garmin 12-Pin Mix-N-Match Cable

Read more less

Airmar B175C-0-L Thru Hull 0 Deg Tilt Low CHIRP with Furuno 12-Pin Mix-N-Match CableModel: B175C-0-L-12F Depth & fast-response water-temperature sensor Low—CHIRPS from 40 kHz to 75 kHz, 32° to 21° beamwidth Available in 0° or 12° tilted versions only 35 kHz of total bandwidth from one transducer Covers popular fishing frequency of 50 kHz plus everything else in the bandwidth Bronze transducer housing Boat Size: Up to 8 m (25’) Hull Type: Fiberglass or wood Exclusive Xducer ID® technology Depth & fast-response water-temperature sensor Hull Type: Wood, fiberglass and metal stepped, planing or displacement type hulls Fixed 0° tilted version for 0° to 7° hull deadrise Engine Type: Can be used with all propulsion types Rely on Airmar’s new broadband transducers for your ultimate fishing mission. Whether you’re a commercial fisherman, charter captain, or tournament angler, there’s a new game in town! Chirp transducers enable bottom detection down to 3,000m (10,000’) with 5 to 10 times greater detail and resolution so precise it’s possible to distinguish between individual baitfish, game fish, and underwater structures. One transducer delivers up to 20 kHz of total bandwidth in just one installation, saving customers time and money.A Tilted Element™ model in the Chirp Thru-Hull product line, the B175L Chirps across the following bandwidths:L Model - Low Frequency 40-60 kHz Acoutis Window Urethane Weight 2.7 kg (6 lb) What's in the Box: B175 Low Chirp, 1kW, 0° Tilt, M&M Transducer, DT MMC-12F Furuno 12-Pin Mix-N-Match Cable

Read more less

Airmar B175C-0-L Thru Hull 0 Deg Tilt Low CHIRP with Raymarine 11-Pin Mix-N-Match CableModel: B175C-0-L-11R Depth & fast-response water-temperature sensor Low—CHIRPS from 40 kHz to 75 kHz, 32° to 21° beamwidth Available in 0° or 12° tilted versions only 35 kHz of total bandwidth from one transducer Covers popular fishing frequency of 50 kHz plus everything else in the bandwidth Bronze transducer housing Boat Size: Up to 8 m (25’) Hull Type: Fiberglass or wood Exclusive Xducer ID® technology Depth & fast-response water-temperature sensor Hull Type: Wood, fiberglass and metal stepped, planing or displacement type hulls Fixed 0° tilted version for 0° to 7° hull deadrise Engine Type: Can be used with all propulsion types Rely on Airmar’s new broadband transducers for your ultimate fishing mission. Whether you’re a commercial fisherman, charter captain, or tournament angler, there’s a new game in town! Chirp transducers enable bottom detection down to 3,000m (10,000’) with 5 to 10 times greater detail and resolution so precise it’s possible to distinguish between individual baitfish, game fish, and underwater structures. One transducer delivers up to 20 kHz of total bandwidth in just one installation, saving customers time and money.A Tilted Element™ model in the Chirp Thru-Hull product line, the B175L Chirps across the following bandwidths:L Model - Low Frequency 40-60 kHz Acoutis Window Urethane Weight 2.7 kg (6 lb) What's in the Box: B175 Low Chirp, 1kW, 0° Tilt, M&M Transducer, DT MMC-11R Raymarine 11-Pin Mix-N-Match Cable

Read more less

Airmar B175C-0-L Thru Hull 0 Deg Tilt Low CHIRP with Furuno 10-Pin Mix-N-Match CableModel: B175C-0-L-10F Depth & fast-response water-temperature sensor Low—CHIRPS from 40 kHz to 75 kHz, 32° to 21° beamwidth Available in 0° or 12° tilted versions only 35 kHz of total bandwidth from one transducer Covers popular fishing frequency of 50 kHz plus everything else in the bandwidth Bronze transducer housing Boat Size: Up to 8 m (25’) Hull Type: Fiberglass or wood Exclusive Xducer ID® technology Depth & fast-response water-temperature sensor Hull Type: Wood, fiberglass and metal stepped, planing or displacement type hulls Fixed 0° tilted version for 0° to 7° hull deadrise Engine Type: Can be used with all propulsion types Rely on Airmar’s new broadband transducers for your ultimate fishing mission. Whether you’re a commercial fisherman, charter captain, or tournament angler, there’s a new game in town! Chirp transducers enable bottom detection down to 3,000m (10,000’) with 5 to 10 times greater detail and resolution so precise it’s possible to distinguish between individual baitfish, game fish, and underwater structures. One transducer delivers up to 20 kHz of total bandwidth in just one installation, saving customers time and money.A Tilted Element™ model in the Chirp Thru-Hull product line, the B175L Chirps across the following bandwidths:L Model - Low Frequency 40-60 kHz Acoutis Window Urethane Weight 2.7 kg (6 lb) What's in the Box: B175 Low Chirp, 1kW, 0° Tilt, M&M Transducer, DT MMC-10F Furuno 10-{Pin Mix-N-Match Cable

Read more less

Airmar B175C-0-L Thru Hull 0 Deg Tilt Low CHIRP with Bare Wire Mix-N-Match CableModel: B175C-0-L-0 Depth & fast-response water-temperature sensor Low—CHIRPS from 40 kHz to 75 kHz, 32° to 21° beamwidth Available in 0° or 12° tilted versions only 35 kHz of total bandwidth from one transducer Covers popular fishing frequency of 50 kHz plus everything else in the bandwidth Bronze transducer housing Boat Size: Up to 8 m (25’) Hull Type: Fiberglass or wood Exclusive Xducer ID® technology Depth & fast-response water-temperature sensor Hull Type: Wood, fiberglass and metal stepped, planing or displacement type hulls Fixed 0° tilted version for 0° to 7° hull deadrise Engine Type: Can be used with all propulsion types Rely on Airmar’s new broadband transducers for your ultimate fishing mission. Whether you’re a commercial fisherman, charter captain, or tournament angler, there’s a new game in town! Chirp transducers enable bottom detection down to 3,000m (10,000’) with 5 to 10 times greater detail and resolution so precise it’s possible to distinguish between individual baitfish, game fish, and underwater structures. One transducer delivers up to 20 kHz of total bandwidth in just one installation, saving customers time and money.A Tilted Element™ model in the Chirp Thru-Hull product line, the B175L Chirps across the following bandwidths:L Model - Low Frequency 40-60 kHz Acoutis Window Urethane Weight 2.7 kg (6 lb) What's in the Box: B175 Low Chirp, 1kW, 0° Tilt, M&M Transducer, DT MMC-0 Bare wire Mix-N-Match Cable

Read more less

Airmar B285C High Wide 1Kw CHIRP Bronze Thru Hull with Humminbird 9-Pin Mix-N-Match CableModel: B285C-HW-HB Depth & temperature Bronze housing Exclusive Xducer ID® technology Get more coverage under the boat with Airmar's wide beam Chirp product line. Offering a high frequency range of 150-250 kHz and a constant 25° Beamwidth, these transducers are truly broadband at its best. In addition to improving the performance of Chirp-ready echosounders, anglers using the single band, wide beam transducers will achieve twice the coverage under the boat compared to our current high frequency Chirp transducersA unique property of the high frequency transducers is that the Beamwidth is a constant 25° angle across the entire frequency band. Now, in addition to providing vast bottom coverage and precise fish detection in the upper water column that can sometimes go unseen with our narrow beam transducers, Airmar's new wide beam format also creates crisper and larger return images on the display. We've got you covered.Specifications CHIRP Frequency 150-250kHz Beam width Constant 25° Maximum depth 500' What's in the Box: B285C High Speed Fairing Block MMC-HB

Read more less

Airmar B285C High Wide 1Kw CHIRP Bronze Thru Hull with Navico 7-Pin Mix-N-Match CableModel: B285C-HW-BL Depth & temperature Bronze housing Exclusive Xducer ID® technology Get more coverage under the boat with Airmar's wide beam Chirp product line. Offering a high frequency range of 150-250 kHz and a constant 25° Beamwidth, these transducers are truly broadband at its best. In addition to improving the performance of Chirp-ready echosounders, anglers using the single band, wide beam transducers will achieve twice the coverage under the boat compared to our current high frequency Chirp transducersA unique property of the high frequency transducers is that the Beamwidth is a constant 25° angle across the entire frequency band. Now, in addition to providing vast bottom coverage and precise fish detection in the upper water column that can sometimes go unseen with our narrow beam transducers, Airmar's new wide beam format also creates crisper and larger return images on the display. We've got you covered.Specifications CHIRP Frequency 150-250kHz Beam width Constant 25° Maximum depth 500' What's in the Box: B285C High Speed Fairing Block MMC-BL

Read more less

Airmar B285C High Wide 1Kw CHIRP Bronze Thru Hull with Navico 9-Pin Mix-N-Match CableModel: B285C-HW-9N Depth & temperature Bronze housing Exclusive Xducer ID® technology Get more coverage under the boat with Airmar's wide beam Chirp product line. Offering a high frequency range of 150-250 kHz and a constant 25° Beamwidth, these transducers are truly broadband at its best. In addition to improving the performance of Chirp-ready echosounders, anglers using the single band, wide beam transducers will achieve twice the coverage under the boat compared to our current high frequency Chirp transducersA unique property of the high frequency transducers is that the Beamwidth is a constant 25° angle across the entire frequency band. Now, in addition to providing vast bottom coverage and precise fish detection in the upper water column that can sometimes go unseen with our narrow beam transducers, Airmar's new wide beam format also creates crisper and larger return images on the display. We've got you covered.Specifications CHIRP Frequency 150-250kHz Beam width Constant 25° Maximum depth 500' What's in the Box: B285C High Speed Fairing Block MMC-9N

Read more less

Airmar B285C High Wide 1Kw CHIRP Bronze Thru Hull with Humminbird 14-Pin Mix-N-Match CableModel: B285C-HW-14HB Depth & temperature Bronze housing Exclusive Xducer ID® technology Get more coverage under the boat with Airmar's wide beam Chirp product line. Offering a high frequency range of 150-250 kHz and a constant 25° Beamwidth, these transducers are truly broadband at its best. In addition to improving the performance of Chirp-ready echosounders, anglers using the single band, wide beam transducers will achieve twice the coverage under the boat compared to our current high frequency Chirp transducersA unique property of the high frequency transducers is that the Beamwidth is a constant 25° angle across the entire frequency band. Now, in addition to providing vast bottom coverage and precise fish detection in the upper water column that can sometimes go unseen with our narrow beam transducers, Airmar's new wide beam format also creates crisper and larger return images on the display. We've got you covered.Specifications CHIRP Frequency 150-250kHz Beam width Constant 25° Maximum depth 500' What's in the Box: B285C High Speed Fairing Block MMC-14HB

Read more less

Airmar B285C High Wide 1Kw CHIRP Bronze Thru Hull with Garmin 12-Pin Mix-N-Match CableModel: B285C-HW-12G Depth & temperature Bronze housing Exclusive Xducer ID® technology Get more coverage under the boat with Airmar's wide beam Chirp product line. Offering a high frequency range of 150-250 kHz and a constant 25° Beamwidth, these transducers are truly broadband at its best. In addition to improving the performance of Chirp-ready echosounders, anglers using the single band, wide beam transducers will achieve twice the coverage under the boat compared to our current high frequency Chirp transducersA unique property of the high frequency transducers is that the Beamwidth is a constant 25° angle across the entire frequency band. Now, in addition to providing vast bottom coverage and precise fish detection in the upper water column that can sometimes go unseen with our narrow beam transducers, Airmar's new wide beam format also creates crisper and larger return images on the display. We've got you covered.Specifications CHIRP Frequency 150-250kHz Beam width Constant 25° Maximum depth 500' What's in the Box: B285C High Speed Fairing Block MMC-12G

Read more less

Airmar B285C High Wide 1Kw CHIRP Bronze Thru Hull with Raymarine 11-Pin Mix-N-Match CableModel: B285C-HW-11R Depth & temperature Bronze housing Exclusive Xducer ID® technology Get more coverage under the boat with Airmar's wide beam Chirp product line. Offering a high frequency range of 150-250 kHz and a constant 25° Beamwidth, these transducers are truly broadband at its best. In addition to improving the performance of Chirp-ready echosounders, anglers using the single band, wide beam transducers will achieve twice the coverage under the boat compared to our current high frequency Chirp transducersA unique property of the high frequency transducers is that the Beamwidth is a constant 25° angle across the entire frequency band. Now, in addition to providing vast bottom coverage and precise fish detection in the upper water column that can sometimes go unseen with our narrow beam transducers, Airmar's new wide beam format also creates crisper and larger return images on the display. We've got you covered.Specifications CHIRP Frequency 150-250kHz Beam width Constant 25° Maximum depth 500' What's in the Box: B285C High Speed Fairing Block MMC-11R-HM

Read more less

Airmar B285C High Wide 1Kw CHIRP Bronze Thru Hull with Bare Wire Mix-N-Match CableModel: B285C-HW-0 Depth & temperature Bronze housing Exclusive Xducer ID® technology Get more coverage under the boat with Airmar's wide beam Chirp product line. Offering a high frequency range of 150-250 kHz and a constant 25° Beamwidth, these transducers are truly broadband at its best. In addition to improving the performance of Chirp-ready echosounders, anglers using the single band, wide beam transducers will achieve twice the coverage under the boat compared to our current high frequency Chirp transducersA unique property of the high frequency transducers is that the Beamwidth is a constant 25° angle across the entire frequency band. Now, in addition to providing vast bottom coverage and precise fish detection in the upper water column that can sometimes go unseen with our narrow beam transducers, Airmar's new wide beam format also creates crisper and larger return images on the display. We've got you covered.Specifications CHIRP Frequency 150-250kHz Beam width Constant 25° Maximum depth 500' What's in the Box: B285C High Speed Fairing Block MMC-0

Read more less

Airmar TM185MW Medium Ultra-Wide Chirp-ready Transom Mount - Requires MMC CableModel: TM185C-MW-MM Depth and fast-response water-temperature sensor 1 kW with depth tracking down to 400 m (1,300') Medium frequency: 60-100 kHz 57° to 73° beamwidth (port/starboard) 16° average fore/aft 40 kHz of total bandwidth from one transducer Medium frequency for superior mid-depth performance and excellent fish-target separation Simple installation on transom of the boat Great performance at boat speeds below 30 knots Easy maintenance and low-cost replacement Exclusive Xducer ID® technology AIRMAR’s innovative transducer designs have revolutionized the fishing world, and they continue to do so with the NEW Chirp-ready TM185 Medium Ultra-Wide (MW) Transom Mount transducer. The TM185MW takes transducer design and performance to a whole new level by using medium frequency (60-100 kHz) with an incredible ultra-wide beamwidth ranging from 57-73° port-starboard to 16° average fore-aft. Maximum coverage under the boat is achieved with this medium-frequency transducer, serving anglers who target pelagic species in the upper water column. Airmar’s new Medium Ultra-Wide models are perfect for seeking deeper species with a frequency band from 60-100 kHz.The TM185MW Transom Mount is a 1 kW transducer housed in one of AIRMAR’s most popular housings. Transom models are best suited for small and trailered vessels where a thruhull installation is not practical. Simple to install and ideal for small trailered vessels where a thru-hull may interfere with loading.Specifications Power Rating 1 kW Transom Angle 2° to 22° Functions Depth, Temperature Acoustic Window Urethane Cable-Length 9 m (30') Freq Med Wide 60-100 kHz Housing Urethane/Stainless Bracket Max Depth 400 m (1300') Medium-Wide Beamwidth 57° to 73° beam p/s 16° average f/a Mounting Style Transom Single or Dual Frequency CHIRP-Ready Single-Band Weight 4.2 kg (9.2 lb.) What's in the Box:TM185MW Medium Ultra-Wide Chirp-ready Transom Mount

Read more less

Airmar B175MW Medium Ultra-Wide 20 deg Tilted Element™ Thru-Hull - requires Mix-N-Match CableModel: B175C-20-MW-MM Fixed 20° tilted version for 16° to 24° hull deadrise Depth and fast-response water-temperature sensor 1 kW with depth tracking down to 400 m (1,300#39;) Medium frequency: 60-100 kHz 57° to 73° beamwidth (port/starboard) 16° average fore/aft 40 kHz of total bandwidth from one transducer Medium frequency for superior mid-depth performance and excellent fish-target separation Bronze housing for use on stepped, planing or displacement hull Low-profile, thru-hull housing yields good resolution at speed when installed properly Exclusive Xducer ID® technology AIRMAR’s innovative transducer designs have revolutionized the fishing world, and they continue to do so with the NEW Chirp-ready B175 Medium Ultra-Wide (MW) Tilted Element™ Thru-hull transducer. The B175MW takes transducer design and performance to a whole new level by using medium frequency (60-100 kHz) with an incredible ultra-wide beamwidth ranging from 57-73° port-starboard to 16° average fore-aft. Maximum coverage under the boat is achieved with this medium-frequency transducer, serving anglers who target pelagic species in the upper water column.Airmar’s new Medium Ultra-Wide models are perfect for seeking deeper species with a frequency band from 60-100 kHz. When paired with our other popular models such as the B275LHW, provides the angler with a broad set of frequencies (Low, Medium-Wide, High-Wide) to interrogate targets from deep to shallow.Specifications Power Rating 1 kW Housing Bronze Functions Depth, Temperature Hull Material Fiberglass or wood Max Vessel LOA Up to 11 m (36') Hole Size 95 mm (3-3/4") Mounting Style Tilted Element Thru-Hull Acoustic Window Urethane Cable-Length 9 m (30') Max Depth 400 m (1300') Medium Frequency 60-100 kHz Medium Frequency Beamwidth 57° to 73° (Port/Starboard) X 16° average (Fore/Aft) Water Temperature -10° to 40°C (14° to 104°F) Cable End Mix-N-Match

Read more less

Airmar B175MW Medium Ultra-Wide 12 deg Tilted Element™ Thru-Hull - requires Mix-N-Match CableModel: B175C-12-MW-MM Fixed 12° tilted version for 8° to 15° hull deadrise Depth and fast-response water-temperature sensor 1 kW with depth tracking down to 400 m (1,300#39;) Medium frequency: 60-100 kHz 57° to 73° beamwidth (port/starboard) 16° average fore/aft 40 kHz of total bandwidth from one transducer Medium frequency for superior mid-depth performance and excellent fish-target separation Bronze housing for use on stepped, planing or displacement hull Low-profile, thru-hull housing yields good resolution at speed when installed properly Exclusive Xducer ID® technology AIRMAR’s innovative transducer designs have revolutionized the fishing world, and they continue to do so with the NEW Chirp-ready B175 Medium Ultra-Wide (MW) Tilted Element™ Thru-hull transducer. The B175MW takes transducer design and performance to a whole new level by using medium frequency (60-100 kHz) with an incredible ultra-wide beamwidth ranging from 57-73° port-starboard to 16° average fore-aft. Maximum coverage under the boat is achieved with this medium-frequency transducer, serving anglers who target pelagic species in the upper water column.Airmar’s new Medium Ultra-Wide models are perfect for seeking deeper species with a frequency band from 60-100 kHz. When paired with our other popular models such as the B275LHW, provides the angler with a broad set of frequencies (Low, Medium-Wide, High-Wide) to interrogate targets from deep to shallow.Specifications Power Rating 1 kW Housing Bronze Functions Depth, Temperature Hull Material Fiberglass or wood Max Vessel LOA Up to 11 m (36') Hole Size 95 mm (3-3/4") Mounting Style Tilted Element Thru-Hull Acoustic Window Urethane Cable-Length 9 m (30') Max Depth 400 m (1300') Medium Frequency 60-100 kHz Medium Frequency Beamwidth 57° to 73° (Port/Starboard) X 16° average (Fore/Aft) Water Temperature -10° to 40°C (14° to 104°F) Cable End Mix-N-Match

Read more less

Airmar B175MW Medium Ultra-Wide 0 deg Tilted Element™ Thru-Hull - requires Mix-N-Match CableModel: B175C-0-MW-MM Fixed 0° tilted version for 0° to 7° hull deadrise Depth and fast-response water-temperature sensor 1 kW with depth tracking down to 400 m (1,300#39;) Medium frequency: 60-100 kHz 57° to 73° beamwidth (port/starboard) 16° average fore/aft 40 kHz of total bandwidth from one transducer Medium frequency for superior mid-depth performance and excellent fish-target separation Bronze housing for use on stepped, planing or displacement hull Low-profile, thru-hull housing yields good resolution at speed when installed properly Exclusive Xducer ID® technology AIRMAR’s innovative transducer designs have revolutionized the fishing world, and they continue to do so with the NEW Chirp-ready B175 Medium Ultra-Wide (MW) Tilted Element™ Thru-hull transducer. The B175MW takes transducer design and performance to a whole new level by using medium frequency (60-100 kHz) with an incredible ultra-wide beamwidth ranging from 57-73° port-starboard to 16° average fore-aft. Maximum coverage under the boat is achieved with this medium-frequency transducer, serving anglers who target pelagic species in the upper water column.Airmar’s new Medium Ultra-Wide models are perfect for seeking deeper species with a frequency band from 60-100 kHz. When paired with our other popular models such as the B275LHW, provides the angler with a broad set of frequencies (Low, Medium-Wide, High-Wide) to interrogate targets from deep to shallow.Specifications Power Rating 1 kW Housing Bronze Functions Depth, Temperature Hull Material Fiberglass or wood Max Vessel LOA Up to 11 m (36') Hole Size 95 mm (3-3/4") Mounting Style Tilted Element Thru-Hull Acoustic Window Urethane Cable-Length 9 m (30') Max Depth 400 m (1300') Medium Frequency 60-100 kHz Medium Frequency Beamwidth 57° to 73° (Port/Starboard) X 16° average (Fore/Aft) Water Temperature -10° to 40°C (14° to 104°F) Cable End Mix-N-Match

Read more less

B175MW Medium Ultra-Wide 20-Degree 1kW CHIRP Transducer Requires Mix & Match CableAirmar’s innovative transducer designs have revolutionized the fishing world, and they continue to do so with the Chirp-ready B175 Medium Ultra-Wide (MW) Tilted Element™ Thru-hull transducer. The B175MW takes transducer design and performance to a level by using medium frequency (60-100 kHz) with an incredible ultra-wide beamwidth ranging from 57-73° starboard to 16° average fore-aft. Maximum coverage under the boat is achieved with this medium-frequency transducer, serving anglers who target pelagic species in the upper water column.Airmar’s Medium Ultra-Wide models are perfect for seeking deeper species with a frequency band from 60-100 kHz. When paired with our other popular models such as the B275LHW, provides the angler with a broad set of frequencies (Low, Medium-Wide, High-Wide) to interrogate targets from deep to shallow.The B175MW Tilted Element Thru-hull is a 1 kW transducer housed in one of AIRMAR’s most popular Tilted Element housings which includes a ceramic element fixed at a 20°, 12° or 0° angle. Because the transducer is installed almost flush with the hull, the tilted element corrects for the hull deadrise and orients the ceramic element vertically to ensure maximum echo returns to the transducer.Features: Depth and fast-response water-temperature sensor 1 kW with depth tracking down to 400 m (1,300') Medium frequency: 60-100 kHz 57° to 73° beamwidth (port/starboard) 16° average fore/aft 40 kHz of total bandwidth from one transducer Medium frequency for superior mid-depth performance and excellent fish-target separation Bronze housing for use on stepped, planing, or displacement hull Low-profile, thru-hull housing yields good resolution at speed when installed properly Exclusive Xducer ID® technology Specifications: Power Rating: 1 kW Max Deadrise Angle: 24° Housing: Bronze Functions: Depth, Temperature Hull Material: Fiberglass or wood Max Vessel LOA: Up to 11 m (36') Hole Size: 95 mm (3-3/4") Mounting Style: Tilted Element Thru-Hull Acoustic Window: Urethane Cable-Length: 9 m (30') Common Use: Fishing Max Depth: 400 m (1300') Medium Frequency: 60-100 kHz Medium Frequency Beamwidth: 57° to 73° (Port/Starboard) X 16° average (Fore/Aft) Medium-Wide Beamwidth: 57° to 73° beam p/s 16° average f/a Power Rating: 1 kW Single or Dual Frequency: CHIRP-Ready Single-Band Tilted Element: Yes Water Temperature: -10° to 40°C (14° to 104°F) Weight: 2.7 kg (6 lbs) This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Quick Guide (pdf)Brochure (pdf)

Read more less

Airmar SS175C-20-HW 20d TiltHigh Wide CHIRP wIth Humminbird 9-PinModel: SS175C-20-HW-HB Depth and fast-response water-temperature sensor 1 kW with a maximum depth of 152 m (500') High Frequency: 150 kHz to 250 kHz = Constant 25° beamwidth 100 kHz of total bandwidth from one transducer Covers popular fishing frequency of 200 kHz plus everything else in the bandwidth High frequency provides superior shallow water performance, bottom detail and fish target separation High wide beamwidth provides more coverage under the boat for detecting fish in the upper water column Low-profile thru-hull housing provides good resolution at speed when installed properly Stainless steel housing for use on stepped, planing or displacement hulls made of fiberglass, wood or metal Recommended boat size: Up to 11 m (36') Also available in transom-mount (TM185HW), in-hull (M285HW) and bronze housing (B175HW) models Exclusive Xducer ID® technology Get more coverage under your boat with Airmar’s unique wide beam, high frequency Chirp-ready transducers. The high band operates across a frequency range of 150 to 250 kHz and has a fixed 25° beam for all frequencies. The high frequency band results in superior resolution. The constant wide beamwidth provides twice the coverage under the boat and excellent fish arches on the display compared to most high frequency narrow beam transducer options.The high wide is the ideal choice for both inshore and pelagic fishing, where resolution and maximum coverage under the boat are essential down to 500'.Because the transducer is installed almost flush to the hull, when the transducer is installed the tilt corrects for the hull deadrise and orients the ceramic element horizontally to assure maximum echo returns to the transducer.Specifications Weight 2.7 kg (6 lb) Hull Deadrise: 16° to 24° hull deadrise Acoustic Window Urethane Hole Size 98 mm (3-7/8") One internal ceramic assembly

Read more less

Airmar SS175C-20-HW 20d TiltHigh Wide CHIRP wIth Si-Tex 8-PinModel: SS175C-20-HW Depth and fast-response water-temperature sensor 1 kW with a maximum depth of 152 m (500') High Frequency: 150 kHz to 250 kHz = Constant 25° beamwidth 100 kHz of total bandwidth from one transducer Covers popular fishing frequency of 200 kHz plus everything else in the bandwidth High frequency provides superior shallow water performance, bottom detail and fish target separation High wide beamwidth provides more coverage under the boat for detecting fish in the upper water column Low-profile thru-hull housing provides good resolution at speed when installed properly Stainless steel housing for use on stepped, planing or displacement hulls made of fiberglass, wood or metal Recommended boat size: Up to 11 m (36') Also available in transom-mount (TM185HW), in-hull (M285HW) and bronze housing (B175HW) models Exclusive Xducer ID® technology Get more coverage under your boat with Airmar’s unique wide beam, high frequency Chirp-ready transducers. The high band operates across a frequency range of 150 to 250 kHz and has a fixed 25° beam for all frequencies. The high frequency band results in superior resolution. The constant wide beamwidth provides twice the coverage under the boat and excellent fish arches on the display compared to most high frequency narrow beam transducer options.The high wide is the ideal choice for both inshore and pelagic fishing, where resolution and maximum coverage under the boat are essential down to 500'.Because the transducer is installed almost flush to the hull, when the transducer is installed the tilt corrects for the hull deadrise and orients the ceramic element horizontally to assure maximum echo returns to the transducer.Specifications Weight 2.7 kg (6 lb) Hull Deadrise: 16° to 24° hull deadrise Acoustic Window Urethane Hole Size 98 mm (3-7/8") One internal ceramic assembly

Read more less

Airmar SS175C-20-HW 20d TiltHigh Wide CHIRP wIth Navico 9-PinModel: SS175C-20-HW Depth and fast-response water-temperature sensor 1 kW with a maximum depth of 152 m (500') High Frequency: 150 kHz to 250 kHz = Constant 25° beamwidth 100 kHz of total bandwidth from one transducer Covers popular fishing frequency of 200 kHz plus everything else in the bandwidth High frequency provides superior shallow water performance, bottom detail and fish target separation High wide beamwidth provides more coverage under the boat for detecting fish in the upper water column Low-profile thru-hull housing provides good resolution at speed when installed properly Stainless steel housing for use on stepped, planing or displacement hulls made of fiberglass, wood or metal Recommended boat size: Up to 11 m (36') Also available in transom-mount (TM185HW), in-hull (M285HW) and bronze housing (B175HW) models Exclusive Xducer ID® technology Get more coverage under your boat with Airmar’s unique wide beam, high frequency Chirp-ready transducers. The high band operates across a frequency range of 150 to 250 kHz and has a fixed 25° beam for all frequencies. The high frequency band results in superior resolution. The constant wide beamwidth provides twice the coverage under the boat and excellent fish arches on the display compared to most high frequency narrow beam transducer options.The high wide is the ideal choice for both inshore and pelagic fishing, where resolution and maximum coverage under the boat are essential down to 500'.Because the transducer is installed almost flush to the hull, when the transducer is installed the tilt corrects for the hull deadrise and orients the ceramic element horizontally to assure maximum echo returns to the transducer.Specifications Weight 2.7 kg (6 lb) Hull Deadrise: 16° to 24° hull deadrise Acoustic Window Urethane Hole Size 98 mm (3-7/8") One internal ceramic assembly

Read more less

Airmar SS175C-20-HW 20d TiltHigh Wide CHIRP wIth Humminbird 21-PinModel: SS175C-20-HW Depth and fast-response water-temperature sensor 1 kW with a maximum depth of 152 m (500') High Frequency: 150 kHz to 250 kHz = Constant 25° beamwidth 100 kHz of total bandwidth from one transducer Covers popular fishing frequency of 200 kHz plus everything else in the bandwidth High frequency provides superior shallow water performance, bottom detail and fish target separation High wide beamwidth provides more coverage under the boat for detecting fish in the upper water column Low-profile thru-hull housing provides good resolution at speed when installed properly Stainless steel housing for use on stepped, planing or displacement hulls made of fiberglass, wood or metal Recommended boat size: Up to 11 m (36') Also available in transom-mount (TM185HW), in-hull (M285HW) and bronze housing (B175HW) models Exclusive Xducer ID® technology Get more coverage under your boat with Airmar’s unique wide beam, high frequency Chirp-ready transducers. The high band operates across a frequency range of 150 to 250 kHz and has a fixed 25° beam for all frequencies. The high frequency band results in superior resolution. The constant wide beamwidth provides twice the coverage under the boat and excellent fish arches on the display compared to most high frequency narrow beam transducer options.The high wide is the ideal choice for both inshore and pelagic fishing, where resolution and maximum coverage under the boat are essential down to 500'.Tilted element transducers have the element fixed at either a 20°, 12° or 0° angle within the transducer housing. Because the transducer is installed almost flush to the hull, when the transducer is installed the tilt corrects for the hull deadrise and orients the ceramic element horizontally to assure maximum echo returns to the transducer.Specifications Weight 2.7 kg (6 lb) Hull Deadrise: Up to 24° Acoustic Window Urethane Hole Size 98 mm (3-7/8") One internal ceramic assembly

Read more less

Airmar SS175C-20-HW 20d TiltHigh Wide CHIRP wIth Humminbird 14-PinModel: SS175C-20-HW Depth and fast-response water-temperature sensor 1 kW with a maximum depth of 152 m (500') High Frequency: 150 kHz to 250 kHz = Constant 25° beamwidth 100 kHz of total bandwidth from one transducer Covers popular fishing frequency of 200 kHz plus everything else in the bandwidth High frequency provides superior shallow water performance, bottom detail and fish target separation High wide beamwidth provides more coverage under the boat for detecting fish in the upper water column Low-profile thru-hull housing provides good resolution at speed when installed properly Stainless steel housing for use on stepped, planing or displacement hulls made of fiberglass, wood or metal Recommended boat size: Up to 11 m (36') Also available in transom-mount (TM185HW), in-hull (M285HW) and bronze housing (B175HW) models Exclusive Xducer ID® technology Get more coverage under your boat with Airmar’s unique wide beam, high frequency Chirp-ready transducers. The high band operates across a frequency range of 150 to 250 kHz and has a fixed 25° beam for all frequencies. The high frequency band results in superior resolution. The constant wide beamwidth provides twice the coverage under the boat and excellent fish arches on the display compared to most high frequency narrow beam transducer options.The high wide is the ideal choice for both inshore and pelagic fishing, where resolution and maximum coverage under the boat are essential down to 500'.Because the transducer is installed almost flush to the hull, when the transducer is installed the tilt corrects for the hull deadrise and orients the ceramic element horizontally to assure maximum echo returns to the transducer.Specifications Weight 2.7 kg (6 lb) Hull Deadrise 16° to 24° hull deadrise Acoustic Window Urethane Hole Size 98 mm (3-7/8") One internal ceramic assembly

Read more less

Airmar SS175C-20-HW 20d TiltHigh Wide CHIRP with Garmin 12-PinModel: SS175C-20-HW Depth and fast-response water-temperature sensor 1 kW with a maximum depth of 152 m (500') High Frequency: 150 kHz to 250 kHz = Constant 25° beamwidth 100 kHz of total bandwidth from one transducer Covers popular fishing frequency of 200 kHz plus everything else in the bandwidth High frequency provides superior shallow water performance, bottom detail and fish target separation High wide beamwidth provides more coverage under the boat for detecting fish in the upper water column Low-profile thru-hull housing provides good resolution at speed when installed properly Stainless steel housing for use on stepped, planing or displacement hulls made of fiberglass, wood or metal Recommended boat size: Up to 11 m (36') Also available in transom-mount (TM185HW), in-hull (M285HW) and bronze housing (B175HW) models Exclusive Xducer ID® technology Get more coverage under your boat with Airmar’s unique wide beam, high frequency Chirp-ready transducers. The high band operates across a frequency range of 150 to 250 kHz and has a fixed 25° beam for all frequencies. The high frequency band results in superior resolution. The constant wide beamwidth provides twice the coverage under the boat and excellent fish arches on the display compared to most high frequency narrow beam transducer options.The high wide is the ideal choice for both inshore and pelagic fishing, where resolution and maximum coverage under the boat are essential down to 500'.Because the transducer is installed almost flush to the hull, when the transducer is installed the tilt corrects for the hull deadrise and orients the ceramic element horizontally to assure maximum echo returns to the transducer.Specifications Weight 2.7 kg (6 lb) Hull Deadrise 16° to 24° hull deadrise Acoustic Window Urethane Hole Size 98 mm (3-7/8") One internal ceramic assembly

Read more less

Airmar SS175C-20-HW 20d TiltHigh Wide CHIRP wIth Raymarine 11-PinModel: SS175C-20-HWGet more coverage under your boat with Airmar’s unique wide beam, high frequency Chirp-ready transducers. The high band operates across a frequency range of 150 to 250 kHz and has a fixed 25° beam for all frequencies. The high frequency band results in superior resolution. The constant wide beamwidth provides twice the coverage under the boat and excellent fish arches on the display compared to most high frequency narrow beam transducer options.The high wide is the ideal choice for both inshore and pelagic fishing, where resolution and maximum coverage under the boat are essential down to 500'.Because the transducer is installed almost flush to the hull, when the transducer is installed the tilt corrects for the hull deadrise and orients the ceramic element horizontally to assure maximum echo returns to the transducer.Specifications Weight 2.7 kg (6 lb) Hull Deadrise 16° to 24° hull deadrise Acoustic Window Urethane Hole Size 98 mm (3-7/8") One internal ceramic assembly

Read more less

Airmar SS175C-12-HW 12d TiltHigh Wide CHIRP with Humminbird 9-PinModel: SS175C-12-HW Depth and fast-response water-temperature sensor 1 kW with a maximum depth of 152 m (500') 100 kHz of total bandwidth from one transducer Covers popular fishing frequency of 200 kHz plus everything else in the bandwidth High frequency provides superior shallow water performance, bottom detail and fish target separation High wide beamwidth provides more coverage under the boat for detecting fish in the upper water column Low-profile thru-hull housing provides good resolution at speed when installed properly Stainless steel housing for use on stepped, planing or displacement hulls made of fiberglass, wood or metal Also available in transom-mount (TM185HW), in-hull (M285HW) and bronze housing (B175HW) models Exclusive Xducer ID® technology Get more coverage under your boat with Airmar’s unique wide beam, high frequency Chirp-ready transducers. The high band operates across a frequency range of 150 to 250 kHz and has a fixed 25° beam for all frequencies. The high frequency band results in superior resolution. The constant wide beamwidth provides twice the coverage under the boat and excellent fish arches on the display compared to most high frequency narrow beam transducer options.The high wide is the ideal choice for both inshore and pelagic fishing, where resolution and maximum coverage under the boat are essential down to 500'.Tilted element transducers have the element fixed at either a 20°, 12° or 0° angle within the transducer housing. Because the transducer is installed almost flush to the hull, when the transducer is installed the tilt corrects for the hull deadrise and orients the ceramic element horizontally to assure maximum echo returns to the transducer.Specifications Weight 2.7 kg (6 lb) Hull Deadrise 8° to 15° hull deadrise Acoustic Window Urethane Hole Size 98 mm (3-7/8") One internal ceramic assembly

Read more less

Airmar SS175C-12-HW 12d TiltHigh Wide CHIRP with Navico BLModel: SS175C-12-HW Depth and fast-response water-temperature sensor 1 kW with a maximum depth of 152 m (500') 100 kHz of total bandwidth from one transducer Covers popular fishing frequency of 200 kHz plus everything else in the bandwidth High frequency provides superior shallow water performance, bottom detail and fish target separation High wide beamwidth provides more coverage under the boat for detecting fish in the upper water column Low-profile thru-hull housing provides good resolution at speed when installed properly Stainless steel housing for use on stepped, planing or displacement hulls made of fiberglass, wood or metal Also available in transom-mount (TM185HW), in-hull (M285HW) and bronze housing (B175HW) models Exclusive Xducer ID® technology Get more coverage under your boat with Airmar’s unique wide beam, high frequency Chirp-ready transducers. The high band operates across a frequency range of 150 to 250 kHz and has a fixed 25° beam for all frequencies. The high frequency band results in superior resolution. The constant wide beamwidth provides twice the coverage under the boat and excellent fish arches on the display compared to most high frequency narrow beam transducer options.The high wide is the ideal choice for both inshore and pelagic fishing, where resolution and maximum coverage under the boat are essential down to 500'.Tilted element transducers have the element fixed at either a 20°, 12° or 0° angle within the transducer housing. Because the transducer is installed almost flush to the hull, when the transducer is installed the tilt corrects for the hull deadrise and orients the ceramic element horizontally to assure maximum echo returns to the transducer.Specifications Weight 2.7 kg (6 lb) Hull Deadrise 8° to 15° hull deadrise Acoustic Window Urethane Hole Size 98 mm (3-7/8") One internal ceramic assembly

Read more less

Airmar SS175C-12-HW 12d TiltHigh Wide CHIRP with Navico 9-PinModel: SS175C-12-HW Depth and fast-response water-temperature sensor 1 kW with a maximum depth of 152 m (500') High Frequency: 150 kHz to 250 kHz = Constant 25° beamwidth 100 kHz of total bandwidth from one transducer Covers popular fishing frequency of 200 kHz plus everything else in the bandwidth High frequency provides superior shallow water performance, bottom detail and fish target separation High wide beamwidth provides more coverage under the boat for detecting fish in the upper water column Low-profile thru-hull housing provides good resolution at speed when installed properly Stainless steel housing for use on stepped, planing or displacement hulls made of fiberglass, wood or metal Recommended boat size: Up to 11 m (36') Also available in transom-mount (TM185HW), in-hull (M285HW) and bronze housing (B175HW) models Exclusive Xducer ID® technology Get more coverage under your boat with Airmar’s unique wide beam, high frequency Chirp-ready transducers. The high band operates across a frequency range of 150 to 250 kHz and has a fixed 25° beam for all frequencies. The high frequency band results in superior resolution. The constant wide beamwidth provides twice the coverage under the boat and excellent fish arches on the display compared to most high frequency narrow beam transducer options.The high wide is the ideal choice for both inshore and pelagic fishing, where resolution and maximum coverage under the boat are essential down to 500'.Tilted element transducers have the element fixed at either a 20°, 12° or 0° angle within the transducer housing. Because the transducer is installed almost flush to the hull, when the transducer is installed the tilt corrects for the hull deadrise and orients the ceramic element horizontally to assure maximum echo returns to the transducer.Specifications Weight 2.7 kg (6 lb) Hull Deadrise 8° to 15° hull deadrise Acoustic Window Urethane Hole Size 98 mm (3-7/8") One internal ceramic assembly

Read more less

Airmar SS175C-12-HW 12d TiltHigh Wide CHIRP with Garmin 8-PinModel: SS175C-12-HW Depth and fast-response water-temperature sensor 1 kW with a maximum depth of 152 m (500') High Frequency: 150 kHz to 250 kHz = Constant 25° beamwidth 100 kHz of total bandwidth from one transducer Covers popular fishing frequency of 200 kHz plus everything else in the bandwidth High frequency provides superior shallow water performance, bottom detail and fish target separation High wide beamwidth provides more coverage under the boat for detecting fish in the upper water column Low-profile thru-hull housing provides good resolution at speed when installed properly Stainless steel housing for use on stepped, planing or displacement hulls made of fiberglass, wood or metal Recommended boat size: Up to 11 m (36') Also available in transom-mount (TM185HW), in-hull (M285HW) and bronze housing (B175HW) models Exclusive Xducer ID® technology Get more coverage under your boat with Airmar’s unique wide beam, high frequency Chirp-ready transducers. The high band operates across a frequency range of 150 to 250 kHz and has a fixed 25° beam for all frequencies. The high frequency band results in superior resolution. The constant wide beamwidth provides twice the coverage under the boat and excellent fish arches on the display compared to most high frequency narrow beam transducer options.The high wide is the ideal choice for both inshore and pelagic fishing, where resolution and maximum coverage under the boat are essential down to 500'.Tilted element transducers have the element fixed at either a 20°, 12° or 0° angle within the transducer housing. Because the transducer is installed almost flush to the hull, when the transducer is installed the tilt corrects for the hull deadrise and orients the ceramic element horizontally to assure maximum echo returns to the transducer.Specifications Weight 2.7 kg (6 lb) Hull Deadrise 8° to 15° hull deadrise Acoustic Window Urethane Hole Size 98 mm (3-7/8") One internal ceramic assembly
