Garmin GPSMAP® 923xsv SideVü, ClearVü and Traditional CHIRP Sonar with Worldwide Basemap with GMR18 HD3 Radar DomeModel: 010-02366-52 Easily integrate with more engines. Connect to compatible third-party devices with OneHelm™ digital switching. Easily build your marine system using the best of network connectivity. Compatible with premium maps and charts for the best in Garmin navigation. See below your boat with built-in sonar capabilities. Manage your marine experience from nearly anywhere2. With 50% more touchscreen pixels and nearly double the processing power of previous-generation 9" GPSMAP devices, this crisp chartplotter/sonar combo with high-resolution IPS display integrates seamlessly into your Garmin marine system.Get built-in Ultra High-Definition SideVü and ClearVü scanning sonars with vivid, high-contrast color palettes to help distinguish fish from structure. GPSMAP 923xsv also supports 1 kW CHIRP traditional sonar capabilities.Pair with Panoptix or Panoptix LiveScope™ easy-to-interpret live sonar (transducer sold separately) to see all around your boat in real time.With its added processing power and new slimline design featuring edge-to-edge glass and a smaller unit footprint, it’s easy to retrofit this 9" plotter in a wider range of dash configurations.New higher-resolution 9" IPS displays offer improved sunlight readability and visibility from any angle, with 50% more pixels than previous-generation 9" GPSMAP devices.These optional charts offer the best of Garmin and Navionics® data, Auto Guidance3 technology and other premium navigation features.This exclusive feature brings together all the operations and capabilities of select third-party devices, such as EmpirBus™ digital switching, on one screen.If you have multiple compatible Garmin devices on your boat, you can share information — such as maps, user data, radar and IP camera video — among them.Connect to compatible autopilots, digital switching, weather, Fusion-Link™ audio system, media, VHF, AIS and more from one screen.Built-in Wi-Fi® connectivity pairs with the free all-in-one mobile app for access to the OneChart™ feature, smart notifications, software updates, Garmin Helm™ digital switching, Garmin Quickdraw™ Community data and more4.Connect with some of your favorite devices, such as quatix® marine watches, gWind™ Wireless 2 transducers, GNX™ Wind marine instruments and wireless remote controls.Now you can connect your chartplotter to different kinds of engines, including select Yamaha engines.Specifications General PHYSICAL DIMENSIONS 9.2" x 6.4" x 3" (23.3 x 16.2 x 7.6 cm) DISPLAY SIZE 7.8" x 4.4"; 9.0" diagonal DISPLAY RESOLUTION 1280 x 720 pixels DISPLAY TYPE WXGA display WEIGHT 3.6 lbs (1.6 kg) WATER RATING IPX7 POLARIZED SUPPORT Yes POWER CONSUMPTION Max power usage at 10 Vdc: 22 W Typical current draw at 12 Vdc: 1.3 A Max current draw at 12 Vdc: 1.8 A ANTENNA Internal or external over NMEA 2000 MOUNTING OPTIONS Bail, flush or flat RECEIVER 10 Hz high-sensitivity GARMIN MARINE NETWORK™ PORTS 1 TRANSMIT POWER 1 kW traditional; 1 kW CHIRP Maps & Memory PRELOADED MAPS worldwide basemap ACCEPTS DATA CARDS 2 microSD™ cards (back of unit) WAYPOINTS 5,000 TRACK LOG 50,000 points; 50 saved tracks ROUTES 100 Outdoor Recreation TIDE TABLES Yes Chartplotter Features GARMIN RADAR COMPATIBLE Yes GARMIN SONAR COMPATIBLE Yes (built-in) GARMIN SMARTMODE COMPATIBLE (CUSTOMIZABLE MONITOR PRESETS) Yes SUPPORTS AIS (TRACKS TARGET SHIPS POSITION) Yes SUPPORTS DSC (DISPLAYS POSITION DATA FROM DSC-CAPABLE VHF RADIO) Yes SUPPORTS FUSION-LINK™ COMPATIBLE RADIOS Yes GSD™ BLACK BOX SONAR SUPPORT Yes GCV™ BLACK BOX SONAR SUPPORT Yes ACTIVECAPTAIN COMPATIBLE Yes GRID™ (GARMIN REMOTE INPUT DEVICE) COMPATIBLE Yes WIRELESS REMOTE COMPATIBLE Yes SAILING FEATURES Yes Sonar Features & Specifications DUAL-FREQUENCY (50/200 KHZ) SONAR CAPABLE Yes DUAL-BEAM (77/200 KHZ) SONAR CAPABLE Yes FREQUENCIES SUPPORTED Traditional: 50/77/83/200 kHz CHIRP (low, medium, high) ClearVü (260/455/800 kHz) (dependent on transducer) CHIRP SONAR TECHNOLOGY Yes (Built-in) CLEARVü Yes with CHIRP (built-in) SIDEVü Yes with CHIRP (built-in) MAXIMUM DEPTH 5,000 ft at 1kW (depth capacity is dependent on water bottom type and other water conditions) BOTTOM LOCK (SHOWS RETURN FROM THE BOTTOM UP) Yes WATER TEMPERATURE LOG AND GRAPH Yes SONAR RECORDING Yes SONAR HISTORY REWIND Yes Connections NMEA 2000® COMPATIBLE Yes TRANSDUCER PIN NUMBERS 12-pin (orange) NMEA 0183 INPUT PORTS 1 (Differential) NMEA 0183 OUTPUT PORTS 1 (Differential) VIDEO INPUT PORTS 1 BNC WIRELESS CONNECTIVITY Yes J1939 COMPATIBLE Yes What's in the Box: GPSMAP 923xsv chartplotter microSD™ card preinstalled Power cable NMEA 2000® T-connector NMEA 2000 drop cable (2 meters) Bail mount kit with knobs Flush mount kit with gasket Protective cover Trim piece snap covers Documentation 8-pin transducer to 12-pin sounder adapter cable GMR 18 HD3 radome Mounting hardware kit Power cable (15 m) Network cable (15 m) Installation instructions

Read more less

Garmin GPSMAP® 1022 10-inch Chartplotter LIVESCOPE Plus BundleModel: 010-01740-00/LVS34UPC: 753759168308 10-inch color display with keypad interface and multifunction control knob High-sensitivity internal 10 Hz GPS and GLONASS receiver Fully network capable for Garmin Marine Network and NMEA 2000® plus NMEA 0183 support Supports optional BlueChart® g3 Vision® premium charts GPSMAP 1022 is designed for cruisers, sailors and sailing racers who need the advanced all-in-1 solution provided by our 10-inch keyed chartplotter. Features a large, bright screen coupled with a quick and easy-to-use keypad interface with user-programmable keys and a multifunction control knob.Garmin Marine Network support allows sharing of sonar, maps, user data, dome or open-array radar, IP cameras and Panoptix™ sonar among multiple units. Includes NMEA 2000 network connectivity and NMEA 0183 support for autopilots, digital switching, weather, FUSION-Link, VHF, AIS and other sensors.Built in Wi-Fi gives you access to the free all-in-one ActiveCaptain™ app, so you can manage your marine experience from nearly anywhere. It creates a simple yet powerful connection between your compatible mobile device and your Garmin chartplotter, charts, maps and the boating community. Wherever you are, you’ll have unlimited access to your cartography, the ability to purchase new maps and charts and access to the Garmin Quickdraw™ Contours Community. Stay connected with smart notifications on your chartplotter screen. You can also plan a trip or prefish a lake, and ActiveCaptain will automatically sync with your chartplotter. Even get notifications for software updates, and decide when to download them on your device.Fast, responsive built-in 10 Hz GPS and GLONASS receiver refreshes your position and heading 10 times each second to make your movement on the screen more fluid. It makes dropping up to 5,000 accurate waypoints — and finding your way back to them — quick and easy.Upgrade to optional premium BlueChart g3 Vision charts and LakeVü g3 Ultra maps. These add features such as high-resolution relief shading of bottom structure — which provides more 3-D relief than contours alone — satellite imagery and more.To help you gain a wind-maximizing competitive edge, your chartplotter features a pre-race guidance page that shows your virtual starting line along with data fields showing laylines, time to burn before the start and a race timer that can be synchronized across all your networked Garmin GPS products. In addition, other supported sailing features include an enhanced wind rose, heading and course-over-ground lines, set and drift, true and apparent wind data and more.If you have waypoints, tracks or frequently used routes stored on another manufacturer’s GPS product — or on a Garmin handheld device — it’s easy to transfer those items to your new Garmin chartplotter via industry-standard GPX software formatting.Specifications Performance and Physical Dimensions 12.5" x 7.3" x 2.7" (318 x 185 x 69 cm) Display size 8.8" x 4.9" (224 x 125 cm) Display resolution 1024 x 600 Display type WSVGA display Weight 4.1lbs Water rating IPX7 Power consumption Max power usage at 10 Vdc: 32.4 W Antenna Internal or external over NMEA 2000 Mounting options Bail or flush Receiver 10 Hz high-sensitivity Garmin Marine Network™ ports 2 Preloaded maps None Accepts data cards 2 SD™ cards Waypoints 5,000 Routes 100 Track log 50,000 points; 50 saved tracks Tide tables Yes Garmin Radar compatible Yes Garmin Sonar compatible Yes (with external black box, sold separately) Garmin SmartMode compatible (customizable monitor presets) Yes Supports AIS (tracks target ships position) Yes Supports DSC (displays position data from DSC-capable VHF radio) Yes Garmin Meteor™ Audio System compatible Yes Supports FUSION-Link™ compatible radios Yes GSD™ Black Box sonar support Yes GCV™ Black Box sonar support Yes ActiveCaptain compatible Yes Garmin Helm compatible Yes GRID™ (Garmin Remote Input Device) compatible Yes Wireless remote compatible Yes CHIRP sonar technology Yes (with external black box, sold separately) ClearVü Yes (with external black box, sold separately) SideVü Yes (with external black box, sold separately) NMEA 2000® compatible Yes NMEA 0183 input ports 1 NMEA 0183 output ports 1 Video input ports 1 BNC Video output ports None Wireless connectivity Yes What's in the Box: GPSMAP 1022 chartplotter Power/data cable NMEA 2000 T-connector NMEA 2000 drop cable (2 m) Bail mount kit with knobs Flush mount kit with gasket Protective cover Trim piece snap covers Documentation LIVESCOPE Plus

Read more less

Garmin GPSMAP® 1243xsv SideVü, ClearVü and Traditional CHIRP Sonar with Garmin Navionics+ coastal and inland water charts for the U.S. and CanadaModel: 010-02367-61 New high-resolution in-plane switching touchscreen display offers improved sunlight readability and wide-angle visibility over previous-generation 12" units Fast and responsive, this robust GPSMAP® system references 10 Hz GNSS (GPS, GLONASS and Galileo) for accurate positioning and smooth speed as well as COG data Slimline display borders, edge-to-edge glass and reduced unit footprint make for easy retrofit in a wider range of dash configurations Preloaded Garmin Navionics+™ coastal charts and inland mapping feature Auto Guidance+™ technology (Auto Guidance+ is for planning purposes only and does not replace safe navigation operations); plus, there’s support for optional Garmin Navionics Vision+™ premium map content. J1939 engine connectivity for easy integration with engines and our exclusive OneHelm™ feature for connecting to your compatible third-party devices, such as EmpirBus™ digital switching Easily build your marine system — from compatible sonar and autopilots to compatible radar, cameras and multimedia — by using NMEA 2000® and NMEA 0183 network connectivity and the Garmin Marine Network Use built-in Wi-Fi® networking to pair with the free ActiveCaptain® smartphone app for access to the OneChart™ feature, smart notifications, software updates and more. Integrated ANT® connectivity support for use with your compatible quatix® marine smartwatches, gWind™ Wireless 2 transducer, GNX™ Wind marine instrument and wireless remote controls Built-in Ultra High-Definition SideVü™ and ClearVü™ scanning sonars with high-contrast vivid color palettes to help distinguish fish from structure Supports live sonar devices, 1 kW CHIRP traditional sonar and more" Get a sharper view from your connected helm with the GPSMAP® 1243xsv chartplotter. With its high-resolution 12" in-plane switching display, ultrasleek design and vivid sonar color palette, it seamlessly integrates into your Garmin marine system. GPSMAP 1243xsv also features built-in Ultra High-Definition SideVü™ and ClearVü™ scanning sonars and supports 1 kW CHIRP traditional sonar as well as fully networkable radar and live sonar devices. Preloaded Garmin Navionics+™ coastal charts and inland mapping feature Auto Guidance+™ technology (Auto Guidance+ is for planning purposes only and does not replace safe navigation operations) for helping you get where you need to go. Plus, there’s support for optional Garmin Navionics Vision+™ premium map content. Easily build your marine system — from compatible sonar and autopilots to compatible radar, cameras and multimedia — by using HTML 5.0, NMEA 2000® and NMEA 0183 network connectivity, J1939 for engines and the Garmin Marine Network. Or pair your plotter with your other compatible Garmin devices, such as quatix® marine smartwatches, wind transducers, wireless remote controls and more.Specifications General PHYSICAL DIMENSIONS 12.1" x 8.9" x 3.2" (30.8 x 22.8 x 8.2 cm) DISPLAY SIZE 10.3" x 6.4"; 12.1" diagonal DISPLAY RESOLUTION 1280 x 800 pixels DISPLAY TYPE WXGA display WEIGHT 6.6 lbs. (3.0 kg) WATER RATING IPX7 POLARIZED SUPPORT Yes POWER CONSUMPTION Max power usage at 10 Vdc: 26.5 W Typical current draw at 12 Vdc: 1.7 A Max current draw at 12 Vdc: 2.2 A ANTENNA Internal or external over NMEA 2000 MOUNTING OPTIONS Bail, flush or flat RECEIVER 10 Hz high-sensitivity GARMIN MARINE NETWORK™ PORTS 2 TRANSMIT POWER 1 kW traditional; 1 kW CHIRP Maps & Memory PRELOADED MAPS Garmin Navionics+ coastal and inland water charts for the U.S. and Canada ACCEPTS DATA CARDS 2 microSD™ cards (back of unit) WAYPOINTS 5,000 TRACK LOG 50,000 points; 50 saved tracks ROUTES 100 Outdoor Recreation TIDE TABLES Yes Chartplotter Features GARMIN RADAR COMPATIBLE Yes GARMIN SONAR COMPATIBLE Yes (built-in) GARMIN SMARTMODE COMPATIBLE (CUSTOMIZABLE MONITOR PRESETS) Yes SUPPORTS AIS (TRACKS TARGET SHIPS POSITION) Yes SUPPORTS DSC (DISPLAYS POSITION DATA FROM DSC-CAPABLE VHF RADIO) Yes SUPPORTS FUSION-LINK™ COMPATIBLE RADIOS Yes GSD™ BLACK BOX SONAR SUPPORT Yes GCV™ BLACK BOX SONAR SUPPORT Yes ACTIVECAPTAIN COMPATIBLE Yes GRID™ (GARMIN REMOTE INPUT DEVICE) COMPATIBLE Yes WIRELESS REMOTE COMPATIBLE Yes SAILING FEATURES Yes Sonar Features & Specifications DUAL-FREQUENCY (50/200 KHZ) SONAR CAPABLE Yes DUAL-BEAM (77/200 KHZ) SONAR CAPABLE Yes FREQUENCIES SUPPORTED Traditional: 50/77/83/200 kHz CHIRP (low, medium, high) ClearVü (260/455/800 kHz) (dependent on transducer) CHIRP SONAR TECHNOLOGY Yes (Built-in) CLEARVü Yes with CHIRP (built-in) SIDEVü Yes with CHIRP (built-in) MAXIMUM DEPTH 5,000 ft at 1kW (depth capacity is dependent on water bottom type and other water conditions) BOTTOM LOCK (SHOWS RETURN FROM THE BOTTOM UP) Yes WATER TEMPERATURE LOG AND GRAPH Yes SONAR RECORDING Yes SONAR HISTORY REWIND Yes Connections NMEA 2000® COMPATIBLE Yes TRANSDUCER PIN NUMBERS 12-pin (orange) NMEA 0183 INPUT PORTS 1 NMEA 0183 OUTPUT PORTS 1 VIDEO INPUT PORTS 1 BNC VIDEO OUTPUT PORTS 1 HDMI WIRELESS CONNECTIVITY Yes J1939 COMPATIBLE Yes What's in the Box: GPSMAP 1243xsv chartplotter Garmin Navionics+ coastal and inland water charts for the U.S. and Canada microSD™ card preinstalled Power cable NMEA 2000® T-connector NMEA 2000 drop cable (2 meters) Bail mount kit with knobs Flush mount kit with gasket Protective cover Trim piece snap covers Documentation 8-pin transducer to 12-pin sounder adapter cable

Read more less

Garmin GMR Fantom™ 24x, BlackModel: 010-02585-10 GMR Fantom brings the power. Fifty watts of it, actually. See targets clearly, and adjust their sizes as needed. With power save mode, you get to choose when to use full power and when to pull back. Every second of power usage counts. Cut back even more by choosing your active times down to the second. MotionScope™ technology shows targets in color as they move toward you or away. Tailor your 50-watt solid-state dome radar to your boat with a white or black option — both with a range from 20’ to 48 nautical miles, even in fog or rain, and up to 60 RPM rotation speed for a refresh rate that can detect movement at any speed.High-resolution images and high antenna gain help to pick out targets at a distance, while 8-bit true color imagery enhances target separation.MotionScope uses the Doppler effect to detect moving targets and highlight them in different colors, so you can navigate around other boats or severe weather — or toward fishing spots where birds feed at the surface.The power save feature lets you choose when you need more power or less, so you have power when you need it and conserve it when you don’t.Boaters and sailors can specify transmit times down to the seconds instead of minutes, allowing for reduced power consumption.These radars don’t have any complex user settings to deal with, so they’re easy to install and start using.Adjust on-screen target resolution for better separation based on your surroundings.Adjust on-screen target resolution for better separation based on your surroundings.See a historical "trail" on the screen to help you quickly and easily identify moving targets and potential collision threats.The single radar antenna can provide split-screen images on your chartplotter side by side, with independent range setting and controls for both close and long range.Using dual radar provides redundancy and allows each display unit on the boat to pull data from one of two different radar sources.This feature automatically adjusts to your surroundings for optimal performance in all conditions.Gain automatically adjusts sea clutter for calm, medium and rough sea conditions.Overlay radar images onto your chartplotter’s map page. You can add an optional autopilot or heading sensor (sold separately) for best results.New mini-automatic radar plotting aid (MARPA) automatic acquisition allows for triggering and tracking of up to 30 targets with no user prompting on all returns, boundary zones, guard zones or MotionScope technology.Set the safety zone and receive an alarm when an object enters the zone.Variable range markers (VRM) and electronic bearing lines (EBL) allow rapid measurements of distance and bearing to vessels and land.Specifications General DIMENSION 25.4" x 9.8" (64.5 cm x 24.9 cm) WEIGHT 17.4 lbs WATERPROOF IPX7 ANTENNA LENGTH 23" (58.42 cm) ROTATION SPEED (RPM) Up to 60 rpm, depending on settings BEAM WIDTH 3.7° horizontal, 25° vertical 5.2° horizontal, 25° vertical 48 nm MINIMUM RANGE 6 meters RADAR TYPE Radome Electrical Features POWER INPUT 10-32 V DC POWER CONSUMPTION 4 W MAX POWER CONSUMPTION TRANSMITTING, POWER SAVE 24 W MAX POWER CONSUMPTION TRANSMITTING, NORMAL MODE 33 W TRANSITION POWER 50 W Radar Features DUAL RANGE SUPPORT Yes RADAR OVERLAY SUPPORT Yes DUAL RADAR Yes AUTOBIRD Yes DYNAMIC AUTO GAIN Dynamic MARPA TARGET TRACK Yes (Requires Heading Sensor, Sold Separately) ECHO TRAIL Yes MOTIONSCOPE Yes TARGET SIZE Yes SCAN Yes What's in the Box: GMR Fantom 24x - White Power cable (15 m/49.21 ft) Network cable (15 m/49.21 ft) Installation instructions Mounting hardware kit and template

Read more less

Garmin GPSMAP® 1223xsv SideVü, ClearVü and Traditional CHIRP Sonar with Worldwide BasemapModel: 010-02367-02 Easily integrate with more engines. Connect to compatible third-party devices with OneHelm™ digital switching. Easily build your marine system using the best of network connectivity. Navigate any waters with preloaded mapping and coastal charts. See below your boat with built-in sonar capabilities. Manage your marine experience from nearly anywhere. With its sleek design, powerful processing and upgraded IPS display, this advanced 12" chartplotter/sonar combo integrates seamlessly into your Garmin marine system.Get built-in Ultra High-Definition SideVü and ClearVü scanning sonars with vivid, high-contrast color palettes to help distinguish fish from structure. GPSMAP 923xsv also supports 1 kW CHIRP traditional sonar capabilities.Pair with Panoptix or Panoptix LiveScope™ easy-to-interpret live sonar (transducer sold separately) to see all around your boat in real time.With its ultrasleek design, vivid sonar color palette and high-resolution 12" in-plane switching display, this large format chartplotter/sonar combo offers improved sunlight readability and wide-angle visibility.If you have multiple compatible Garmin devices on your boat, you can share information — such as maps, user data, radar and IP camera video — among them.Connect to compatible autopilots, digital switching, weather, Fusion-Link™ audio system, media, VHF, AIS and more from one screen.Built-in Wi-Fi® connectivity pairs with the free all-in-one mobile app for access to the OneChart™ feature, smart notifications, software updates, Garmin Helm™ digital switching, Garmin Quickdraw™ Community data and more.Connect with some of your favorite devices, such as quatix® marine watches, gWind™ Wireless 2 transducers, GNX™ Wind marine instruments and wireless remote controls.Now you can connect your chartplotter to different kinds of engines, including select Yamaha engines.This exclusive feature brings together all the operations and capabilities of select third-party devices, such as EmpirBus™ digital switching, on one screen.Connect with some of your favorite devices, such as quatix® marine watches, gWind™ Wireless 2 transducers, GNX™ Wind marine instruments and wireless remote controls.Now you can connect your chartplotter to different kinds of engines, including select Yamaha engines.This exclusive feature brings together all the operations and capabilities of select third-party devices, such as EmpirBus™ digital switching, on one screen.Specifications General PHYSICAL DIMENSIONS 12.1" x 8.9" x 3.2" (30.8 x 22.8 x 8.2 cm) DISPLAY SIZE 10.3" x 6.4"; 12.1" diagonal DISPLAY RESOLUTION 1280 x 800 pixels DISPLAY TYPE WXGA display WEIGHT 6.6 lbs. (3.0 kg) WATER RATING IPX7 POLARIZED SUPPORT Yes POWER CONSUMPTION Max power usage at 10 Vdc: 26.5 W Typical current draw at 12 Vdc: 1.7 A Max current draw at 12 Vdc: 2.2 A ANTENNA Internal or external over NMEA 2000 MOUNTING OPTIONS Bail, flush or flat RECEIVER 10 Hz high-sensitivity GARMIN MARINE NETWORK™ PORTS 2 TRANSMIT POWER 1 kW traditional; 1 kW CHIRP Maps & Memory PRELOADED MAPS worldwide basemap ACCEPTS DATA CARDS 2 microSD™ cards (back of unit) WAYPOINTS 5,000 TRACK LOG 50,000 points; 50 saved tracks ROUTES 100 Outdoor Recreation TIDE TABLES Yes Chartplotter Features GARMIN RADAR COMPATIBLE Yes GARMIN SONAR COMPATIBLE Yes (built-in) GARMIN SMARTMODE COMPATIBLE (CUSTOMIZABLE MONITOR PRESETS) Yes SUPPORTS AIS (TRACKS TARGET SHIPS POSITION) Yes SUPPORTS DSC (DISPLAYS POSITION DATA FROM DSC-CAPABLE VHF RADIO) Yes SUPPORTS FUSION-LINK™ COMPATIBLE RADIOS Yes GSD™ BLACK BOX SONAR SUPPORT Yes GCV™ BLACK BOX SONAR SUPPORT Yes ACTIVECAPTAIN COMPATIBLE Yes GRID™ (GARMIN REMOTE INPUT DEVICE) COMPATIBLE Yes WIRELESS REMOTE COMPATIBLE Yes SAILING FEATURES Yes Sonar Features & Specifications DUAL-FREQUENCY (50/200 KHZ) SONAR CAPABLE Yes DUAL-BEAM (77/200 KHZ) SONAR CAPABLE Yes FREQUENCIES SUPPORTED Traditional: 50/77/83/200 kHz CHIRP (low, medium, high) ClearVü (260/455/800 kHz) (dependent on transducer) CHIRP SONAR TECHNOLOGY Yes (Built-in) CLEARVü Yes with CHIRP (built-in) SIDEVü Yes with CHIRP (built-in) MAXIMUM DEPTH 5,000 ft at 1kW (depth capacity is dependent on water bottom type and other water conditions) BOTTOM LOCK (SHOWS RETURN FROM THE BOTTOM UP) Yes WATER TEMPERATURE LOG AND GRAPH Yes SONAR RECORDING Yes SONAR HISTORY REWIND Yes Connections NMEA 2000® COMPATIBLE Yes TRANSDUCER PIN NUMBERS 12-pin (orange) NMEA 0183 INPUT PORTS 1 NMEA 0183 OUTPUT PORTS 1 VIDEO INPUT PORTS 1 BNC VIDEO OUTPUT PORTS 1 HDMI WIRELESS CONNECTIVITY Yes J1939 COMPATIBLE Yes What's in the Box: GPSMAP 1223xsv chartplotter microSD™ card preinstalled Power cable NMEA 2000® T-connector NMEA 2000 drop cable (2 meters) Bail mount kit with knobs Flush mount kit with gasket Protective cover Trim piece snap covers Documentation 8-pin transducer to 12-pin sounder adapter cable

Read more less

Garmin ECHOMAP UHD2 93sv LIVESCOPE Plus, U.S. inland with GT56 transducerModel: 010-02688-01/LVS34 Easy-to-use 9" chartplotter with a bright, sunlight-readable touchscreen display with improved detail, clarity and viewing angle Built-in Garmin Navionics+™ inland maps with integrated Navionics® data cover more than 18,000 lakes with up to 1’ contours Built-in Wi-Fi® connectivity lets you wirelessly share sonar, waypoints and routes with another ECHOMAP UHD2 chartplotter Wirelessly connects to your Force® trolling motor to create and follow routes, navigate to waypoints, control speed, check battery life and more" Included GT56-TM transducer for Garmin traditional, ClearVü™ and SideVü™ scanning sonars The 9" ECHOMAP™ UHD2 touchscreen with keyed-assist chartplotter knows the water better than a local. Its high-resolution display offers improved detail, clarity and viewing angle. See clear, sharp fish arches with Garmin traditional sonar. ClearVü™ and SideVü™ scanning sonars feature vivid color palettes for clear, high-contrast views all around your boat (transducer sold separately). ECHOMAP UDH2 also supports LiveScope™ sonar systems. Navigate the waters with built-in Garmin Navionics+™ cartography. Built-in Wi-Fi® connectivity lets you wirelessly share sonar, waypoints and routes with another ECHOMAP UHD2 chartplotter. Wherever you drop your line, get improved position accuracy, particularly in areas where signals are reflected or weak, with multi-band GPS. You can also pair with the free all-in-one ActiveCaptain® app on your compatible smartphone for access to the OneChart™ feature, software updates and more. The chartplotter supports NMEA 2000® networks to connect your compatible autopilots, digital switching, music, and more to view all on one screen.What's in the Box: ECHOMAP UHD2 92sv GT56 transducer Power cable Tilt mount with quick-release cradle Protective cover Hardware Documentation LIVESCOPE Plus

Read more less

Garmin Force® Current Trolling Motor for KayaksModel: 010-02864-00 LEGENDARY FORCE PERFORMANCE AND RELIABILITY WIRELESS THROTTLE AND STEERING CONTROL WITH THE INCLUDED REMOTE STAY ON THE FISH WITH ANCHOR LOCK AND MULTI-BAND GPS SIMPLE AND INTUITIVE INSTALLATION WIRELESS INTEGRATION WITH GARMIN CHARTPLOTTERS WIRELESS MAN OVERBOARD TAG Use the included remote to control throttle and steering with the wireless remote control. Want to control throttle and steering without setting the rod down? Check out the power steer pedals.Turn your boat quickly with full forward and reverse thrust in any direction. Weave through tight timber, turn in a tight circle, sneak along shorelines, and creep through weed beds while you fish. Use the included wireless handheld remote for point-and-go gesture steering.Wireless integration with your Garmin chartplotters allows you to create routes and tracks for the trolling motor to follow while you fish. You can also adjust throttle and steering on the chartplotter control bar, adjust motor settings and more.The anchor lock technology with multi-band GPS provides our most precise boat positioning technology to help keep the boat in one place, even in windy conditions or strong current.When wearing the included wireless man overboard tag, the motor cuts off if it detects you fall overboard.An efficient brushless motor design has longer run times than brushed motors and allows you to focus on fishing — and not running out of battery.Quickly stow or deploy the prop with one hand when you need to glide over shallow areas with the included stow rope and cleat kit.Connect your compatible Garmin smartwatch to control steering, anchor lock and more from your wrist.Use the high-efficiency prop to maximize battery life, or the weedless prop to cut through aquatic vegetation.The 4-hole mounting pattern makes installation easy on many different types of kayaks. The wireless foot pedals and rail system are also designed to accommodate a wide variety of installation methods.Get on and off the water fast with simple motor and pedal installation and removal.Don’t spook the fish; the motor is extremely quiet above and below the water.The sturdy alloy shaft and components are built to endure harsh saltwater and freshwater environments with advanced corrosion protection.Specifications General Color black For use in freshwater, brackish water and saltwater Mount style 4-hole tilt mount Max thrust 50 lbs (ISO13342) using high efficiency propeller at 24 V30 lbs (ISO13342) using high efficiency propeller at 12 V Voltage 12 V or 24 V Electric steering Yes Built-in heading sensor Yes Built-in GPS yes (dual frequency GPS) Warranty 3-year, limited lifetime on shaft Water rating IPX7 Mounting location stern Wireless remote yes (included) Shaft length (from mount to top of drive motor) 16.6" (max); 11.4" (min) Power steer foot pedals (kayak) compatible Yes(not included) Battery indicator Yes Variable speed control yes (20 steps) quatix remote control supported Yes Manual reverse control Yes Autopilot Features Route following Yes Anchor lock Yes Smart Anchor Lock features Yes Anchor lock jog Yes Heading hold Yes Cruise control Yes Gesture features yes (manual+, heading hold+, jog+) Remote Features Display size 1.2" (30.2 mm) diameter Display resolution 240 x 240 pixels Display type color, sunlight-visible, transflective memory-in-pixel (MIP) Chartplotter user-programmable keys Yes Autopilot feature control Yes Water rating IPX7 Battery life typical use with backlight at low, 43 weeks Floats Yes What's in the Box: Force® Kayak Propulsion System Documentation Force trolling motor remote with lanyard Black MOB tag Power cable Pull rope and cleat Skeg Performance propeller Weedless propeller Mounting hardware

Read more less

Garmin ECHOMAP™ Ultra 2 106sv 10" Chartplotters without Transducer; Includes Garmin Navionics+™ U.S. Inland & Coastal MappingModel: 010-02880-10 SUPPORTS LIVESCOPE™ SONAR1 AND MORE WIRELESSLY NETWORK; SHARE SONAR, WAYPOINTS AND ROUTES2 CAPTURE SCREEN RECORDINGS TO SHARE FISH CATCHES MULTI-BAND GPS FOR IMPROVED POSITION ACCURACY With big, crisp, sunlight-readable touchscreen displays, these versatile chartplotters put a world of fishfinding capability at your fingertips. They’re available with built-in Garmin Navionics+™ mapping, and the transducer bundle adds Ultra High-Definition scanning sonars as well as CHIRP traditional sonar.The ECHOMAP Ultra 2 series supports the full lineup of LiveScope live-scanning sonar products (transducers sold separately).High-contrast vivid scanning sonar color palettes make it easier than ever to distinguish targets and structure.Bring a fresh new look and feel to your chartplotter with optional Garmin Navionics Vision+™ premium mapping (sold separately), featuring high-resolution relief shading, satellite imagery and more.If you have another compatible ECHOMAP Ultra 2 or ECHOMAP UHD2 chartplotter on your boat, you can wirelessly share information — such as sonar3, waypoints and routes — with them.1LiveScope™ System sonar transducer sold separately 2Via one-to-one unit wireless connection only 3LiveScope sonar cannot be shared wirelessly between two ECHOMAP Ultra 2 or ECHOMAP UHD2 chartplotters 4Requires the ActiveCaptain app on your compatible smartphone paired to your ECHOMAP Ultra 2 series chartplotterSpecifications General DIMENSION 11.6" x 7.7" x 3.9" (29.5 x 19.5 x 9.8 cm) WEIGHT 4.0 lbs (1.8 kg) WATERPROOF IPX7 TOUCHSCREEN Yes DISPLAY TYPE WXGA, IPS DISPLAY SIZE 8.5" x 5.4"; 10" diagonal (21.7 x 13.6 cm; 25.4 cm diagonal) DISPLAY RESOLUTION 1280 x 800 pixels MOUNTING OPTIONS Bail or flush INPUT Touchscreen with Keyed Assist Maps & Memory ACCEPTS DATA CARDS 2 microSD cards WAYPOINTS 5000 TRACK POINTS 50,000 TRACKS 50 saved tracks NAVIGATION ROUTES 100 Sensors GPS Yes GLONASS Yes GALILEO Yes BEIDOU Yes HAS BUILT-IN RECEIVER Yes RECEIVER 10 Hz NMEA 2000 COMPATIBLE Yes NMEA 0183 COMPATIBLE Yes SUPPORTS WAAS Yes SUPPORTS MULTI-BAND, MULTI-CONSTELLATION GPS Yes Built-in Maps BUILT-IN AUTO GUIDANCE+ Yes GARMIN NAVIONICS+ INLAND & COASTAL Garmin Navionics+™ U.S. Inland & Coastal Mapping TIDE TABLES yes Optional Map Support BLUECHART G3 Yes BLUECHART G3 VISION Yes LAKEVü G3 Yes LAKEVü G3 ULTRA Yes GARMIN NAVIONICS+™ Yes GARMIN NAVIONICS VISION+™ Yes TOPO 100K Yes STANDARD MAPPING Yes GARMIN QUICKDRAW CONTOURS Yes Electrical Features POWER INPUT 9 to 18 Vdc TYPICAL CURRENT DRAW AT 12 VDC 2.3 A MAXIMUM CURRENT DRAW AT 12 VDC 5.0 A MAXIMUM POWER USAGE AT 10 VDC 34 W Connections NMEA 2000® PORTS 1 GARMIN MARINE NETWORK PORTS 2 (large connector) 12-PIN TRANSDUCER PORTS 12-pin scanning sonar ANT+ (CONNECTIVITY) Yes GARMIN WI-FI NETWORK (LOCAL CONNECTION) Yes Sonar Features DISPLAYS SONAR Yes POWER OUTPUT 600 watt TRADITIONAL SONAR (DUAL FREQUENCY/BEAM) built-in (single channel CHIRP, 70/83/200 kHz, L, M, H CHIRP) CLEARVü built-in 260/455/800/1000/1200 kHz SIDEVü built-in 260/455/800/1000/1200 kHz PANOPTIX™ SONAR Yes LIVESCOPE Yes What's in the Box: ECHOMAP Ultra 106sv; Includes Garmin Navionics+™ U.S. Inland & Coastal Mapping Power/data cable Bail mount with quick release cradle Protective sun cover 8-pin transducer to 12-pin sounder adapter cable Hardware Documentation GLS10 Black box LVS34 Transducer Perspective mount Trolling motor barrel mount

Read more less

Garmin GSD28 Sonar ModuleModel: 010-02797-00 High-powered sonar black box engineered for superior sport fishing at extreme depths Next-generation xCHIRP sonar technology provides our clearest fish arches for excellent target separation, smooth bottom returns and precise targeting Garmin RapidReturn™ sonar is our the fastest deep-water scrolling sonar Garmin RapidReturn™ sonar fills the sonar screen faster, allowing a captain to make fast and informed decisions based on what is below their boat Add the MSC™ 10 external satellite compass (sold separately) to eliminate wave and swell from your sonar returns with heave compensation Compatible with a wide range of Garmin and AIRMAR® transducers (sold separately) Ideal for retrofitting to boats with existing bare wire transducers by using manual configuration settings Can output 300 watts to 3 kW with a maximum depth of 10,000’ (transducer-dependent) Supports dual-channel CHIRP (up to 3 kW per channel) 25 to 250 kHz frequency range (transducer dependent) Rated for harsh marine environments and water-resistance with an IPX7 rating The depths. Revealed. Take your sport fishing to extreme depths with GSD™ 28, a high-powered sonar module with features to improve your chances for success (transducer-dependent). Garmin RapidReturn™ sonar provides quicker returns on your chartplotter with 2 to 6 times the ping rate of our GSD 26, so you see fish before you’re out of range (transducer-dependent). Easily distinguish bait from sport fish, and get our clearest sonar with next-generation xCHIRP technology. GSD 28 supports a wide range of Garmin and AIRMAR® transducers (sold separately) that can be manually or automatically configured. When the seas get rough, ensure flat bottom returns with the MSC™ 10 external heave compensation sensor (sold separately).The GSD 28 module is ideal for retrofitting to boats with existing bare wire transducers.Specifications General Case material Fully gasketed, aluminum housing, steel back panel, plastic access panel Physical dimensions 10.7" 14.4" 4.0" (27.06 cm 36.66 cm 10.1 cm) Weight 14.13 lbs (6.4 kg) Water rating IPX7 Temperature range From 5° F to 158° F (from -15° C to 70° C) Electrical Features Power input 10-32 V Power usage 120 W maximum Fuse 15A Sonar Features Frequencies supported Dual channel CHIRP: 25-250 kHz (tranducer dependant) Transmit power 300W—3kW rms (transducer dependant) 300W—3kW rms (transducer dependant) 10,000 ft (3,048 m) xCHIRP Yes Rapid return Yes Connections Garmin Marine Network Ports 1 (Garmin BlueNet) Sonar connections 2 bare wire What's in the Box: GSD 28 Power cable Garmin BlueNet™ marine network cable (6 ft) with legacy network adapter Field installable adapter kit for the Garmin BlueNet network Mounting hardware Documentation

Read more less

Garmin GPSMAP8610xsv 10" Chartplotter/Sonar Combo with Full HD In-plane Switching (IPS) Touchscreen and Garmin Navionics+ coastal and inland water charts for the U.S. and CanadaModel: 010-02091-51 Features a 10" full HD in-plane switching touchscreen display for wider viewing angles, superior clarity and sunlight readability, even with polarized sunglasses Built-in support for the full suite of Garmin sonar capabilities, including CHIRP traditional, ClearVü™ and SideVü™ scanning sonars, Ultra High-Definition scanning sonar (no black box required), the LiveScope™ System and the full-line of live sonar products (transducers sold separately) Adds a stunning appearance with ability to install multiple displays either flat mounted edge-to- edge to create a sleek glass helm look or mounted flush Fully network capable with NMEA 2000® connectivity and the Garmin Marine Network to easily build your marine system — from sonar, radar and autopilots to instruments, cameras and multimedia ANT® connectivity and Wi-Fi® networking let you connect with your compatible quatix® smartwatches, gWind™ Wireless 2 wind sensor and more See RPMs, fuel flow, temperature, trim and more for up to four of your compatible Mercury® engines by using the SmartCraft® Connect gateway For full control of your boat on your chartplotter screen, use our exclusive OneHelm™ feature to connect to many third-party devices Preloaded Garmin Navionics+™ coastal charts and inland mapping feature Auto Guidance+™ technology (Auto Guidance+ is for planning purposes only and does not replace safe navigation operations); plus, there’s support for optional Garmin Navionics Vision+™ premium map content. SmartMode™ station controls enable presets for one-touch access to docking, cruising, fishing, anchoring and more Built-in Garmin SailAssist™ features provide data, displays and prerace guidance needed to gain a competitive edge Use built-in Wi-Fi® networking to pair with the free ActiveCaptain® smartphone app for access to the OneChart™ feature, smart notifications, Garmin Quickdraw™ Community data and more. Dual microSD™ card slots on back of unit for use with the ActiveCaptain® app and cartography cards The GPSMAP® 8610xsv chartplotter features a 10" full HD in-plane switching touchscreen display for wider viewing angles, superior clarity and sunlight readability, even with polarized sunglasses. It offers built-in support for our industry-leading sonar , including dual-channel 1 kW traditional CHIRP, CHIRP ClearVü™ and CHIRP SideVü™ scanning sonars plus built-in support for Ultra High-Definition scanning (no black box required). It also supports Panoptix™ and LiveScope™ sonar products and a wide range of other transducers (sold separately). The device is preloaded with Garmin Navionics+™ coastal charts and inland mapping that feature Auto Guidance+™ technology (Auto Guidance+ is for planning purposes only and does not replace safe navigation operations) for confidence in helping you get where you need to go. Plus, there’s support for optional Garmin Navionics Vision+™ premium map content. Experience superior connectivity and networking solutions with complete control of your entire system, right at your fingertips. The chartplotter includes a premium-performance processor for our fastest map drawing, superior networking, video distribution and more. Multiple displays can be flat mounted edge-to-edge to create a sleek glass helm look or mounted flush. NMEA 2000® networking and the Garmin Marine Network allow you to build your full marine electronics suite — from radar and autopilots to cameras and instruments — controlled from your chartplotter and shared across multiple screens. With SmartMode™ station controls, everything is designed to give you quick, one-touch access to the information you need to ease high-stress situations such as docking. For full control of your boat on your chartplotter screen, use the OneHelm™ feature to connect to many compatible third-party devices. Built-in Garmin SailAssist™ features provide data, displays and prerace guidance to help you gain a competitive edge. Download the ActiveCaptain® app to your compatible smartphone or tablet to manage your marine experience--from trip planning and prefishing to purchasing, downloading and updating maps. See RPMs, fuel flow, temperature, trim and more for up to four compatible Mercury® engines by using the SmartCraft® Connect gateway.Specifications General Physical dimensions 10.25" x 8.0625" x 2.95" (25.9 cm x 20.5 cm x 7.5 cm) Weight 5.2 lbs (2.4kg) Water rating IPX6 and IPX7 Display type touchscreen IPS display (anti-glare finish) Display size 8.6" x 5.4" (21.8 cm x 13.7 cm) Display resolution WUXGA; 1920 x 1200 pixels Power consumption 2.7 A Antenna Internal or external over NMEA 2000 Mounting options Bail, flat or flush (Garmin do not offer any hardware or accessories for a flat-mount installation. Professional tools and knowledge is required.) Receiver 10 Hz GPS/GLONASS/Galileo Garmin Marine Network™ ports 2 Maps & Memory Accepts data cards 2 microSD cards (on back) Waypoints 5,000 Routes 100 (250 waypoints each) Track log 50,000 points; 50 saved tracks pre-loaded maps Garmin Navionics+ coastal and inland water charts for the U.S. and Canada Outdoor Recreation Features Tide tables Yes Chartplotter Features Garmin Radar compatible Yes Garmin Sonar compatible Yes Garmin SmartMode compatible (customizable monitor presets) Yes Supports AIS (tracks target ships position) Yes Supports DSC (displays position data from DSC-capable VHF radio) Yes Supports FUSION-Link™ compatible radios Yes GSD™ Black Box sonar support Yes GCV™ Black Box sonar support Yes ActiveCaptain compatible Yes Garmin Helm compatible Yes GRID™ (Garmin Remote Input Device) compatible Yes Wireless remote compatible Yes Sonar Features & Specifications Dual-frequency (50/200 kHz) sonar capable Yes Dual-beam (77/200 kHz) sonar capable Yes Frequencies supported Regular Traditional: 50/200, 77/200, 83/200 Single Channel CHIRP: 40-250 Dual Channel CHIRP: 40-250 SideVü/ClearVü: CHIRP 260/455/800(dependent on transducer) Frequencies supported Ultra High Definition Ultra High-Definition ClearVü: 0.8 MHz (800 kHz), CHIRP range: 760-880 kHzUltra High-Definition SideVü: 1.2 MHz (1,200 kHz), CHIRP range: 1,060-1,170 kHz(dependent on transducer) Transmit power 1 kW traditional; 1 kW CHIRP CHIRP sonar technology Yes (Built-in) ClearVü Yes SideVü Yes Maximum depth 5,000 ft at 1kW (depth capacity is dependent on water bottom type and other water conditions) Connections NMEA 2000® compatible Yes Transducer pin numbers 1 — LVS sonar, 1 — 12 pin scanning sonar, 1- 8 pin sonar NMEA 0183 input ports 1 differential NMEA 0183 output ports 1 differential Video input ports 1 - BNC composite1 - HDMI (HDCP compliant) Video output ports 1 HDMI Wireless connectivity Yes What's in the Box: GPSMAP 8610xsv Garmin Navionics+ coastal and inland water charts for the U.S. and Canada Power cable NMEA 2000® drop cable NMEA 2000 T-connector Bail mount with knobs Flush mount kit Sun cover Trim piece snap covers Documentation

Read more less

Garmin Compact Reactor™ 40 Kicker Autopilot With GHC™ 50 Autopilot Instrument and Stainless Steel Tilt TubeModel: 010-02794-10 This Reactor 40 kicker autopilot is the perfect companion for your small gasoline-powered boat. Sit back and relax. With this autopilot, you can maintain heading hold and stay on course. You’re not just getting an autopilot; you’re getting a convenient floating handheld remote, too. Easily fine-tune autopilot throttle settings with the touch of a button. Combine with your compatible Garmin chartplotter, and control your autopilot — from anywhere on your boat. The GHC™ 50 autopilot instrument enhances your autopilot experien Designed for small gasoline boats, this Reactor 40 kicker autopilot gives you the extra hand you need, so you can fish and explore paradise worry-free.This kicker autopilot works for boats with small gasoline outboard motors up to 25 horsepower1.Whether you’re fishing for your favorite species or just taking your sailboat out of the marina, this autopilot helps maintain heading hold and route to keep you on course — even against wind, waves or heavy current.The Reactor 40 kicker autopilot includes a convenient floating handheld remote control with a bright, sunlight-readable display. This allows you to quickly and easily control throttle settings as well as drop to idle speeds when netting a fish or coming up to a mooring.1See Autopilot Guide for details on supported motors and required accessoriesSpecifications Steering Actuator Motor side Extends 4" (10.3 cm) from end of tilt tube Motor 2.5" (6.2 cm) diameter Overall length Closed 17.5" (44.5 cm); Extended 25.3" (64.4 cm) Throttle Actuator Dimensions 6.0" x 2.5" x 1.1" (15.1 x 5.9 x 2.8 cm) Operating temperature range 0° to 70° C Water rating IPX7 (excluding cable) What's in the Box: GHC 50 helm control display CCU (Course computer unit) ECU (Electronic control unit) ECU power cable ECU to CCU interconnect cable Steering actuator Throttle actuator Autopilot remote NMEA 2000 drop cable (2 m) NMEA 2000 T-connectors Male and female terminators NMEA 2000 power cable Documentation Stainless steel tilt tube

Read more less

Garmin GMR Fantom™ 24x, whiteModel: 010-02585-00 GMR Fantom brings the power. Fifty watts of it, actually. See targets clearly, and adjust their sizes as needed. With power save mode, you get to choose when to use full power and when to pull back. Every second of power usage counts. Cut back even more by choosing your active times down to the second. MotionScope™ technology shows targets in color as they move toward you or away. Tailor your 50-watt solid-state dome radar to your boat with a white or black option — both with a range from 20’ to 48 nautical miles, even in fog or rain, and up to 60 RPM rotation speed for a refresh rate that can detect movement at any speed.High-resolution images and high antenna gain help to pick out targets at a distance, while 8-bit true color imagery enhances target separation.MotionScope uses the Doppler effect to detect moving targets and highlight them in different colors, so you can navigate around other boats or severe weather — or toward fishing spots where birds feed at the surface.The power save feature lets you choose when you need more power or less, so you have power when you need it and conserve it when you don’t.Boaters and sailors can specify transmit times down to the seconds instead of minutes, allowing for reduced power consumption.These radars don’t have any complex user settings to deal with, so they’re easy to install and start using.Adjust on-screen target resolution for better separation based on your surroundings.Adjust on-screen target resolution for better separation based on your surroundings.See a historical "trail" on the screen to help you quickly and easily identify moving targets and potential collision threats.The single radar antenna can provide split-screen images on your chartplotter side by side, with independent range setting and controls for both close and long range.Using dual radar provides redundancy and allows each display unit on the boat to pull data from one of two different radar sources.This feature automatically adjusts to your surroundings for optimal performance in all conditions.Gain automatically adjusts sea clutter for calm, medium and rough sea conditions.Overlay radar images onto your chartplotter’s map page. You can add an optional autopilot or heading sensor (sold separately) for best results.New mini-automatic radar plotting aid (MARPA) automatic acquisition allows for triggering and tracking of up to 30 targets with no user prompting on all returns, boundary zones, guard zones or MotionScope technology.Set the safety zone and receive an alarm when an object enters the zone.Variable range markers (VRM) and electronic bearing lines (EBL) allow rapid measurements of distance and bearing to vessels and land.Specifications General DIMENSION 25.4" x 9.8" (64.5 cm x 24.9 cm) WEIGHT 17.4 lbs WATERPROOF IPX7 ANTENNA LENGTH 23" (58.42 cm) ROTATION SPEED (RPM) Up to 60 rpm, depending on settings BEAM WIDTH 3.7° horizontal, 25° vertical 5.2° horizontal, 25° vertical 48 nm MINIMUM RANGE 6 meters RADAR TYPE Radome Electrical Features POWER INPUT 10-32 V DC POWER CONSUMPTION 4 W MAX POWER CONSUMPTION TRANSMITTING, POWER SAVE 24 W MAX POWER CONSUMPTION TRANSMITTING, NORMAL MODE 33 W TRANSITION POWER 50 W Radar Features DUAL RANGE SUPPORT Yes RADAR OVERLAY SUPPORT Yes DUAL RADAR Yes AUTOBIRD Yes DYNAMIC AUTO GAIN Dynamic MARPA TARGET TRACK Yes (Requires Heading Sensor, Sold Separately) ECHO TRAIL Yes MOTIONSCOPE Yes TARGET SIZE Yes SCAN Yes What's in the Box: GMR Fantom 24x - White Power cable (15 m/49.21 ft) Network cable (15 m/49.21 ft) Installation instructions Mounting hardware kit and template

Read more less

Garmin Reactor 40 Steer-by-wire Corepack for Yamaha Helm Master Without GHC ControlModel: 010-00705-91 Solid-state 9-axis Attitude Heading Reference System (AHRS) Minimizes heading error, course deviation, rudder movement and power consumption while providing a comfortable ride Minimal commissioning and calibration Reactor 40 for steer-by-wire provides robust autopilot capabilities for Yamaha Helm Master systems. With a complete package designed for powerboats and sailboats, Garmin brings an advanced marine technology to the boating public that was once only available for commercial boats. The Reactor 40 autopilot series is simply the most responsive autopilot system we have ever offered.Reactor 40 autopilots are very versatile. Both powerboat and sailing features are available in all corepacks, including heading hold, wind hold, tack/jibe, step turns and more.With its advanced solid-state 9-axis AHRS, you can mount Reactor 40 nearly anywhere, in any orientation. In addition, this new system greatly minimizes heading error, course deviation, rudder movement and power consumption while providing a comfortable ride for all on board.This amazing autopilot actually reacts to the sea to hold your course. Even when the boat is pitching and rolling, you can remain confident that the Reactor 40 autopilot will keep you on your desired course.All autopilots require commissioning and calibration — all of them. We know you just want to get on the water, so we made this process as fast and easy as possible. That’s the power of simple.Combined with a compatible Garmin networked chartplotter, you can have full control of Reactor 40 from wherever you are on the boat. In addition to holding its course in virtually all weather and wind conditions, the system can smoothly perform a variety of preprogrammed trolling and search procedures. Plus, with a compatible Garmin networked chartplotter and BlueChart® g2 Vision® charts (sold separately), you gain optional features such as Auto Guidance , which automatically steers GPS paths.Auto Guidance is for planning purposes only and does not replace safe navigation operations.Specifications CCU Specifications Dimensions 3 19/32 in. diameter (91.4 mm) Temperature range From 5°F to 131°F (from -15°C to 55°C) Case material Fully gasketed, high-impact plastic, waterproof to IEC 529 IPX7 standards CCU cable length 9.5 ft. (3 m) NMEA 2000 power input 9-16V NMEA 2000 LEN 3 (150 mA) Buzzer/Alarm Specifications Dimensions (L Diameter) 29/32 in. 1 in. (23 mm 25 mm) Temperature range from 5°F to 131°F (from -15°C to 55°C) Cable length 10 ft. (3.0 m) GHC 20 Specifications Unit dimensions, WxHxD 4.3 " x 4.4 " x 1.9 " (10.9 x 11.2 x 4.8 cm) Display resolution, WxH 320 x 240 pixels Display type QVGA color LCD display NMEA output NMEA 0183, NMEA 2000® Supply voltage Powered by NMEA 2000 bus, 9-16 VDC, units operate up to 32 VDC Operating temperature -15° C to 70 C° (5° F to 158° F) Max power consumption 3W Viewing angle 170° Brightness 1200 cd/m2 (NIT) Water rating IPX7 NMEA 2000 LEN (Load Equivalency Number) 7 (350 mA at 9VDC) Autopilot Gateway Specifications Dimensions (L Diameter) 5 1/8" 2 3/8" x 1" (130 mm 60 mm x 25 mm) What's in the Box: Reactor 40 CCU (Course Computer Unit) Yamaha Gateway CCU cable Buzzer NMEA 2000® drop cables (2 meters) NMEA 2000 power cable NMEA 2000 T-connectors Male and female terminators Documentation

Read more less

Garmin ECHOMAP UHD2 93sv LIVESCOPE Plus Bundle , U.S. inland without transducerModel: 010-02688-00/LVS34 Easy-to-use 9" chartplotter with a bright, sunlight-readable touchscreen display with improved detail, clarity and viewing angle Built-in Garmin Navionics+™ inland maps with integrated Navionics® data cover more than 18,000 lakes with up to 1’ contours Built-in Wi-Fi® connectivity lets you wirelessly share sonar, waypoints and routes with another ECHOMAP UHD2 chartplotter Wirelessly connects to your Force® trolling motor to create and follow routes, navigate to waypoints, control speed, check battery life and more" The 9" ECHOMAP™ UHD2 touchscreen with keyed-assist chartplotter knows the water better than a local. Its high-resolution display offers improved detail, clarity and viewing angle. See clear, sharp fish arches with Garmin traditional sonar. ClearVü™ and SideVü™ scanning sonars feature vivid color palettes for clear, high-contrast views all around your boat (transducer sold separately). ECHOMAP UDH2 also supports LiveScope™ sonar systems. Navigate the waters with built-in Garmin Navionics+™ cartography. Built-in Wi-Fi® connectivity lets you wirelessly share sonar, waypoints and routes with another ECHOMAP UHD2 chartplotter. Wherever you drop your line, get improved position accuracy, particularly in areas where signals are reflected or weak, with multi-band GPS. You can also pair with the free all-in-one ActiveCaptain® app on your compatible smartphone for access to the OneChart™ feature, software updates and more. The chartplotter supports NMEA 2000® networks to connect your compatible autopilots, digital switching, music, and more to view all on one screen.What's in the Box: ECHOMAP UHD2 92sv 12-pin sounder to 8-pin transducer cable Power cable Tilt mount with quick-release cradle Protective cover Hardware Documentation LIVESCOPE Plus

Read more less

Garmin ECHOMAP™ Ultra 2 126sv 12" Chartplotters without Transducer; Includes Garmin Navionics+™ U.S. Inland & Coastal MappingModel: 010-02882-00 SUPPORTS LIVESCOPE™ SONAR1 AND MORE WIRELESSLY NETWORK; SHARE SONAR, WAYPOINTS AND ROUTES2 CAPTURE SCREEN RECORDINGS TO SHARE FISH CATCHES MULTI-BAND GPS FOR IMPROVED POSITION ACCURACY With big, crisp, sunlight-readable touchscreen displays, these versatile chartplotters put a world of fishfinding capability at your fingertips. They’re available with built-in Garmin Navionics+™ mapping, and the transducer bundle adds Ultra High-Definition scanning sonars as well as CHIRP traditional sonar.The ECHOMAP Ultra 2 series supports the full lineup of LiveScope live-scanning sonar products (transducers sold separately).High-contrast vivid scanning sonar color palettes make it easier than ever to distinguish targets and structure.Bring a fresh new look and feel to your chartplotter with optional Garmin Navionics Vision+™ premium mapping (sold separately), featuring high-resolution relief shading, satellite imagery and more.If you have another compatible ECHOMAP Ultra 2 or ECHOMAP UHD2 chartplotter on your boat, you can wirelessly share information — such as sonar, waypoints and routes — with them.LiveScope™ System sonar transducer sold separately Via one-to-one unit wireless connection only LiveScope sonar cannot be shared wirelessly between two ECHOMAP Ultra 2 or ECHOMAP UHD2 chartplotters Requires the ActiveCaptain app on your compatible smartphone paired to your ECHOMAP Ultra 2 series chartplotterSpecifications General DIMENSION 13.4" x 9.0" x 3.9" (34.1 x 22.9 x 9.8 cm) WEIGHT 5.5 lbs (2.5 kg) WATERPROOF IPX7 TOUCHSCREEN Yes DISPLAY TYPE WXGA, IPS DISPLAY SIZE 10.3" x 6.4"; 12.1" diagonal (26.1 x 16.3 cm; 30.7 cm diagonal) DISPLAY RESOLUTION 1280 x 800 pixels MOUNTING OPTIONS Bail or flush INPUT Touchscreen with Keyed Assist Maps & Memory ACCEPTS DATA CARDS 2 microSD cards WAYPOINTS 5000 TRACK POINTS 50,000 TRACKS 50 saved tracks NAVIGATION ROUTES 100 Sensors GPS Yes GLONASS Yes GALILEO Yes BEIDOU Yes HAS BUILT-IN RECEIVER Yes RECEIVER 10 Hz NMEA 2000 COMPATIBLE Yes NMEA 0183 COMPATIBLE Yes SUPPORTS WAAS Yes SUPPORTS MULTI-BAND, MULTI-CONSTELLATION GPS Yes Built-in Maps BUILT-IN AUTO GUIDANCE+ Yes GARMIN NAVIONICS+ INLAND & COASTAL Includes Garmin Navionics+™ U.S. Inland & Coastal Mapping TIDE TABLES Yes Optional Map Support BLUECHART G3 Yes BLUECHART G3 VISION Yes LAKEVü G3 Yes LAKEVü G3 ULTRA Yes GARMIN NAVIONICS+™ Yes GARMIN NAVIONICS VISION+™ Yes TOPO 100K Yes STANDARD MAPPING Yes GARMIN QUICKDRAW CONTOURS Yes Electrical Features POWER INPUT 9 to 18 Vdc TYPICAL CURRENT DRAW AT 12 VDC 2.5 A MAXIMUM CURRENT DRAW AT 12 VDC 5.0 A MAXIMUM POWER USAGE AT 10 VDC 36 W Connections NMEA 2000® PORTS 1 GARMIN MARINE NETWORK PORTS 2 (large connector) 12-PIN TRANSDUCER PORTS 12-pin scanning sonar ANT+ (CONNECTIVITY) Yes GARMIN WI-FI NETWORK (LOCAL CONNECTION) Yes Sonar Features DISPLAYS SONAR Yes POWER OUTPUT 600 watt TRADITIONAL SONAR (DUAL FREQUENCY/BEAM) built-in (single channel CHIRP, 70/83/200 kHz, L, M, H CHIRP) CLEARVü built-in 260/455/800/1000/1200 kHz SIDEVü built-in 260/455/800/1000/1200 kHz PANOPTIX™ SONAR Yes LIVESCOPE Yes What's in the Box: ECHOMAP Ultra 126sv includes Includes Garmin Navionics+™ U.S. Inland & Coastal Mapping Power/data cable Bail mount with quick release cradle Protective sun cover 8-pin transducer to 12-pin sounder adapter cable Hardware Documentation

Read more less

Garmin ECHOMAP™ Ultra 2 122sv 12" Chartplotters without TransducerModel: 010-02881-00 SUPPORTS LIVESCOPE™ SONAR1 AND MORE WIRELESSLY NETWORK; SHARE SONAR, WAYPOINTS AND ROUTES2 CAPTURE SCREEN RECORDINGS TO SHARE FISH CATCHES MULTI-BAND GPS FOR IMPROVED POSITION ACCURACY With big, crisp, sunlight-readable touchscreen displays, these versatile chartplotters put a world of fishfinding capability at your fingertips. They’re available with built-in Garmin Navionics+™ mapping, and the transducer bundle adds Ultra High-Definition scanning sonars as well as CHIRP traditional sonar.The ECHOMAP Ultra 2 series supports the full lineup of LiveScope live-scanning sonar products (transducers sold separately).High-contrast vivid scanning sonar color palettes make it easier than ever to distinguish targets and structure.Bring a fresh new look and feel to your chartplotter with optional Garmin Navionics Vision+™ premium mapping (sold separately), featuring high-resolution relief shading, satellite imagery and more.If you have another compatible ECHOMAP Ultra 2 or ECHOMAP UHD2 chartplotter on your boat, you can wirelessly share information — such as sonar, waypoints and routes — with them.LiveScope™ System sonar transducer sold separately Via one-to-one unit wireless connection only LiveScope sonar cannot be shared wirelessly between two ECHOMAP Ultra 2 or ECHOMAP UHD2 chartplotters Requires the ActiveCaptain app on your compatible smartphone paired to your ECHOMAP Ultra 2 series chartplotterSpecifications General DIMENSION 13.4" x 9.0" x 3.9" (34.1 x 22.9 x 9.8 cm) WEIGHT 5.5 lbs (2.5 kg) WATERPROOF IPX7 TOUCHSCREEN Yes DISPLAY TYPE WXGA, IPS DISPLAY SIZE 10.3" x 6.4"; 12.1" diagonal (26.1 x 16.3 cm; 30.7 cm diagonal) DISPLAY RESOLUTION 1280 x 800 pixels MOUNTING OPTIONS Bail or flush INPUT Touchscreen with Keyed Assist Maps & Memory ACCEPTS DATA CARDS 2 microSD cards WAYPOINTS 5000 TRACK POINTS 50,000 TRACKS 50 saved tracks NAVIGATION ROUTES 100 Sensors GPS Yes GLONASS Yes GALILEO Yes BEIDOU Yes HAS BUILT-IN RECEIVER Yes RECEIVER 10 Hz NMEA 2000 COMPATIBLE Yes NMEA 0183 COMPATIBLE Yes SUPPORTS WAAS Yes SUPPORTS MULTI-BAND, MULTI-CONSTELLATION GPS Yes Built-in Maps BUILT-IN AUTO GUIDANCE+ Yes GARMIN NAVIONICS+ INLAND & COASTAL No TIDE TABLES No Optional Map Support BLUECHART G3 Yes BLUECHART G3 VISION Yes LAKEVü G3 Yes LAKEVü G3 ULTRA Yes GARMIN NAVIONICS+™ Yes GARMIN NAVIONICS VISION+™ Yes TOPO 100K Yes STANDARD MAPPING Yes GARMIN QUICKDRAW CONTOURS Yes Electrical Features POWER INPUT 9 to 18 Vdc TYPICAL CURRENT DRAW AT 12 VDC 2.5 A MAXIMUM CURRENT DRAW AT 12 VDC 5.0 A MAXIMUM POWER USAGE AT 10 VDC 36 W Connections NMEA 2000® PORTS 1 GARMIN MARINE NETWORK PORTS 2 (large connector) 12-PIN TRANSDUCER PORTS 12-pin scanning sonar ANT+ (CONNECTIVITY) Yes GARMIN WI-FI NETWORK (LOCAL CONNECTION) Yes Sonar Features DISPLAYS SONAR Yes POWER OUTPUT 600 watt TRADITIONAL SONAR (DUAL FREQUENCY/BEAM) built-in (single channel CHIRP, 70/83/200 kHz, L, M, H CHIRP) CLEARVü built-in 260/455/800/1000/1200 kHz SIDEVü built-in 260/455/800/1000/1200 kHz PANOPTIX™ SONAR Yes LIVESCOPE Yes What's in the Box: ECHOMAP Ultra 122sv Power/data cable Bail mount with quick release cradle Protective sun cover 8-pin transducer to 12-pin sounder adapter cable Hardware Documentation

Read more less

Garmin GPSMAP 1243 Chartplotter with Garmin Navionics+ coastal and inland water charts for the U.S. and CanadaModel: 010-02367-60 New high-resolution in-plane switching touchscreen display offers improved sunlight readability and wide-angle visibility over previous-generation 12" units Fast and responsive, this robust GPSMAP® system references 10 Hz GNSS (GPS, GLONASS and Galileo) for accurate positioning and smooth speed as well as COG data Slimline display borders, edge-to-edge glass and reduced unit footprint make for easy retrofit in a wider range of dash configurations Preloaded Garmin Navionics+™ coastal charts and inland mapping feature Auto Guidance+™ technology (Auto Guidance+ is for planning purposes only and does not replace safe navigation operations) ; plus, there’s support for optional Garmin Navionics Vision+™ premium map content. Built-in Garmin SailAssist™ features, including laylines, race features, set and drift, wind data and more. Requires compatible wind transducer (sold separately) J1939 engine connectivity for easy integration with engines and our exclusive OneHelm™ feature for connecting to your compatible third-party devices, such as EmpirBus™ digital switching Easily build your marine system — from compatible sonar and autopilots to compatible radar, cameras and multimedia — by using NMEA 2000® and NMEA 0183 networking and the Garmin Marine Network Use built-in Wi-Fi® networking to pair with the free ActiveCaptain® smartphone app for access to the OneChart™ feature, smart notifications, software updates and more. Integrated ANT® connectivity support for use with compatible quatix® smartwatches, the gWind™ Wireless 2 transducer, GNX™ Wind marine instrument and wireless remote controls (sold separately)" "Get a sharper view from your connected helm with the GPSMAP® 1243 chartplotter. Its high-resolution 12" in-plane switching touchscreen and ultrasleek design seamlessly integrate into your Garmin marine system, putting full control at your fingertips. Preloaded Garmin Navionics+™ coastal charts and inland mapping feature Auto Guidance+™ technology (Auto Guidance+ is for planning purposes only and does not replace safe navigation operations) for helping you get where you need to go. Plus, there’s support for optional Garmin Navionics Vision+™ premium map content. Easily build your marine system — from compatible sonar and autopilots to compatible radar, cameras and multimedia — by using HTML 5.0, NMEA 2000® and NMEA 0183 networking, J1939 for engines and the Garmin Marine Network. Add FrontVü™ forward-looking sonar (sold separately) (The ability to effectively avoid forward collisions with FrontVü sonar decreases as speed rises above 8 knots[HT1] ) which can help in avoiding underwater obstructions ahead. Or pair your plotter with your other compatible Garmin devices, such as quatix® smartwatches, wind transducers, wireless remote controls and more."Specifications General PHYSICAL DIMENSIONS 12.1" x 8.9" x 3.2" (30.8 x 22.8 x 8.2 cm) DISPLAY SIZE 10.3" x 6.4"; 12.1" diagonal DISPLAY RESOLUTION 1280 x 800 pixels DISPLAY TYPE WXGA display WEIGHT 6.6 lbs. (3.0 kg) WATER RATING IPX7 POLARIZED SUPPORT Yes POWER CONSUMPTION Max power usage at 10 Vdc: 26.5 W Typical current draw at 12 Vdc: 1.7 A Max current draw at 12 Vdc: 2.2 A ANTENNA Internal or external over NMEA 2000 MOUNTING OPTIONS Bail, flush or flat RECEIVER 10 Hz high-sensitivity GARMIN MARINE NETWORK™ PORTS 2 Maps & Memory PRELOADED MAPS Garmin Navionics+ coastal and inland water charts for the U.S. and Canada ACCEPTS DATA CARDS 2 microSD™ cards (back of unit) WAYPOINTS 5,000 TRACK LOG 50,000 points; 50 saved tracks ROUTES 100 Outdoor Recreation TIDE TABLES Yes Chartplotter Features GARMIN RADAR COMPATIBLE Yes GARMIN SONAR COMPATIBLE Yes (with external black box, sold separately) GARMIN SMARTMODE COMPATIBLE (CUSTOMIZABLE MONITOR PRESETS) Yes SUPPORTS AIS (TRACKS TARGET SHIPS POSITION) Yes SUPPORTS DSC (DISPLAYS POSITION DATA FROM DSC-CAPABLE VHF RADIO) Yes SUPPORTS FUSION-LINK™ COMPATIBLE RADIOS Yes GSD™ BLACK BOX SONAR SUPPORT Yes GCV™ BLACK BOX SONAR SUPPORT Yes ACTIVECAPTAIN COMPATIBLE Yes GRID™ (GARMIN REMOTE INPUT DEVICE) COMPATIBLE Yes WIRELESS REMOTE COMPATIBLE Yes SAILING FEATURES Yes Sonar Features & Specifications DUAL-FREQUENCY (50/200 KHZ) SONAR CAPABLE Yes (with external black box, sold separately) DUAL-BEAM (77/200 KHZ) SONAR CAPABLE Yes (with external black box, sold separately) CHIRP SONAR TECHNOLOGY Yes (with external black box, sold separately) CLEARVü Yes (with external black box, sold separately) SIDEVü Yes (with external black box, sold separately) Connections NMEA 2000® COMPATIBLE Yes NMEA 0183 INPUT PORTS 1 NMEA 0183 OUTPUT PORTS 1 VIDEO INPUT PORTS 1 BNC VIDEO OUTPUT PORTS 1 HDMI WIRELESS CONNECTIVITY Yes J1939 COMPATIBLE Yes What's in the Box: GPSMAP 1243 chartplotter with Garmin Navionics+ coastal and inland water charts for the U.S. and Canada microSD™ card preinstalled Power cable NMEA 2000® T-connector NMEA 2000 drop cable (2 meters) Bail mount kit with knobs Flush mount kit with gasket Protective cover Trim piece snap covers Documentation

Read more less

Garmin Compact Reactor™ 40 Kicker Autopilot With GHC™ 50 Autopilot InstrumentModel: 010-02794-09 This Reactor 40 kicker autopilot is the perfect companion for your small gasoline-powered boat. Sit back and relax. With this autopilot, you can maintain heading hold and stay on course. You’re not just getting an autopilot; you’re getting a convenient floating handheld remote, too. Easily fine-tune autopilot throttle settings with the touch of a button. Combine with your compatible Garmin chartplotter, and control your autopilot — from anywhere on your boat. The GHC™ 50 autopilot instrument enhances your autopilot experien Designed for small gasoline boats, this Reactor 40 kicker autopilot gives you the extra hand you need, so you can fish and explore paradise worry-free.This kicker autopilot works for boats with small gasoline outboard motors up to 25 horsepower1.Whether you’re fishing for your favorite species or just taking your sailboat out of the marina, this autopilot helps maintain heading hold and route to keep you on course — even against wind, waves or heavy current.The Reactor 40 kicker autopilot includes a convenient floating handheld remote control with a bright, sunlight-readable display. This allows you to quickly and easily control throttle settings as well as drop to idle speeds when netting a fish or coming up to a mooring.1See Autopilot Guide for details on supported motors and required accessoriesSpecifications Steering Actuator Motor side Extends 4" (10.3 cm) from end of tilt tube Motor 2.5" (6.2 cm) diameter Overall length Closed 17.5" (44.5 cm); Extended 25.3" (64.4 cm) Throttle Actuator Dimensions 6.0" x 2.5" x 1.1" (15.1 x 5.9 x 2.8 cm) Operating temperature range 0° to 70° C Water rating IPX7 (excluding cable) What's in the Box: GHC 50 helm control display CCU (Course computer unit) ECU (Electronic control unit) ECU power cable ECU to CCU interconnect cable Steering actuator Throttle actuator Autopilot remote NMEA 2000 drop cable (2 m) NMEA 2000 T-connectors Male and female terminators NMEA 2000 power cable Documentation

Read more less

Garmin GPSMAP 1223 Chartplotter with Worldwide BasemapModel: 010-02367-00 Easily integrate with more engines. Connect to compatible third-party devices with OneHelm™ digital switching. Easily build your marine system using the best of network connectivity. Compatible with premium maps and charts for the best in Garmin navigation. Take the guesswork out of sailing with clear laylines and more — right on the screen. Manage your marine experience from nearly anywhere2. With its sleek design, powerful processing and upgraded IPS display, this advanced 12" chartplotter integrates seamlessly into your Garmin marine system.With its powerful technology and new slimline design featuring edge-to-edge glass and a smaller unit footprint, it’s easy to retrofit this 12" plotter in a wider range of dash configurations.New 12" IPS displays offer improved sunlight readability and wide-angle visibility over previous-generation GPSMAP 12" Plus devices.View laylines, race start line guidance, enhanced wind rose, heading and course-over-ground lines, true wind data fields and tide/current/time slider, wind angle, set and drift, wind speed and more.These optional charts offer the best of Garmin and Navionics® data, Auto Guidance technology and other premium navigation features.If you have multiple compatible Garmin devices on your boat, you can share information — such as maps, user data, radar and IP camera video — among them.Connect to compatible autopilots, digital switching, weather, Fusion-Link™ audio system, media, VHF, AIS and more from one screen.Built-in Wi-Fi® connectivity pairs with the free all-in-one mobile app for access to the OneChart™ feature, smart notifications, software updates, Garmin Helm™ digital switching, Garmin Quickdraw™ Community data and more.Connect with some of your favorite devices, such as quatix® marine watches, gWind™ Wireless 2 transducers, GNX™ Wind marine instruments and wireless remote controls.Now you can connect your chartplotter to different kinds of engines, including select Yamaha engines.This exclusive feature brings together all the operations and capabilities of select third-party devices, such as EmpirBus™ digital switching, on one screen.Pair with Panoptix PS51 (transducer sold separately) with FrontVü scanning sonar6 to help you see and avoid submerged obstacles in real time as you approach within a 300’ range.Specifications General PHYSICAL DIMENSIONS 12.1" x 8.9" x 3.2" (30.8 x 22.8 x 8.2 cm) DISPLAY SIZE 10.3" x 6.4"; 12.1" diagonal DISPLAY RESOLUTION 1280 x 800 pixels DISPLAY TYPE WXGA display WEIGHT 6.6 lbs. (3.0 kg) WATER RATING IPX7 POLARIZED SUPPORT Yes POWER CONSUMPTION Max power usage at 10 Vdc: 26.5 W Typical current draw at 12 Vdc: 1.7 A Max current draw at 12 Vdc: 2.2 A ANTENNA Internal or external over NMEA 2000 MOUNTING OPTIONS Bail, flush or flat RECEIVER 10 Hz high-sensitivity GARMIN MARINE NETWORK™ PORTS 2 Maps & Memory PRELOADED MAPS worldwide basemap ACCEPTS DATA CARDS 2 microSD™ cards (back of unit) WAYPOINTS 5,000 TRACK LOG 50,000 points; 50 saved tracks ROUTES 100 Outdoor Recreation TIDE TABLES Yes Chartplotter Features GARMIN RADAR COMPATIBLE Yes GARMIN SONAR COMPATIBLE Yes (with external black box, sold separately) GARMIN SMARTMODE COMPATIBLE (CUSTOMIZABLE MONITOR PRESETS) Yes SUPPORTS AIS (TRACKS TARGET SHIPS POSITION) Yes SUPPORTS DSC (DISPLAYS POSITION DATA FROM DSC-CAPABLE VHF RADIO) Yes SUPPORTS FUSION-LINK™ COMPATIBLE RADIOS Yes GSD™ BLACK BOX SONAR SUPPORT Yes GCV™ BLACK BOX SONAR SUPPORT Yes ACTIVECAPTAIN COMPATIBLE Yes GRID™ (GARMIN REMOTE INPUT DEVICE) COMPATIBLE Yes WIRELESS REMOTE COMPATIBLE Yes SAILING FEATURES Yes Sonar Features & Specifications DUAL-FREQUENCY (50/200 KHZ) SONAR CAPABLE Yes (with external black box, sold separately) DUAL-BEAM (77/200 KHZ) SONAR CAPABLE Yes (with external black box, sold separately) CHIRP SONAR TECHNOLOGY Yes (with external black box, sold separately) CLEARVü Yes (with external black box, sold separately) SIDEVü Yes (with external black box, sold separately) Connections NMEA 2000® COMPATIBLE Yes NMEA 0183 INPUT PORTS 1 NMEA 0183 OUTPUT PORTS 1 VIDEO INPUT PORTS 1 BNC VIDEO OUTPUT PORTS 1 HDMI WIRELESS CONNECTIVITY Yes J1939 COMPATIBLE Yes What's in the Box: GPSMAP 1223 chartplotter microSD™ card preinstalled Power cable NMEA 2000® T-connector NMEA 2000 drop cable (2 meters) Bail mount kit with knobs Flush mount kit with gasket Protective cover Trim piece snap covers Documentation

Read more less

Garmin GPSMAP8410xsv 10" Chartplotter/Sonar Combo with Full HD In-plane Switching (IPS) TouchscreenModel: 010-02091-02 Features a 10" full HD IPS touchscreen display Built-in support for the full suite of Garmin sonar capabilities Fully network capable with NMEA 2000® connectivity and the Garmin Marine Network Includes Bluetooth® connectivity, ANT® technology and Wi-Fi® networking SmartMode™ station controls enable quick, one-touch access to the information you need Serious sport fishermen, cruisers, sailors and sail racers demand serious equipment. The easy-to-use, easy-to-install GPSMAP 8410xsv chartplotter/sonar combo delivers MFD performance in a combo-size package. It features a 10" full HD in IPS touchscreen display for wider viewing angles, superior clarity and sunlight readability, even with polarized sunglasses. Multiple displays can be flat mounted edge-to-edge to create a sleek glass helm look or can be mounted flush.The GPSMAP 8410xsv chartplotter/sonar combo offers built-in support for our industry-leading sonar, including dual-channel 1 kW traditional CHIRP, CHIRP ClearVü and CHIRP SideVü scanning sonars plus built-in support for Ultra High-Definition scanning sonar (no black box required). It also supports the entire Panoptix™ all-seeing sonar line (transducers sold separately).NMEA 2000 networking and the Garmin Marine Network allow you to easily build your full marine electronics suite — from radar and autopilots to cameras, instruments and forward-looking sonar — controlled from your chartplotter and shared across multiple screens. In addition, our exclusive OneHelm™ system coordinates many third-party manufactured onboard marine products to bring full control of systems — such as digital switching, lighting, stabilization and more — conveniently to your chartplotter screen.The GPSMAP 8410xsv chartplotter has a premium-performance processor that enables fast map drawing, superior networking, video distribution and more. Built-in Wi-Fi technology lets you pair with the free ActiveCaptain® app for access to OneChart™, smart notifications , Garmin Quickdraw™ community data and more. You can also control video streaming from our GC™ 100 wireless camera and VIRB® action cameras. In addition, built-in ANT wireless technology connects you directly to our quatix® marine watch, gWind™ Wireless 2 transducer and wireless remote controls.Networked sonar, radar, cameras, media and digital switching can be independent or incorporated into SmartMode station controls. With SmartMode, everything is designed to give you quick, one-touch access to the information you need to ease high-stress situations such as docking.The Garmin SailAssist™ feature provides data, displays and prerace guidance to help you gain a competitive edge. Other sailing features include laylines, enhanced wind rose, heading and course-over-ground lines, true wind data fields and tide/current/time slider. Gauge displays provide need-to-know information at a glance, including true and apparent wind angle, set and drift, true or apparent wind speed, horizontal or vertical graphs and a data bar with customizable fields.Download the ActiveCaptain app to your smartphone or tablet to manage your marine experience from anywhere — from trip planning and prefishing to updating software and purchasing maps.Specifications General Physical dimensions 10.25" x 8.0625" x 2.95" (25.9 cm x 20.5 cm x 7.5 cm) Weight 5.2 lbs (2.4kg) Water rating IPX6 and IPX7 Display type touchscreen IPS display (anti-glare finish) Display size 8.6" x 5.4" (21.8 cm x 13.7 cm) Display resolution WUXGA; 1920 x 1200 pixels Power consumption 2.7 A Antenna Internal or external over NMEA 2000 Mounting options Bail, flat or flush (Garmin do not offer any hardware or accessories for a flat-mount installation. Professional tools and knowledge is required.) Receiver 10 Hz GPS/GLONASS/Galileo Garmin Marine Network™ ports 2 Maps & Memory Accepts data cards 2 microSD cards (on back) Waypoints 5,000 Routes 100 (250 waypoints each) Track log 50,000 points; 50 saved tracks pre-loaded maps Worldwide Basemap Outdoor Recreation Features Tide tables Yes Chartplotter Features Garmin Radar compatible Yes Garmin Sonar compatible Yes Garmin SmartMode compatible (customizable monitor presets) Yes Supports AIS (tracks target ships position) Yes Supports DSC (displays position data from DSC-capable VHF radio) Yes Supports FUSION-Link™ compatible radios Yes GSD™ Black Box sonar support Yes GCV™ Black Box sonar support Yes ActiveCaptain compatible Yes Garmin Helm compatible Yes GRID™ (Garmin Remote Input Device) compatible Yes Wireless remote compatible Yes Sonar Features & Specifications Dual-frequency (50/200 kHz) sonar capable Yes Dual-beam (77/200 kHz) sonar capable Yes Frequencies supported Regular Traditional: 50/200, 77/200, 83/200 Single Channel CHIRP: 40-250 Dual Channel CHIRP: 40-250 SideVü/ClearVü: CHIRP 260/455/800(dependent on transducer) Frequencies supported Ultra High Definition Ultra High-Definition ClearVü: 0.8 MHz (800 kHz), CHIRP range: 760-880 kHzUltra High-Definition SideVü: 1.2 MHz (1,200 kHz), CHIRP range: 1,060-1,170 kHz(dependent on transducer) Transmit power 1 kW traditional; 1 kW CHIRP CHIRP sonar technology Yes (Built-in) ClearVü Yes SideVü Yes Maximum depth 5,000 ft at 1kW (depth capacity is dependent on water bottom type and other water conditions) Connections NMEA 2000® compatible Yes Transducer pin numbers 1 — LVS sonar, 1 — 12 pin scanning sonar, 1- 8 pin sonar NMEA 0183 input ports 1 differential NMEA 0183 output ports 1 differential Video input ports 1 - BNC composite1 - HDMI (HDCP compliant) Video output ports 1 HDMI Wireless connectivity Yes What's in the Box: GPSMAP 8410xsv Power cable NMEA 2000® drop cable NMEA 2000 T-connector Bail mount with knobs Flush mount kit Sun cover Trim piece snap covers Documentation

Read more less

Garmin GMR™ 24 xHD3 24" 4kw Radar DomeModel: 010-02842-00 24" 4-kW magnetron dome radars feature long ranges and improved target detection on your compatible chartplotter Scan averaging, a first for Garmin magnetron radar, helps filter out sea clutter and interference, providing boaters with enhanced detection of consistent targets Pulse expansion and angular target size processing optimize on-screen object shapes at all range scales Rotation speed of up to 60 rpm improves the redraw rate for faster target updates on your MFD The radar’s true echo trails feature displays a historical "trail" of boats on the water, removing relative motion influence to help users quickly identify moving targets Auto bird gain and the bird mode preset feature help users locate flocks of birds at the water’s surface — where there are often fish to be found below MARPA technology tracks selected targets, helping users keep track of other vessels and avoid collisions (requires heading sensor, sold separately) Radar overlay displays radar images over maps on your compatible chartplotter (requires heading sensor, sold separately) The reliable dome drive motor offers low-noise operation Radar detection range extends from 20 meters up to 48 nautical miles" See more of what’s out there, and gain extra peace of mind with the GMR™ xHD3 series dome radars. Combining high-definition imaging with our latest platform technology, these robust 4-kW magnetron radars offer new levels of confidence, clarity and performance for boaters who want to venture out on the water. Scan averaging, a first for Garmin magnetron radar, results in reduced sea clutter and interference on the display. Plus, other advanced features include true echo trails, auto bird gain, improved target-size processing and more. Delivering crisp, high-resolution picture quality and up to a 48-nautical mile detection range, these radars easily connect to your compatible Garmin chartplotter or MFD through the Garmin Marine Network.What's in the Box: GMR 24 xHD3 dome radar Power cable (15 m/49.21 ft) Network cable (15 m/49.21 ft) Mounting hardware kit and template Installation instructions

Read more less

Garmin GPSMAP8610 10" Plotter with Garmin Navionics+ coastal and inland water charts for the U.S. and CanadaModel: 010-02091-50 Features a 10" full HD in-plane switching touchscreen display for wider viewing angles, superior clarity and sunlight readability, even with polarized sunglasses Adds a stunning appearance with ability to install multiple displays either flat mounted edge- to-edge to create a sleek glass helm look or mounted flush Fully network capable with NMEA 2000® connectivity and the Garmin Marine Network to easily build your marine system — from sonar, radar and autopilots to instruments, cameras and multimedia ANT® connectivity and Wi-Fi® networking let you connect with your compatible quatix® smartwatches, gWind™ Wireless 2 wind sensor and more For full control of your boat on your chartplotter screen, use our exclusive OneHelm™ feature to connect to many third-party devices Preloaded Garmin Navionics+™ coastal charts and inland mapping feature Auto Guidance+™ technology (Auto Guidance+ is for planning purposes only and does not replace safe navigation operations); plus, there’s support for optional Garmin Navionics Vision+™ premium map content. See RPMs, fuel flow, temperature, trim and more for up to four of your compatible Mercury® engines by using the SmartCraft® Connect gateway Compatible with your Panoptix™ PS51 transducer with FrontVü™ forward-looking sonar, which helps you avoid running aground SmartMode™ station controls enable presets for one-touch access to docking, cruising, fishing, anchoring and more Built-in Garmin SailAssist™ features provide data, displays and prerace guidance needed to gain a competitive edge Use built-in Wi-Fi® networking to pair with the free ActiveCaptain® smartphone app for access to the OneChart™ feature, smart notifications, Garmin Quickdraw™ Community data and more. Dual microSD™ card slots on back of unit for use with the ActiveCaptain® app and cartography cards The GPSMAP® 8610 chartplotter features a 10" full HD in-plane switching touchscreen display for wider viewing angles, superior clarity and sunlight readability, even with polarized sunglasses. Experience superior connectivity and networking solutions with complete control of your entire system, right at your fingertips. The device is preloaded with Garmin Navionics+™ coastal charts and inland mapping that feature Auto Guidance+™ technology (Auto Guidance+ is for planning purposes only and does not replace safe navigation operations) for helping you get where you need to go. Plus, there’s support for optional Garmin Navionics Vision+™ premium map content. GPSMAP 8610 includes a premium-performance processor for our fastest map drawing, superior networking, video distribution and more. Multiple displays can be flat mounted edge-to-edge to create a sleek glass helm look or mounted flush. NMEA 2000® networking and the Garmin Marine Network allow you to build your full marine electronics suite — from radar and autopilots to cameras and instruments — controlled from your chartplotter and shared across multiple screens. With SmartMode™ station controls, everything is designed to give you quick, one-touch access to the information you need to ease high-stress situations such as docking. For full control of your boat on your chartplotter screen, use our exclusive OneHelm™ feature to connect to many compatible third-party devices. Built-in Garmin SailAssist™ features provide data, displays and prerace guidance to help you gain a competitive edge. Download the ActiveCaptain® smartphone app to your compatible smartphone or tablet to manage your marine experience — from trip planning and prefishing to purchasing, downloading and updating maps. See RPMs, fuel flow, temperature, trim and more for up to four of your compatible Mercury® engines by using the SmartCraft® Connect gateway.Specifications General Physical dimensions 10.25" x 8.0625" x 2.95" (25.9 cm x 20.5 cm x 7.5 cm) Weight 5.2 lbs (2.4kg) Water rating IPX6 and IPX7 Display type touchscreen IPS display (anti-glare finish) Display size 8.6" x 5.4" (21.8 cm x 13.7 cm) Display resolution WUXGA; 1920 x 1200 pixels Power consumption 2.0 A Antenna Internal or external over NMEA 2000 Mounting options Bail, flat or flush (Garmin do not offer any hardware or accessories for a flat-mount installation. Professional tools and knowledge is required.) Receiver 10 Hz GPS/GLONASS/Galileo Garmin Marine Network™ ports 2 Maps & Memory Accepts data cards 2 microSD cards (on back) Waypoints 5,000 Routes 100 (250 waypoints each) Track log 50,000 points; 50 saved tracks pre-loaded maps Garmin Navionics+ coastal and inland water charts for the U.S. and Canada Outdoor Recreation Features Tide tables Yes Chartplotter Features Garmin Radar compatible Yes Garmin Sonar compatible Yes Garmin SmartMode compatible (customizable monitor presets) Yes Supports AIS (tracks target ships position) Yes Supports DSC (displays position data from DSC-capable VHF radio) Yes Supports FUSION-Link™ compatible radios Yes GSD™ Black Box sonar support Yes GCV™ Black Box sonar support Yes ActiveCaptain compatible Yes Garmin Helm compatible Yes GRID™ (Garmin Remote Input Device) compatible Yes Wireless remote compatible Yes Sonar Features & Specifications Dual-frequency (50/200 kHz) sonar capable Yes (with external black box, sold separately) Dual-beam (77/200 kHz) sonar capable Yes (with external black box, sold separately) Frequencies supported NA Transmit power NA CHIRP sonar technology Yes_(when_connected_to_another_compatible_sonar_device) ClearVü yes (with GCV™ black box, sold separately) SideVü yes (with GCV™ black box, sold separately) Maximum depth NA Connections NMEA 2000® compatible Yes Transducer pin numbers NA NMEA 0183 input ports 1 differential NMEA 0183 output ports 1 differential Video input ports 1 - BNC composite1 - HDMI (HDCP compliant) Video output ports 1 HDMI Wireless connectivity Yes What's in the Box: GPSMAP 8610 Garmin Navionics+ coastal and inland water charts for the U.S. and Canada Power cable NMEA 2000® drop cable NMEA 2000 T-connector Bail mount with knobs Flush mount kit Sun cover Trim piece snap covers Documentation

Read more less

Garmin Reactor™ 40 Steer-by-wire Standard Corepack With GHC™ 50 Autopilot InstrumentModel: 010-02794-03 This Reactor 40 standard corepack is the perfect companion for your boat’s steer-by-wire system. Yes, it features a solid-state 9-axis AHRS. And yes, that means you can mount it nearly anywhere. Even when you’re pitching or rolling, this autopilot reacts to sea conditions to keep you on course. You just want to get on the water, so we made calibration fast and easy. That’s the power of simple. Combine with your compatible Garmin chartplotter, and control your autopilot — from anywhere on your boat. The GHC™ 50 autopilot instrument enhances your autopilot experience This corepack works with SeaStar Optimus systems, Yanmar Marine ZT370 sterndrive electronic power steering systems and ZF 2800 Pod drives. It requires a compatible Garmin chartplotter.With its advanced solid-state 9-axis AHRS, you can mount Reactor 40 nearly anywhere, in any orientation. It even reduces power consumption, minimizes heading error and more.Hold your course on the sea — this autopilot reacts to conditions, so you can remain confident even when you’re pitching or rolling.All autopilots require commissioning and calibration. Reactor 40 makes it quick and easy.Control your autopilot from anywhere on your boat by using your compatible Garmin devices, including the Reactor autopilot remote, select quatix® marine smartwatches and more (requires a compatible Garmin chartplotter or GHC 50 autopilot instrument).Reactor 40 corepack with the GHC 50 autopilot instrument to adds a dedicated, touchscreen autopilot display to your helm. Plus, GHC 50 allows you to share data and settings with Garmin MFDs and other installed Garmin devices.When connected to your compatible Garmin chartplotter, all Reactor 40 corepacks offer powerboat and sailing features, including heading hold and step turns — plus wind hold and tack/jibe when paired with a wind sensor (sold separately). You can even gain additional benefits such as the follow route and Auto Guidance+™ features1.1 Auto Guidance is for planning purposes only and does not replace safe navigation operationsSpecifications CCU Specifications Dimensions 3 19/32" diameter (91.4 mm) Weight 5.6 oz (159 g) Temperature range From 5°F to 131°F (from -15°C to 55°C) Case material Fully gasketed, high-impact plastic, waterproof to IEC 529 IPX7 standards CCU cable length 9.5 ft (3 m) NMEA 2000 power input 9-16V NMEA 2000 LEN 3 (150 mA) Buzzer/Alarm Specifications Dimensions (L Diameter) 29/32" 1" (23 mm 25 mm) Weight 2.4 oz (68 g) Temperature range from 5°F to 131°F (from -15°C to 55°C) Cable length 10 ft (3.0 m) What's in the Box: Reactor 40 CCU (Course Computer Unit) GHC™ 50 helm control display CCU cable Buzzer NMEA 2000® drop cables (2 meters) NMEA 2000 power cable NMEA 2000 T-connectors Male and female terminators Documentation

Read more less

Garmin GPSMAP8410 10" PlotterModel: 010-02091-00 Features a 10" full HD IPS touchscreen display Fully network capable with NMEA 2000® connectivity and the Garmin Marine Network Includes Bluetooth® connectivity, ANT® technology and Wi-Fi® networking Garmin SailAssist™ feature provides critical sailing data and displays prerace guidance for racers SmartMode™ station controls enable quick, one-touch access to the information you need Serious cruisers, sailors and sail racers demand serious equipment. The easy-to-use, easy-to-install GPSMAP 8410 chartplotter delivers MFD performance in a combo-size package. It features a 10" full HD IPS touchscreen display for wider viewing angles, superior clarity and sunlight readability, even with polarized sunglasses. Multiple displays can be flat mounted edge-to-edge to create a sleek glass helm look or can be mounted flush. It also provides standard USB touch output for use as a touchscreen monitor for Windows® and Mac® operating systems.NMEA 2000 networking and the Garmin Marine Network allow you to easily build your full marine electronics suite — from radar and autopilots to cameras, instruments and forward-looking sonar — controlled from your chartplotter and shared across multiple screens. In addition, our exclusive OneHelm™ system coordinates many third-party manufactured onboard marine products to bring full control of systems — such as digital switching, lighting, stabilization and more — conveniently to your chartplotter screen.The GPSMAP 8410 chartplotter has a premium-performance processor that enables fast map drawing, superior networking, video distribution and more. Built-in Wi-Fi technology lets you pair with the free ActiveCaptain® app for access to OneChart™, smart notifications , Garmin Quickdraw™ community data and more. You can also control video streaming from our GC™ 100 wireless camera and VIRB® action cameras. In addition, built-in ANT wireless technology connects you directly to our quatix® marine watch, gWind™ Wireless 2 transducer and wireless remote controls.Networked sonar, radar, cameras, media and digital switching can be independent or incorporated into SmartMode station controls. With SmartMode, everything is designed to give you quick, one-touch access to the information you need to ease high-stress situations such as docking.For the most detailed, clear and concise charts and maps, GPSMAP 8410 includes expandable memory for accessory map purchases such as BlueChart® g3 and BlueChart® g3 Vision featuring Navionics data. The charts and maps also include our Auto Guidance technology, which shows a suggested route to a destination , based on your boat’s specifications.You don’t have to stand for hours at the helm. The optional easy-to-use GRID™ 20 remote input device provides intuitive remote access and control of your entire Garmin marine system. It features a 360-degree joystick with a rotary knob and push-to-select button for easy chartplotter menu/setting navigation and fine control, even in the worst conditions.To help you make informed decisions, the Garmin SailAssist feature provides critical data displays and prerace guidance to help you gain a competitive edge. Other sailing features include laylines, enhanced wind rose, heading and course-over-ground lines, true wind data fields and tide/current/time slider. Gauge displays provide need-to-know information at a glance, including true and apparent wind angle, set and drift, true or apparent wind speed, horizontal or vertical graphs and a data bar with customizable fields.Download the ActiveCaptain app to your smartphone or tablet to manage your marine experience from anywhere — from trip planning and prefishing to updating software and purchasing maps.Specifications General Physical dimensions 10.25" x 8.0625" x 2.95" (25.9 cm x 20.5 cm x 7.5 cm) Weight 5.2 lbs (2.4kg) Water rating IPX6 and IPX7 Display type touchscreen IPS display (anti-glare finish) Display size 8.6" x 5.4" (21.8 cm x 13.7 cm) Display resolution WUXGA; 1920 x 1200 pixels Power consumption 2.0 A Antenna Internal or external over NMEA 2000 Mounting options Bail, flat or flush (Garmin do not offer any hardware or accessories for a flat-mount installation. Professional tools and knowledge is required.) Receiver 10 Hz GPS/GLONASS/Galileo Garmin Marine Network™ ports 2 Maps & Memory Accepts data cards 2 microSD cards (on back) Waypoints 5,000 Routes 100 (250 waypoints each) Track log 50,000 points; 50 saved tracks pre-loaded maps Worldwide Basemap Outdoor Recreation Features Tide tables Yes Chartplotter Features Garmin Radar compatible Yes Garmin Sonar compatible Yes Garmin SmartMode compatible (customizable monitor presets) Yes Supports AIS (tracks target ships position) Yes Supports DSC (displays position data from DSC-capable VHF radio) Yes Supports FUSION-Link™ compatible radios Yes GSD™ Black Box sonar support Yes GCV™ Black Box sonar support Yes ActiveCaptain compatible Yes Garmin Helm compatible Yes GRID™ (Garmin Remote Input Device) compatible Yes Wireless remote compatible Yes Sonar Features & Specifications Dual-frequency (50/200 kHz) sonar capable Yes (with external black box, sold separately) Dual-beam (77/200 kHz) sonar capable Yes (with external black box, sold separately) Frequencies supported NA Transmit power NA CHIRP sonar technology Yes_(when_connected_to_another_compatible_sonar_device) ClearVü yes (with GCV™ black box, sold separately) SideVü yes (with GCV™ black box, sold separately) Maximum depth NA Connections NMEA 2000® compatible Yes Transducer pin numbers NA NMEA 0183 input ports 1 differential NMEA 0183 output ports 1 differential Video input ports 1 - BNC composite1 - HDMI (HDCP compliant) Video output ports 1 HDMI Wireless connectivity Yes What's in the Box: GPSMAP 8410 Power cable NMEA 2000® drop cable NMEA 2000 T-connector Bail mount with knobs Flush mount kit Sun cover Trim piece snap covers Documentation

Read more less

Course Computer Unit (CCU) - Reactor™ 40 Steer-by-wireGarmin's CCU is the brain of the Reactor 40 autopilot system, containing sensory equipment used to determine heading and rate of turn. Connect the CCU to your boat's steering system and the NMEA 2000® network to communicate with your GHC™ 20 and optional NMEA 2000-compatible devices.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

Garmin Reactor 40 Steer-by-wire Course Computer UnitModel: 010-11052-65Garmins CCU is the brain of the Reactor 40 autopilot system, containing sensory equipment used to determine heading and rate of turn. Connect the CCU to your boat's steering system and the NMEA 2000 network to communicate with your GHC 20 and optional NMEA 2000-compatible devices.Use as replacement for Reactor 40 Steer-by-Wire and Steer-By-Wire for Yamaha Helm Master systems

Read more less

Garmin GPSMAP® 1242xsv 12-inch Chartplotter/Sonar Combo Is All-in-1 Solution with Garmin Navionics+ coastal and inland water charts for the U.S. and Canada and GT52-TM TransducerModel: 010-01741-60 Large, bright 12" screen with keypad interface and multifunction control knob Includes GT52-TM transducer for Garmin CHIRP sonar and CHIRP ClearVü™ and CHIRP SideVü™ scanning sonars Supports all-seeing live sonar, which includes LiveScope™ sonar (transducers sold separately) Preloaded Garmin Navionics+™ coastal charts and inland mapping feature Auto Guidance+™ technology (Auto Guidance+ is for planning purposes only and does not replace safe navigation operations); plus, there’s support for optional Garmin Navionics Vision+™ premium map content. Built-in wireless capabilities for Garmin mobile apps See RPMs, fuel flow, temperature, trim and more for up to four of your compatible Mercury® engines by using the SmartCraft® Connect gateway Supports the Garmin Marine Network; allows sharing of sonar, radar, maps, user data, and NMEA 2000® and NMEA 0183 network connectivity support, including autopilots, digital switching, weather, media, VHF, AIS and other sensors Includes Quickdraw Contours map drawing software Built-in Garmin SailAssist™ features include laylines, race features, set and drift, wind data and more Integrated ANT® connectivity support for use with compatible quatix® smartwatches, the gWind™ Wireless 2 transducer, GNX™ Wind marine instrument and remote controls (sold separately) Experience an advanced all-in-one solution with our 12" GPSMAP® 1242xsv keyed combo. It features a large, bright screen coupled with a keypad interface and multifunction control knob. A GT52-TM transducer is included for Garmin CHIRP sonar along with CHIRP ClearVü™ and CHIRP SideVü™ scanning sonars. There’s also support for Panoptix™ and LiveScope™ sonar products and a wide range of other transducers (sold separately). Preloaded Garmin Navionics+™ coastal charts and inland mapping feature Auto Guidance+™ technology (Auto Guidance+ is for planning purposes only and does not replace safe navigation operations). Plus, there’s support for optional Garmin Navionics Vision+™ premium map content. The combo also includes Quickdraw Contours software and the Quickdraw Community on our Garmin Connect™ online network. Use built-in Wi-Fi® technology to pair with the free ActiveCaptain® smartphone app for access to the OneChart™ feature, smart notifications, Garmin Quickdraw™ Community data and more. Garmin Marine Network support allows sharing of sonar, maps, user data, radar, IP cameras and live sonar among multiple units. Plus, there’s NMEA 2000® and NMEA 0183 network connectivity support, including autopilots, digital switching, weather, media, VHF, AIS and other sensors. These units also include integrated ANT® connectivity support for use with compatible quatix® smartwatches, the gWind™ Wireless 2 transducer, GNX™ Wind marine instrument and remote controls (sold separately). See RPMs, fuel flow, temperature, trim and more for up to four of your compatible Mercury® engines by using the SmartCraft® Connect gateway. "Fast, responsive built-in 10 Hz GPS and GLONASS refreshes your position and heading 10 times each second to make your movement on the screen more fluid. It makes dropping up to 5,000 accurate waypoints — and finding your way back to them — quick and easy.Instantly create personalized HD fishing maps on screen with 1’ contours. Tailor them to fit your needs. These are your maps — you own them. Keep the data to yourself, or share it with the Quickdraw Community on our Garmin Connect™ online network.To help you gain a wind-maximizing competitive edge, your chartplotter features a prerace guidance page that shows your virtual starting line along with data fields showing laylines, time to burn before the start and a race timer that can be synchronized across all your networked Garmin GPS products. In addition, other supported sailing features include an enhanced wind rose, heading and course-over-ground lines, set and drift, true and apparent wind data and more.If you have waypoints, tracks or frequently used routes stored on another manufacturer’s GPS product — or on a Garmin handheld device — it’s easy to transfer those items to your new Garmin chartplotter via industry-standard GPX software formatting.Specifications Performance and Physical Dimensions 14.1" x 8.9" x 2.7" (35.8 x 22.6 x 6.9 cm) Display size 10.3" x 6.4" (26.2 x 16.3 cm) Display resolution 1280 x 800 Display type WXGA display Weight 5.2 lbs (2.34 kg) Water rating IPX7 Power consumption Max power usage at 10 Vdc: 34.8 W Antenna Internal or external over NMEA 2000 Mounting options Bail or flush Receiver 10 Hz high-sensitivity Garmin Marine Network™ ports 2 Preloaded maps Garmin Navionics+ coastal and inland water charts for the U.S. and Canada Accepts data cards 2 SD™ cards Waypoints 5,000 Routes 100 Track log 50,000 points; 50 saved tracks Tide tables Yes Garmin Radar compatible Yes Garmin Sonar compatible Yes (built-in) Garmin SmartMode compatible (customizable monitor presets) Yes Supports AIS (tracks target ships position) Yes Supports DSC (displays position data from DSC-capable VHF radio) Yes Garmin Meteor™ Audio System compatible Yes Supports FUSION-Link™ compatible radios Yes GSD™ Black Box sonar support Yes GCV™ Black Box sonar support Yes ActiveCaptain compatible Yes Garmin Helm compatible Yes GRID™ (Garmin Remote Input Device) compatible Yes Wireless remote compatible Yes Dual-frequency (50/200 kHz) sonar capable Yes Dual-beam (77/200 kHz) sonar capable Yes Transmit power 1 kW traditional; 1 kW CHIRP CHIRP sonar technology Yes (Built-in) ClearVü Yes with CHIRP (built-in) SideVü Yes with CHIRP (built-in) Maximum depth 5,000 ft at 1kW (depth capacity is dependent on water bottom type and other water conditions) Bottom lock (shows return from the bottom up) Yes Water temperature log and graph Yes Sonar recording Yes Sonar history rewind Yes NMEA 2000® compatible Yes Transducer pin numbers 12 NMEA 0183 input ports 1 NMEA 0183 output ports 1 Video input ports 1 BNC Video output ports None Wireless connectivity Yes What's in the Box: GPSMAP 1242xsv chartplotter Garmin Navionics+ coastal and inland water charts for the U.S. and Canada Power/data cable NMEA 2000 T-connector NMEA 2000 drop cable (2 m) Bail mount kit with knobs Flush mount kit with gasket Protective cover Trim piece snap covers Documentation GT52-TM transducer

Read more less

Garmin LiveScope™ XR System with GLS 10™ and LVS62 TransducerModel: 010-02719-00 Explore the deep with an extended range up to 500’ in freshwater and 350’ in saltwater. Find fish circling your boat with clear views close around your hull. Get maximum contrast and clarity in your images with vivid color palettes. Don’t miss a thing with supported Forward, Down and Perspective modes plus necessary mount. You didn’t think it could get better, but it did with the extended range of the LiveScope XR System. It’s the latest in LiveScope technology, now for coastal and open-water fishing.The Reverse Range Offset feature uses more of the screen to display fish and structure up to 500’ in freshwater and 350’ in saltwater.The Compress Range feature gives you a clear view close to your boat while keeping an eye on targets farther away.Real-time sonar ensures that your live images are as accurate as possible.A built-in stabilization system keeps the sonar image on your compatible chartplotter steady, even in rough conditions.Choose from seven vivid color options — including aqua, Caribbean, lava and more — to see fish and structure in maximum contrast and clarity.Now scout even farther ahead of your boat to see what’s happening in real time.Explore live views of the activity deeper beneath your boat.See under the water with a view from your perspective above the water.Specifications General DIMENSION GLS 10 sonar black box: 9.7" x 5.9" x 2.6" (24.5 x 14.9 x 6.5 cm);LVS62 transducer: 8.20" x 3.98" x 2.76" (20.8 x 10.1 x 7.0 cm) WEIGHT GLS 10 sonar black box: 4.3 lbs (2.0 kg) WATERPROOF IPX7 TRANSDUCER BEAMWIDTH 20° x 135° TRANSDUCER CABLE LENGTH 20 ft TRANSDUCER NUMBER OF PINS 21 TEMPERATURE RANGE GLS 10 Black Box: Operating: -15 C to 70 C Sonar Features & Specifications FREQUENCY 265 - 550 kHz MAXIMUM DEPTH Freshwater: Down and Forward: 500’ (152.0 m)Saltwater: Down and Forward: 350’ (106.0 m) SONAR TYPE Live TARGET SEPARATION @100' 22" PERSPECTIVE MODE MOUNT INCLUDED Yes Connections GARMIN MARINE NETWORK PORTS 1 (small connector) Electrical Features POWER INPUT 10-32 V POWER USAGE 21 W typical, 58 W max TRANSMIT POWER 500 W FUSE 7.5 A COMPASS-SAFE DISTANCE 7" (0.18 m) What's in the Box: LiveScope GLS 10 sonar black box LiveScope XR LVS62 transducer Perspective mount (LiveScope XR LVS62 transducer only) Trolling motor barrel mount Shaft mount Power cable 2 meter Garmin Marine Network cable (small connector) Network adapter cable Documentation

Read more less

B275LH-W Bronze Thru-Hull Transducer - 12-PinGet more coverage under your boat with Airmar’s unique wide beam, high frequency Chirp-ready transducers. The high band operates across a frequency range of 150 to 250 kHz and has a fixed 25° beam for all frequencies. The high frequency band results in superior resolution. The constant wide beamwidth provides twice the coverage under the boat and excellent fish arches on the display compared to most high frequency narrow beam transducer options.The included high-performance fairing improves broadband performance at speeds over 30 knots (34 MPH).The high wide is the ideal choice for both inshore and pelagic fishing, where resolution and maximum coverage under the boat are essential down to 500'.The low frequency band and 1 kW of power also provides great deeper water performance. Get the best of both worlds with Airmar’s dual frequency Chirp-ready transducers with wide beam coverage.Features: Depth and fast-response water-temperature sensor 1 kW for great deep water performance from the low frequency Low Frequency: 42 kHz to 65 kHz with maximum depth of 914 m (3000') 25° to 16° beamwidth High Frequency: 150 kHz to 250 kHz with maximum depth of 152 m (500')25° constant beamwidth 123 kHz of total bandwidth from one transducer Covers popular fishing frequencies of 50 and 200 kHz plus everything else in the bandwidth High frequency provides superior shallow water performance, bottom detail and fish target separation High wide beamwidth provides more coverage under the boat for detecting fish in the upper water column Bronze transducer housing with high-performance fairing for optimal performance at higher speeds Recommended boat size: 8 m (25') and above Hull Type: Fiberglass or wood Exclusive Xducer ID® technology WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Mounting Style: Thru-Hull Imagining: Standard Chirp: Low/High Wide Cable Length (Feet): 12m Temperature: Yes Speed Included: No Pins: 12 Box Dimensions: 7"H x 19"W x 26"L WT: 24.15 lbs UPC: 753759123574 Brochure (pdf)

Read more less

Garmin ECHOMAP™ Ultra 2 106sv 10" Chartplotters with GT56UHD-TM Transducer; Includes Garmin Navionics+™ U.S. Inland & Coastal MappingModel: 010-02880-01 SUPPORTS LIVESCOPE™ SONAR1 AND MORE WIRELESSLY NETWORK; SHARE SONAR, WAYPOINTS AND ROUTES2 CAPTURE SCREEN RECORDINGS TO SHARE FISH CATCHES MULTI-BAND GPS FOR IMPROVED POSITION ACCURACY With big, crisp, sunlight-readable touchscreen displays, these versatile chartplotters put a world of fishfinding capability at your fingertips. They’re available with built-in Garmin Navionics+™ mapping, and the transducer bundle adds Ultra High-Definition scanning sonars as well as CHIRP traditional sonar.The ECHOMAP Ultra 2 series supports the full lineup of LiveScope live-scanning sonar products (transducers sold separately).High-contrast vivid scanning sonar color palettes make it easier than ever to distinguish targets and structure.Bring a fresh new look and feel to your chartplotter with optional Garmin Navionics Vision+™ premium mapping (sold separately), featuring high-resolution relief shading, satellite imagery and more.If you have another compatible ECHOMAP Ultra 2 or ECHOMAP UHD2 chartplotter on your boat, you can wirelessly share information — such as sonar, waypoints and routes — with them.LiveScope™ System sonar transducer sold separately Via one-to-one unit wireless connection only LiveScope sonar cannot be shared wirelessly between two ECHOMAP Ultra 2 or ECHOMAP UHD2 chartplotters Requires the ActiveCaptain app on your compatible smartphone paired to your ECHOMAP Ultra 2 series chartplotterSpecifications General DIMENSION 11.6" x 7.7" x 3.9" (29.5 x 19.5 x 9.8 cm) WEIGHT 4.0 lbs (1.8 kg) WATERPROOF IPX7 TOUCHSCREEN Yes DISPLAY TYPE WXGA, IPS DISPLAY SIZE 8.5" x 5.4"; 10" diagonal (21.7 x 13.6 cm; 25.4 cm diagonal) DISPLAY RESOLUTION 1280 x 800 pixels MOUNTING OPTIONS Bail or flush INPUT Touchscreen with Keyed Assist Maps & Memory ACCEPTS DATA CARDS 2 microSD cards WAYPOINTS 5000 TRACK POINTS 50,000 TRACKS 50 saved tracks NAVIGATION ROUTES 100 Sensors GPS Yes GLONASS Yes GALILEO Yes BEIDOU Yes HAS BUILT-IN RECEIVER Yes RECEIVER 10 Hz NMEA 2000 COMPATIBLE Yes NMEA 0183 COMPATIBLE Yes SUPPORTS WAAS Yes SUPPORTS MULTI-BAND, MULTI-CONSTELLATION GPS Yes Built-in Maps BUILT-IN AUTO GUIDANCE+ Yes GARMIN NAVIONICS+ INLAND & COASTAL Garmin Navionics+™ U.S. Inland & Coastal Mapping TIDE TABLES yes Optional Map Support BLUECHART G3 Yes BLUECHART G3 VISION Yes LAKEVü G3 Yes LAKEVü G3 ULTRA Yes GARMIN NAVIONICS+™ Yes GARMIN NAVIONICS VISION+™ Yes TOPO 100K Yes STANDARD MAPPING Yes GARMIN QUICKDRAW CONTOURS Yes Electrical Features POWER INPUT 9 to 18 Vdc TYPICAL CURRENT DRAW AT 12 VDC 2.3 A MAXIMUM CURRENT DRAW AT 12 VDC 5.0 A MAXIMUM POWER USAGE AT 10 VDC 34 W Connections NMEA 2000® PORTS 1 GARMIN MARINE NETWORK PORTS 2 (large connector) 12-PIN TRANSDUCER PORTS 12-pin scanning sonar ANT+ (CONNECTIVITY) Yes GARMIN WI-FI NETWORK (LOCAL CONNECTION) Yes Sonar Features DISPLAYS SONAR Yes POWER OUTPUT 600 watt TRADITIONAL SONAR (DUAL FREQUENCY/BEAM) built-in (single channel CHIRP, 70/83/200 kHz, L, M, H CHIRP) CLEARVü built-in 260/455/800/1000/1200 kHz SIDEVü built-in 260/455/800/1000/1200 kHz PANOPTIX™ SONAR Yes LIVESCOPE Yes What's in the Box: ECHOMAP Ultra 106sv; Includes Garmin Navionics+™ U.S. Inland & Coastal Mapping Power/data cable Bail mount with quick release cradle Protective sun cover GT56UHD-TM transducer Hardware Documentation

Read more less

Garmin ECHOMAP™ Ultra 2 102sv 10" Chartplotters with GT56UHD-TM TransducerModel: 010-02879-01 SUPPORTS LIVESCOPE™ SONAR1 AND MORE WIRELESSLY NETWORK; SHARE SONAR, WAYPOINTS AND ROUTES2 CAPTURE SCREEN RECORDINGS TO SHARE FISH CATCHES MULTI-BAND GPS FOR IMPROVED POSITION ACCURACY With big, crisp, sunlight-readable touchscreen displays, these versatile chartplotters put a world of fishfinding capability at your fingertips. They’re available with built-in Garmin Navionics+™ mapping, and the transducer bundle adds Ultra High-Definition scanning sonars as well as CHIRP traditional sonar.The ECHOMAP Ultra 2 series supports the full lineup of LiveScope live-scanning sonar products (transducers sold separately).High-contrast vivid scanning sonar color palettes make it easier than ever to distinguish targets and structure.Bring a fresh new look and feel to your chartplotter with optional Garmin Navionics Vision+™ premium mapping (sold separately), featuring high-resolution relief shading, satellite imagery and more.If you have another compatible ECHOMAP Ultra 2 or ECHOMAP UHD2 chartplotter on your boat, you can wirelessly share information — such as sonar, waypoints and routes — with them.LiveScope™ System sonar transducer sold separately Via one-to-one unit wireless connection only LiveScope sonar cannot be shared wirelessly between two ECHOMAP Ultra 2 or ECHOMAP UHD2 chartplotters Requires the ActiveCaptain app on your compatible smartphone paired to your ECHOMAP Ultra 2 series chartplotterSpecifications General DIMENSION 11.6" x 7.7" x 3.9" (29.5 x 19.5 x 9.8 cm) WEIGHT 4.0 lbs (1.8 kg) WATERPROOF IPX7 TOUCHSCREEN Yes DISPLAY TYPE WXGA, IPS DISPLAY SIZE 8.5" x 5.4"; 10" diagonal (21.7 x 13.6 cm; 25.4 cm diagonal) DISPLAY RESOLUTION 1280 x 800 pixels MOUNTING OPTIONS Bail or flush INPUT Touchscreen with Keyed Assist Maps & Memory ACCEPTS DATA CARDS 2 microSD cards WAYPOINTS 5000 TRACK POINTS 50,000 TRACKS 50 saved tracks NAVIGATION ROUTES 100 Sensors GPS Yes GLONASS Yes GALILEO Yes BEIDOU Yes HAS BUILT-IN RECEIVER Yes RECEIVER 10 Hz NMEA 2000 COMPATIBLE Yes NMEA 0183 COMPATIBLE Yes SUPPORTS WAAS Yes SUPPORTS MULTI-BAND, MULTI-CONSTELLATION GPS Yes Built-in Maps BUILT-IN AUTO GUIDANCE+ Yes GARMIN NAVIONICS+ INLAND & COASTAL No TIDE TABLES No Optional Map Support BLUECHART G3 Yes BLUECHART G3 VISION Yes LAKEVü G3 Yes LAKEVü G3 ULTRA Yes GARMIN NAVIONICS+™ Yes GARMIN NAVIONICS VISION+™ Yes TOPO 100K Yes STANDARD MAPPING Yes GARMIN QUICKDRAW CONTOURS Yes Electrical Features POWER INPUT 9 to 18 Vdc TYPICAL CURRENT DRAW AT 12 VDC 2.3 A MAXIMUM CURRENT DRAW AT 12 VDC 5.0 A MAXIMUM POWER USAGE AT 10 VDC 34 W Connections NMEA 2000® PORTS 1 GARMIN MARINE NETWORK PORTS 2 (large connector) 12-PIN TRANSDUCER PORTS 12-pin scanning sonar ANT+ (CONNECTIVITY) Yes GARMIN WI-FI NETWORK (LOCAL CONNECTION) Yes Sonar Features DISPLAYS SONAR Yes POWER OUTPUT 600 watt TRADITIONAL SONAR (DUAL FREQUENCY/BEAM) built-in (single channel CHIRP, 70/83/200 kHz, L, M, H CHIRP) CLEARVü built-in 260/455/800/1000/1200 kHz SIDEVü built-in 260/455/800/1000/1200 kHz PANOPTIX™ SONAR Yes LIVESCOPE Yes What's in the Box: ECHOMAP Ultra 102sv Power/data cable Bail mount with quick release cradle Protective sun cover GT56UHD-TM transducer Hardware Documentation

Read more less

Garmin LVS62 Transducer Only for Livescope XRModel: 010-02719-10 Explore the deep with an extended range up to 500’ in freshwater and 350’ in saltwater. Find fish circling your boat with clear views close around your hull. Upgrade your current LiveScope System black box (GLS™ 10 sonar module) with just a new transducer. Get maximum contrast and clarity in your images with vivid color palettes. Don’t miss a thing with supported Forward, Down and Perspective modes plus necessary mount. You didn’t think it could get better, but it did with the extended range of the LiveScope XR System. It’s the latest in LiveScope technology, now for coastal and open-water fishing.The Reverse Range Offset feature uses more of the screen to display fish and structure up to 500’ in freshwater and 350’ in saltwater.The Compress Range feature gives you a clear view close to your boat while keeping an eye on targets farther away.Real-time sonar ensures that your live images are as accurate as possible.A built-in stabilization system keeps the sonar image on your compatible chartplotter steady, even in rough conditions.Choose from seven vivid color options — including aqua, Caribbean, lava and more — to see fish and structure in maximum contrast and clarity.Now scout even farther ahead of your boat to see what’s happening in real time.Explore live views of the activity deeper beneath your boat.See under the water with a view from your perspective above the water.Specifications General DIMENSION LVS62 transducer: 8.20" x 3.98" x 2.76" (20.8 x 10.1 x 7.0 cm) WEIGHT LVS62 transducer with cable: 3.92 lbs (1.78 kg) WATERPROOF IPX7 TRANSDUCER BEAMWIDTH 20° x 135° TRANSDUCER CABLE LENGTH 20 ft TRANSDUCER NUMBER OF PINS 21 TEMPERATURE RANGE LVS62 Transducer: Operating: 0 C to 40 C Sonar Features & Specifications FREQUENCY 265 - 550 kHz MAXIMUM DEPTH Freshwater: Down and Forward: 500’ (152.0 m) Saltwater: Down and Forward: 350’ (106.0 m) SONAR TYPE Live TARGET SEPARATION @100' 22" PERSPECTIVE MODE MOUNT INCLUDED Yes Connections GARMIN MARINE NETWORK PORTS 1 (small connector) Electrical Features POWER INPUT 10-32 V POWER USAGE 21 W typical, 58 W max TRANSMIT POWER 500 W FUSE 7.5 A COMPASS-SAFE DISTANCE 7" (0.18 m) What's in the Box: LiveScope XR LVS62 transducer Perspective mount (LiveScope XR LVS62 transducer only) Trolling motor barrel mount Shaft mount Power cable Documentation

Read more less

Garmin Class B Compact v2 Drive UnitModel: 010-12029-01The Class B Drive Unit works with the Reactor 40 Mechanical/Retrofit/Solenoid Corepack to control your sailboat’s steering system. This device is designed for use with sailboats with up to 48,400 lbs of displacement.Specifications Dimensions (WxHxD, centered) 31.9 x 4.6" x 8.9" (810 x 120 x 225 mm) Drive unit type integrated hydraulic linear Stroke length 10" (254 mm) Maximum thrust 1,610 lbs (730 kg) Supply voltage 10V to 30 V (regulated to 12V by the ECU) Average clutch current at 12V 1 Amp Average motor current at 12V 2-4 Amps Operating temperature -15° C to 50° C

Read more less

Garmin GPSMAP® 1242xsv 12-inch Chartplotter/Sonar Combo Is All-in-1 Solution with Garmin Navionics+ coastal and inland water charts for the U.S. and CanadaModel: 010-01741-50UPC: 753759175511 Large, bright 12" screen with keypad interface and multifunction control knob Supports all-seeing live sonar, which includes LiveScope™ sonar (transducers sold separately) Preloaded Garmin Navionics+™ coastal charts and inland mapping feature Auto Guidance+™ technology (Auto Guidance+ is for planning purposes only and does not replace safe navigation operations); plus, there’s support for optional Garmin Navionics Vision+™ premium map content. Built-in wireless capabilities for Garmin mobile apps See RPMs, fuel flow, temperature, trim and more for up to four of your compatible Mercury® engines by using the SmartCraft® Connect gateway Supports the Garmin Marine Network; allows sharing of sonar, radar, maps, user data, and NMEA 2000® and NMEA 0183 network connectivity support, including autopilots, digital switching, weather, media, VHF, AIS and other sensors Includes Quickdraw Contours map drawing software Built-in Garmin SailAssist™ features include laylines, race features, set and drift, wind data and more Integrated ANT® connectivity support for use with compatible quatix® smartwatches, the gWind™ Wireless 2 transducer, GNX™ Wind marine instrument and remote controls (sold separately) Experience an advanced all-in-one solution with our 12" GPSMAP® 1242xsv keyed combo. It features a large, bright screen coupled with a keypad interface and multifunction control knob. It comes with built-in support for Garmin CHIRP sonar along with CHIRP ClearVü™ and CHIRP SideVü™ scanning sonars. The combo also supports Panoptix™ and LiveScope™ sonar products, including the LiveScope™ Plus System and a wide range of other transducers (sold separately). Use built-in Wi-Fi® technology to pair with the free ActiveCaptain® smatrphone app for access to the OneChart™ feature, smart notifications, Garmin Quickdraw™ Community data and more. Garmin Marine Network support allows sharing of sonar, maps, user data, radar, IP cameras and live sonar among multiple units. Plus, there’s NMEA 2000® and NMEA 0183 network connectivity support, including autopilots, digital switching, weather, media, VHF, AIS and other sensors. These units also include integrated ANT® connectivity support for use with compatible quatix® smartwatches, the gWind™ Wireless 2 transducer, GNX™ Wind marine instrument and wireless remote controls (sold separately). Preloaded Garmin Navionics+™ coastal charts and inland mapping feature Auto Guidance+™ technology (Auto Guidance+ is for planning purposes only and does not replace safe navigation operations.) Plus, there’s support for optional Garmin Navionics Vision+™ premium map content. The combo also includes Quickdraw Contours software and the Quickdraw Community on our Garmin Connect™ online network. See RPMs, fuel flow, temperature, trim and more for up to four of your compatible Mercury® engines by using the SmartCraft® Connect gateway.Specifications Performance and Physical Dimensions 14.1" x 8.9" x 2.7" (35.8 x 22.6 x 6.9 cm) Display size 10.3" x 6.4" (26.2 x 16.3 cm) Display resolution 1280 x 800 Display type WXGA display Weight 5.2 lbs Water rating IPX7 Power consumption Max power usage at 10 Vdc: 34.8 W Antenna Internal or external over NMEA 2000 Mounting options Bail or flush Receiver 10 Hz high-sensitivity Garmin Marine Network™ ports 2 Preloaded maps Garmin Navionics+ coastal and inland water charts for the U.S. and Canada Accepts data cards 2 SD™ cards Waypoints 5,000 Routes 100 Track log 50,000 points; 50 saved tracks Tide tables Yes Garmin Radar compatible Yes Garmin Sonar compatible Yes (built-in) Garmin SmartMode compatible (customizable monitor presets) Yes Supports AIS (tracks target ships position) Yes Supports DSC (displays position data from DSC-capable VHF radio) Yes Garmin Meteor™ Audio System compatible Yes Supports FUSION-Link™ compatible radios Yes GSD™ Black Box sonar support Yes GCV™ Black Box sonar support Yes ActiveCaptain compatible Yes Garmin Helm compatible Yes GRID™ (Garmin Remote Input Device) compatible Yes Wireless remote compatible Yes Dual-frequency (50/200 kHz) sonar capable Yes Dual-beam (77/200 kHz) sonar capable Yes Transmit power 1 kW traditional; 1 kW CHIRP CHIRP sonar technology Yes (Built-in) ClearVü Yes with CHIRP (built-in) SideVü Yes with CHIRP (built-in) Maximum depth 5,000 ft at 1kW (depth capacity is dependent on water bottom type and other water conditions) Bottom lock (shows return from the bottom up) Yes Water temperature log and graph Yes Sonar recording Yes Sonar history rewind Yes NMEA 2000® compatible Yes Transducer pin numbers 12 NMEA 0183 input ports 1 NMEA 0183 output ports 1 Video input ports 1 BNC Video output ports None Wireless connectivity Yes What's in the Box: GPSMAP 1242xsv chartplotter Garmin Navionics+ coastal and inland water charts for the U.S. and Canada Power/data cable NMEA 2000 T-connector NMEA 2000 drop cable (2 m) Bail mount kit with knobs Flush mount kit with gasket Protective cover Trim piece snap covers Documentation 8-pin transducer to 12-pin sounder adapter cable

Read more less

Garmin Reactor 40 Kicker Autopilot with Stainless Steel Tilt TubeModel: 010-00705-96 Specially designed for boats with small gasoline outboard motors up to 20 horsepower. Helps maintain heading hold and route to keep you on course — even against wind, waves or heavy current Includes convenient floating handheld remote control with a bright, sunlight-readable display (requires compatible ANT® technology-capable MFD or GHC 20 autopilot display; both sold separately) Easily fine-tune autopilot throttle setting with the touch of a button to quickly drop to idle speed when netting a fish Easy to install and integrate GHC 20 autopilot display, compatible Garmin chartplotters (sold separately) or your NMEA 2000® network-compatible GPS system Includes stainless steel tilt tube for Yamaha® and Honda outboards Whether you’re going for salmon, trout, walleye or some other species or just taking your sailboat out of the marina, your Reactor 40 kicker autopilot can help you maintain heading hold and route to keep you on course - even against wind, waves or heavy current.The Reactor 40 kicker autopilot includes a convenient floating handheld remote control with a bright, sunlight-readable display. Quickly and easily fine-tune your autopilot throttle setting with the touch of a button, and quickly drop to idle speed when netting a fish or coming up to a mooring. Enjoy easy integration with our GHC 20 autopilot display, compatible Garmin chartplotters (sold separately) or your NMEA 2000 network-compatible GPS system for a seamless onboard setup.What's in the Box: CCU (Course computer unit) ECU (Electronic control unit) ECU power cable ECU to CCU interconnect cable Steering actuator Stainless steel tilt tube Throttle actuator Autopilot Remote NMEA 2000® drop cable (2 meters) NMEA 2000 power cable 2 NMEA 2000 T-connectors NMEA 2000 male terminator NMEA 2000 female terminator Documentation

Read more less

Garmin LiveScope™ Plus Ice Fishing Kit With LiveScope™ Plus System and Lead Acid BatteryModel: 010-02706-30 Catch your limit with the power of LiveScope™ sonar. Just add your ECHOMAP or GPSMAP unit and ice. Use LiveScope™ Forward mode to locate fish and drill where you find ’em. Keep an eye on your jig and how fish react to it with LiveScope™ Down mode. Everything goes where you go. All accessories fit in the rugged, portable carrying case. Adapt your fishing technique with the LiveScope Plus transducer with live, real-time scanning sonar that lets you see up to 200’ in any direction.LiveScope Forward mode shows up to 200’ all around you, so you can locate schools of fish and know where to drill the next hole.LiveScope Down mode homes in on targets, so you can watch fish respond to your jig.The rugged, portable carrying case fits your ECHOMAP 7" or 9" units or GPSMAP 7" and 9" units plus all the included parts, so you can easily transport it from hole to hole and season to season.Kit accessories include a swivel pole mount for the LiveScope transducer, 12Ah battery, charger, flexible power cable and transducer adapter cable.What's in the Box: LiveScope™ Plus System Panoptix ice fishing mount Power cable Documentation Portable fishing kit includes below items Bag with handle Rechargeable battery

Read more less

Garmin Reactor™ 40 Kicker Autopilot Without GHC™ 20 Autopilot DisplayModel: 010-00705-95 Specially designed for boats with small gasoline outboard motors up to 20 horsepower Helps maintain heading hold and route to keep you on course — even against wind, waves or heavy current Includes convenient floating handheld remote control with a bright, sunlight-readable display Easily fine-tune autopilot throttle setting with the touch of a button to quickly drop to idle speed when netting a fish Easy to install and integrate with included GHC 20 autopilot display, compatible Garmin chartplotters or NMEA 2000® network-compatible GPS system Whether you’re going for salmon, trout, walleye or some other species or just taking your sailboat out of the marina, your Reactor 40 kicker autopilot can help you maintain heading hold and route to keep you on course — even against wind, waves or heavy current.The Reactor 40 kicker autopilot includes a convenient floating handheld remote control with a bright, sunlight-readable display. Quickly and easily fine-tune your autopilot throttle setting with the touch of a button, and quickly drop to idle speed when netting a fish or coming up to a mooring. Enjoy easy integration with our GHC 20 autopilot display, compatible Garmin chartplotters or NMEA 2000 network-compatible GPS system for a seamless onboard setup.Specifications ECU-14 Dimensions 6.9" x 5.6" x 2.6" (17.5 x 14.2 x 6.5 cm) Supply voltage range 10 to 32 volts Operating temperature range -20° to 70° C Typical power consumption 1 to 2 amps average depending on weather conditions Water rating IPX7 Throttle Actuator Dimensions 6.0" x 2.5" x 1.1" (15.1 x 5.9 x 2.8 cm) Operating temperature range 0° to 70° C Water rating IPX6 Steering Actuator Dimensions Motor side Extends 4" (10.3 cm) from end of tilt tube Motor 2.5" (6.2 cm) diameter Overall length Closed 17.5" (44.5 cm); Extended 25.3" (64.4 cm) Steering Acuator General Operating temperature range -20° to 70° C Water rating IPX7 Reactor Remote Physical dimensions (W x H x D) 6.0" x 2.0" x 1.3" (15.2 x 5.2 x 3.2 cm) Weight 3.8 oz (109 g) without batteries Display type Sunlight-visible, transflective memory-in-pixel (MIP) Display size 1.2" (3.0 cm) diameter Display resolution 240 x 240 pixels Power 2 x AA batteries (sold separately) What's in the Box: Autopilot Remote CCU (Course computer unit) ECU (Electronic control unit) ECU power cable ECU to CCU interconnect cable Steering actuator Throttle actuator Documentation

Read more less

Garmin Reactor™ 40 Steer-by-wire Standard Corepack Without GHC ControlModel: 010-00705-90 Solid-state 9-axis Attitude Heading Reference System (AHRS) Minimizes heading error, course deviation, rudder movement and power consumption while providing a comfortable ride Minimal commissioning and calibration Reactor 40 for steer-by-wire provides robust autopilot capabilities for SeaStar Optimus systems, Yanmar Marine ZT 370 stern drive electronic power steering systems and ZF 2800 Pod drives.With a complete package designed for powerboats and sailboats, Garmin brings an advanced marine technology to the boating public that was once only available for commercial boats. The Reactor 40 autopilot series is simply the most responsive autopilot system we have ever offered.Reactor 40 autopilots are very versatile. Both powerboat and sailing features are available in all corepacks, including heading hold, wind hold, tack/jibe, step turns and more; simply pick the autopilot that’s compatible with your existing steering system.With its advanced solid-state 9-axis AHRS, you can mount Reactor 40 nearly anywhere, in any orientation. In addition, this new system greatly minimizes heading error, course deviation, rudder movement and power consumption while providing a comfortable ride for all on board.This amazing autopilot actually reacts to the sea to hold your course. Even when the boat is pitching and rolling, you can remain confident that the Reactor 40 autopilot will keep you on your desired course.All autopilots require commissioning and calibration — all of them. We know you just want to get on the water, so we made this process as fast and easy as possible. That’s the power of simple.Combined with Garmins compatible networked chartplotter, you can have full control of Reactor 40 from wherever you are on the boat. In addition to holding its course in virtually all weather and wind conditions, the system can smoothly perform a variety of preprogrammed trolling and search procedures. Plus, with a compatible Garmin networked chartplotter and BlueChart® g2 Vision® charts (sold separately), you gain optional features such as Auto Guidance*, which automatically steers GPS paths.*Auto Guidance is for planning purposes only and does not replace safe navigation operations.Specifications CCU Specifications Dimensions 3 19/32 in. diameter (91.4 mm) Temperature range From 5°F to 131°F (from -15°C to 55°C) Case material Fully gasketed, high-impact plastic, waterproof to IEC 529 IPX7 standards CCU cable length 9.5 ft. (3 m) NMEA 2000 power input 9-16V NMEA 2000 LEN 3 (150 mA) What's in the Box: Reactor 40 CCU (Course Computer Unit) CCU cable Buzzer NMEA 2000® drop cables (2 meters) NMEA 2000 power cable NMEA 2000 T-connectors and terminators Male and female terminators Documentation

Read more less

Garmin GMR Fantom™ 18x, BlackModel: 010-02584-10 GMR Fantom brings the power. Fifty watts of it, actually. See targets clearly, and adjust their sizes as needed. With power save mode, you get to choose when to use full power and when to pull back. Every second of power usage counts. Cut back even more by choosing your active times down to the second. MotionScope™ technology shows targets in color as they move toward you or away. Tailor your 50-watt solid-state dome radar to your boat with a white or black option — both with a range from 20’ to 48 nautical miles, even in fog or rain, and up to 60 RPM rotation speed for a refresh rate that can detect movement at any speed.High-resolution images and high antenna gain help to pick out targets at a distance, while 8-bit true color imagery enhances target separation.MotionScope uses the Doppler effect to detect moving targets and highlight them in different colors, so you can navigate around other boats or severe weather — or toward fishing spots where birds feed at the surface.The power save feature lets you choose when you need more power or less, so you have power when you need it and conserve it when you don’t.Boaters and sailors can specify transmit times down to the seconds instead of minutes, allowing for reduced power consumption.These radars don’t have any complex user settings to deal with, so they’re easy to install and start using.Adjust on-screen target resolution for better separation based on your surroundings.Adjust on-screen target resolution for better separation based on your surroundings.See a historical "trail" on the screen to help you quickly and easily identify moving targets and potential collision threats.The single radar antenna can provide split-screen images on your chartplotter side by side, with independent range setting and controls for both close and long range.Using dual radar provides redundancy and allows each display unit on the boat to pull data from one of two different radar sources.This feature automatically adjusts to your surroundings for optimal performance in all conditions.Gain automatically adjusts sea clutter for calm, medium and rough sea conditions.Overlay radar images onto your chartplotter’s map page. You can add an optional autopilot or heading sensor (sold separately) for best results.New mini-automatic radar plotting aid (MARPA) automatic acquisition allows for triggering and tracking of up to 30 targets with no user prompting on all returns, boundary zones, guard zones or MotionScope technology.Set the safety zone and receive an alarm when an object enters the zone.Variable range markers (VRM) and electronic bearing lines (EBL) allow rapid measurements of distance and bearing to vessels and land.Specifications General DIMENSION 20" x 9.8" (50.8 cm x 24.8 cm) WEIGHT 14.0 lbs WATERPROOF IPX7 ANTENNA LENGTH 17" (43.18 cm) ROTATION SPEED (RPM) Up to 60 rpm, depending on settings BEAM WIDTH 5.2° horizontal, 25° vertical 5.2° horizontal, 25° vertical 48 nm MINIMUM RANGE 6 meters RADAR TYPE Radome Electrical Features POWER INPUT 10-32 V DC POWER CONSUMPTION 4 W MAX POWER CONSUMPTION TRANSMITTING, POWER SAVE 24 W MAX POWER CONSUMPTION TRANSMITTING, NORMAL MODE 33 W TRANSITION POWER 50 W Radar Features DUAL RANGE SUPPORT Yes RADAR OVERLAY SUPPORT Yes DUAL RADAR Yes AUTOBIRD Yes DYNAMIC AUTO GAIN Dynamic MARPA TARGET TRACK Yes (Requires Heading Sensor, Sold Separately) ECHO TRAIL Yes MOTIONSCOPE Yes TARGET SIZE Yes SCAN Yes What's in the Box: GMR Fantom 18x - Black Power cable (15 m/49.21 ft) Network cable (15 m/49.21 ft) Installation instructions Mounting hardware kit and template

Read more less

Garmin GPSMAP® 1222xsv 12-inch Chartplotter/Sonar Combo Is All-in-1 SolutionModel: 010-01741-02UPC: 753759168346 12-inch color display with keypad interface and multifunction control knob High-sensitivity internal 10 Hz GPS and GLONASS receiver Built-in single channel CHIRP sonar, CHIRP ClearVü and CHIRP SideVü scanning sonar and Panoptix™ support (transducers sold separately) Fully network capable for Garmin Marine Network and NMEA 2000® plus NMEA 0183 support Experience an advanced all-in-1 solution with our 12-inch GPSMAP 1222xsv keyed combo. It has built-in support for Garmin CHIRP sonar, CHIRP ClearVü, CHIRP SideVü. It also has built-in support for Panoptix all-seeing sonar and premium Garmin sonar modules (transducers sold separately). Features a large, bright screen coupled with a quick and easy-to-use keypad interface with user-programmable keys and a multifunction control knob.Garmin Marine Network support allows sharing of sonar, maps, user data, dome or open-array radar, IP cameras and Panoptix™ sonar among multiple units. Includes NMEA 2000 network connectivity and NMEA 0183 support for autopilots, digital switching, weather, FUSION-Link, VHF, AIS and other sensors.Enjoy built-in ANT wireless connectivity directly to quatix® marine watch, Garmin Nautix™ in-view display, gWind™ Wireless 2 transducer, GNX™ Wind marine instrument and wireless remote controls.Built in Wi-Fi gives you access to the free all-in-one ActiveCaptain™ app, so you can manage your marine experience from nearly anywhere. It creates a simple yet powerful connection between your compatible mobile device and your Garmin chartplotter, charts, maps and the boating community. Wherever you are, you’ll have unlimited access to your cartography, the ability to purchase new maps and charts and access to the Garmin Quickdraw™ Contours Community. Stay connected with smart notifications on your chartplotter screen. You can also plan a trip or prefish a lake, and ActiveCaptain will automatically sync with your chartplotter. Even get notifications for software updates, and decide when to download them on your device.Right out of the box, you have access to some amazing sonar capabilities; all you have to add are transducers. Comes with built-in Garmin 1 kW CHIRP sonar, CHIRP ClearVü and CHIRP SideVü scanning sonar. It even supports Panoptix all-seeing sonar, premium Garmin sonar modules and a wide range of transducers (sold separately).Networked combos can share their internal sonar with any other device on the network. You can also choose what information is overlaid on the sonar screen; for example, radar, time of day or GPS speed.Fast, responsive built-in 10 Hz GPS and GLONASS receiver refreshes your position and heading 10 times each second to make your movement on the screen more fluid. It makes dropping up to 5,000 accurate waypoints — and finding your way back to them — quick and easy.Two SD™ card slots provide expandable memory for accessory map purchases, such as LakeVü HD, LakeVü HD Ultra, BlueChart® g2 HD or BlueChart® g2 Vision® HD, which adds Garmin patented Auto Guidance and other great features.Instantly create personalized HD fishing maps on screen with 1-foot contours. Tailor them to fit your needs. These are your maps — you own them. Keep the data to yourself, or share it with the Quickdraw Community on Garmin Connect™.To help you gain a wind-maximizing competitive edge, your chartplotter features a pre-race guidance page that shows your virtual starting line along with data fields showing laylines, time to burn before the start and a race timer that can be synchronized across all your networked Garmin GPS products. In addition, other supported sailing features include an enhanced wind rose, heading and course-over-ground lines, set and drift, true and apparent wind data and more.If you have waypoints, tracks or frequently used routes stored on another manufacturer’s GPS product — or on a Garmin handheld device — it’s easy to transfer those items to your new Garmin chartplotter via industry-standard GPX software formatting.Specifications Performance and Physical Dimensions 14.1" x 8.9" x 2.7" (35.8 x 22.6 x 6.9 cm) Display size 10.3" x 6.4" (26.2 x 16.3 cm) Display resolution 1280 x 800 Display type WXGA display Weight 5.2 lbs Water rating IPX7 Antenna Internal or external over NMEA 2000 NMEA 2000® compatible Yes NMEA 0183 compatible Yes SiriusXM™ Weather & Radio compatible Yes Power consumption Max power usage at 10 Vdc: 34.8 W Typical current draw at 12 Vdc: 2.2 A Max current draw at 12 Vdc: 2.9 A Mounting options Bail or flush Maps and Memory Preloaded maps None Accepts data card 2 SD™ cards Waypoints 5,000 Routes 100 Track log 50,000 points; 50 saved tracks Chartplotter Features Garmin Radar compatible Yes Garmin Sonar compatible Yes (with external black box, sold separately) Wireless remote compatible Yes Supports AIS (tracks target ships position) Yes Supports DSC (displays position data from DSC-capable VHF radio) Yes Tide tables Yes Garmin Meteor Audio System compatible Yes Supports Fusion Lync compatible marine radios Yes GSD™ Black Box sonar support Yes GCV™ Black Box sonar support Yes BlueChart® Mobile (planning) compatible Yes Garmin Helm compatible Yes GRID™ (Garmin Remote Input Device) compatible Yes Connections Transducer 1 - 12 pin NMEA 0183 input ports 1 NMEA 0183 output ports 1 Video input ports 1 BNC Video output ports None Wireless connectivity Yes Garmin Marine Network™ ports 2 Sonar Features and Specifications CHIRP sonar technology Yes (Built-in) ClearVü Yes with CHIRP (built-in) SideVü Yes with CHIRP (built-in) Dual-frequency (50/200 kHz) sonar capable Yes Dual-beam (77/200 kHz) sonar capable Yes Frequencies supported Traditional: 50/77/83/200 kHz CHIRP (low, medium, high) ClearVü/SideVü (260/455/800 kHz) (dependent on transducer) Transmit power 1 kW traditional; 1 kW CHIRP Maximum depth 5,000 ft at 1kW (depth capacity is dependent on water bottom type and other water conditions) Bottom lock (shows return from the bottom up) Yes Water temperature log and graph Yes Sonar recording Yes Sonar history rewind Yes What's in the Box: GPSMAP 1222xsv chartplotter Power/data cable NMEA 2000 T-connector NMEA 2000 drop cable (2 m) Bail mount kit with knobs Flush mount kit with gasket Protective cover Trim piece snap covers Documentation 8-pin transducer to 12-pin sounder adapter cable

Read more less

Garmin Reactor™ 40 Mechanical/Retrofit/Solenoid Corepack With GHC™ 50 Autopilot InstrumentModel: 010-02794-02 The Reactor 40 mechanical/retrofit/solenoid corepack works with a wide variety of steering systems. Yes, it features a solid-state 9-axis AHRS. And yes, that means you can mount it nearly anywhere. Even when you’re pitching or rolling, this autopilot reacts to sea conditions to keep you on course. You just want to get on the water, so we made calibration fast and easy. That’s the power of simple. Combine with your compatible Garmin chartplotter, and control your autopilot — from anywhere on your boat. The GHC™ 50 autopilot instrument enhances your autopilot experience. This corepack works with direct or cable-actuated steering systems to support heading hold, wind hold, step turns and tack/jibe modes.With its advanced solid-state 9-axis AHRS, you can mount Reactor 40 nearly anywhere, in any orientation. It even reduces power consumption, minimizes heading error and more.Hold your course on the sea — this autopilot reacts to conditions, so you can remain confident even when you’re pitching or rolling.All autopilots require commissioning and calibration. Reactor 40 makes it quick and easy.Gain more freedom when maneuvering your boat. On hydraulic installations, this corepack allows for optional Shadow Drive technology to automatically disengage the autopilot when you turn the wheel.Choose between class A, class B compact or class B drive units for your steering system (sold separately). All Garmin linear drives include built-in rudder feedback sensing.Control your autopilot from anywhere on your boat by using your compatible Garmin devices, including the Reactor autopilot remote, select quatix® marine smartwatches and more (requires a compatible Garmin chartplotter or GHC 50 autopilot instrument).Combine the Reactor 40 corepack with the GHC 50 autopilot instrument to add a dedicated, touchscreen autopilot display to your helm. Plus, GHC 50 allows you to share data and settings with Garmin MFDs and other installed Garmin devices.For even more peace of mind, add the GRF 10 rudder feedback sensor to further enhance your autopilot’s performance (requires GHC 50 autopilot instrument or compatible Garmin chartplotter).When connected to your compatible Garmin chartplotter, all Reactor 40 corepacks offer powerboat and sailing features, including heading hold and step turns — plus wind hold and tack/jibe when paired with a wind sensor (sold separately). You can even gain additional benefits such as the follow route and Auto Guidance+™ features1.1 Auto Guidance is for planning purposes only and does not replace safe navigation operationsSpecifications CCU dimensions: 4.3" x 4.4" x 1.9" (10.9 x 11.2 x 4.8 cm)CCU dimensions 4.3" x 4.4" x 1.9" (10.9 x 11.2 x 4.8 cm) ECU dimensions 6.6" x 4.6" x 2.1" (16.8 x 11.7 x 5.3 cm) Supply voltage 10 V to 30 V Operating temperature -15° C to 60 C° (5° F to 140° F) Maximum sustained motor current 15A Maximum instantaneous motor current 40A Maximum clutch current 2.5A (for drives requiring higher current than 2.5A, a relay needs to be added to the clutch circuit) Buzzer/Alarm Specifications Dimensions (L Diameter) 29/32" 1" (23 mm 25 mm) Weight 2.4 oz (68 g) Temperature range from 5°F to 131°F (from -15°C to 55°C) Cable length 10 ft (3.0 m) What's in the Box: Reactor 40 CCU (Course Computer Unit) GHC™ 50 helm control display ECU (Electronic Control Unit) ECU power cable Interconnect cable Buzzer NMEA 2000® drop cables (2 meters) NMEA 2000 T-connectors Male and female terminators Documentation

Read more less

Garmin Reactor™ 40 Hydraulic Autopilot With GHC™ 50 Autopilot InstrumentModel: 010-02794-00 This Reactor 40 corepack is the perfect companion for your hydraulically steered system. Yes, it features a solid-state 9-axis AHRS. And yes, that means you can mount it nearly anywhere. Even when you’re pitching or rolling, this autopilot reacts to sea conditions to keep you on course. You just want to get on the water, so we made calibration fast and easy. That’s the power of simple. Combine with your compatible Garmin chartplotter, and control your autopilot — from anywhere on your boat. Want more? The optional GHC™ 50 autopilot instrument enhances your autopilot experience. Designed for powerboats, this Reactor 40 hydraulic autopilot gives you the extra hand you need, so you can explore paradise worry-free.This corepack is an ideal autopilot solution for all types of hydraulically steered powerboats — inboards, outboards, stern drives and diesels — or hydraulically steered sailboats1. It requires a compatible Garmin chartplotter or GHC 50 autopilot instrument.With its advanced solid-state 9-axis AHRS, you can mount Reactor 40 nearly anywhere, in any orientation. It even reduces power consumption, minimizes heading error and more.Hold your course on the sea — this autopilot reacts to conditions, so you can remain confident even when you’re pitching or rolling.All autopilots require commissioning and calibration. Reactor 40 makes it quick and easy.Control your autopilot from anywhere on your boat by using your compatible Garmin devices, including the Reactor autopilot remote, select quatix® marine smartwatches and more (requires a compatible Garmin chartplotter or GHC 50 autopilot instrument).Gain more freedom when maneuvering your boat. This corepack allows for optional Shadow Drive technology to automatically disengage the autopilot when you turn the wheel.Combine the Reactor 40 hydraulic autopilot with the GHC 50 autopilot instrument to add a dedicated touchscreen autopilot display to your helm. Plus, GHC 50 allows you to share data and settings with Garmin MFDs and other installed Garmin devices.When connected to your compatible Garmin chartplotter, all Reactor 40 corepacks offer powerboat and sailing features, including heading hold and step turns — plus wind hold and tack/jibe when paired with a wind sensor (sold separately). You can even gain additional benefits such as the follow route and Auto Guidance+™ features2.1 Hydraulic pump not included; various pump options are available based on the hydraulic steering of your boat2 Auto Guidance is for planning purposes only and does not replace safe navigation operationsSpecifications NMEA output NMEA 2000 Display resolution (WxH) 320 x 240 pixels Display type QVGA color LCD display Supply voltage 10V to 20V What's in the Box: Reactor 40 CCU (Course Computer Unit) GHC™ 50 helm control display ECU (Electronic Control Unit) ECU power cable Interconnect cable Shadow Drive Buzzer NMEA 2000® drop cables (2 meters) NMEA 2000 power cable NMEA 2000 T-connectors Male and female terminators Documentation

Read more less

B265LM Bronze Thru-Hull Mount Transducer with Depth & TemperatureGarmin's best performing 1 kW thru-hull transducer, this bare wire mount performs well in deep water and has exceptional bottom and water column detail.This transducer has a depth of 3,000 ft; an operating frequency of 42 to 65 kHz and 85 to 135 kHz; a beamwidth of 16 to 25 degrees and 11 to 16 degrees; and a 0 to 20 degree deadrise.Transducer kit comes with installation instructions. Follow the instructions carefully to avoid damaging your boat.Compatible Devices:GSD™ 26 CHIRP Professional Sonar ModuleWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Pins: Bare Wires Mounting Style: Thru-Hull Imagining: Standard Chirp: Low/Medium Cable Length (Feet): 39' Speed Included: No Temperature: Yes Box Dimensions: 7"H x 18"W x 26"L WT: 24.2 lbs UPC: 753759972141

Read more less

Garmin Compact Reactor™ 40 Hydraulic Autopilot with GHC™ 50 and Shadow Drive™ Technology Pack With GHC™ 50 and Shadow DriveModel: 010-02794-08 This Reactor 40 hydraulic autopilot is the perfect companion for your hydraulically steered system. Yes, it features a solid-state 9-axis AHRS. And yes, that means you can mount it nearly anywhere.c Even when you’re pitching or rolling, this autopilot reacts to sea conditions to keep you on course. You just want to get on the water, so we made calibration fast and easy. That’s the power of simple. Combine with your compatible Garmin chartplotter, and control your autopilot — from anywhere on your boat. The GHC™ 50 autopilot instrument enhances your autopilot experien Designed for boats less than 25’ long, this entry-level, Compact Reactor 40 hydraulic autopilot gives you the extra hand you need, so you can explore paradise worry-free.This corepack is an ideal autopilot solution for single-engine outboard boats that are less than 25’ long1. It provides relief from manually holding the wheel to maintain course, especially when cruising at moderate to high speeds2.With its advanced solid-state 9-axis AHRS, you can mount Reactor 40 nearly anywhere, in any orientation. It even reduces power consumption, minimizes heading error and more.Hold your course on the sea — this autopilot reacts to conditions, so you can remain confident even when you’re pitching or rolling.All autopilots require commissioning and calibration. Reactor 40 makes it quick and easy. This autopilot is easy to install with flexible mounting options.Control your autopilot from anywhere on your boat by using your compatible Garmin devices, including the Reactor autopilot remote, select quatix® marine smartwatches and more (requires a compatible Garmin chartplotter or GHC 50 autopilot instrument).Gain more freedom when maneuvering your boat. This corepack allows for optional Shadow Drive technology to automatically disengage the autopilot when you turn the wheel.When connected to your compatible Garmin chartplotter, all Reactor 40 corepacks offer powerboat and sailing features, including heading hold and step turns — plus wind hold and tack/jibe when paired with a wind sensor (sold separately). You can even gain additional benefits such as the follow route and Auto Guidance+™ features3.1 Requires a compatible Garmin chartplotter (sold separately)2 Not recommended for fishing or applications that require holding heading while trolling at low speeds or operating in rough waters. For applications that require precise heading control, our higher-performance Reactor 40 models are recommended. Compact Reactor uses a gear pump design with limited performance relative to similar flow piston pumps. Not recommended for power assist installs, engines above 150 horsepower or boats with more than 12-degree deadrises. Mount pump within 6’ of the steering cylinder for best results.3 Auto Guidance is for planning purposes only and does not replace safe navigation operationsSpecifications Unit dimensions, WxHxD 4.3 " x 4.4 " x 1.9 " (10.9 x 11.2 x 4.8 cm) Pump dimensions, LxWxH 6.6 " x 3.9 " x 3.3 " (16.8 x 10.0 x 8.5 cm) NMEA output NMEA 2000 Supply voltage 10V to 20V Operating temperature -15° C to 70 C° (5° F to 158° F) What's in the Box: GHC 50 helm control display Reactor 40 CCU (Course Computer Unit) 1.0 L Pump ECU (Electronic Control Unit) ECU power cable Interconnect cable Buzzer NMEA 2000® drop cables (2 meters) NMEA 2000 power cable NMEA 2000 T-connectors Male and female terminators Documentation Shadow Drive

Read more less

Garmin GMR Fantom™ 18x, whiteModel: 010-02584-00 GMR Fantom brings the power. Fifty watts of it, actually. See targets clearly, and adjust their sizes as needed. With power save mode, you get to choose when to use full power and when to pull back. Every second of power usage counts. Cut back even more by choosing your active times down to the second. MotionScope™ technology shows targets in color as they move toward you or away. Tailor your 50-watt solid-state dome radar to your boat with a white or black option — both with a range from 20’ to 48 nautical miles, even in fog or rain, and up to 60 RPM rotation speed for a refresh rate that can detect movement at any speed.High-resolution images and high antenna gain help to pick out targets at a distance, while 8-bit true color imagery enhances target separation.MotionScope uses the Doppler effect to detect moving targets and highlight them in different colors, so you can navigate around other boats or severe weather — or toward fishing spots where birds feed at the surface.The power save feature lets you choose when you need more power or less, so you have power when you need it and conserve it when you don’t.Boaters and sailors can specify transmit times down to the seconds instead of minutes, allowing for reduced power consumption.These radars don’t have any complex user settings to deal with, so they’re easy to install and start using.Adjust on-screen target resolution for better separation based on your surroundings.Adjust on-screen target resolution for better separation based on your surroundings.See a historical "trail" on the screen to help you quickly and easily identify moving targets and potential collision threats.The single radar antenna can provide split-screen images on your chartplotter side by side, with independent range setting and controls for both close and long range.Using dual radar provides redundancy and allows each display unit on the boat to pull data from one of two different radar sources.This feature automatically adjusts to your surroundings for optimal performance in all conditions.Gain automatically adjusts sea clutter for calm, medium and rough sea conditions.Overlay radar images onto your chartplotter’s map page. You can add an optional autopilot or heading sensor (sold separately) for best results.New mini-automatic radar plotting aid (MARPA) automatic acquisition allows for triggering and tracking of up to 30 targets with no user prompting on all returns, boundary zones, guard zones or MotionScope technology.Set the safety zone and receive an alarm when an object enters the zone.Variable range markers (VRM) and electronic bearing lines (EBL) allow rapid measurements of distance and bearing to vessels and land.Specifications General DIMENSION 20" x 9.8" (50.8 cm x 24.8 cm) WEIGHT 14.0 lbs WATERPROOF IPX7 ANTENNA LENGTH 17" (43.18 cm) ROTATION SPEED (RPM) Up to 60 rpm, depending on settings BEAM WIDTH 5.2° horizontal, 25° vertical 5.2° horizontal, 25° vertical 48 nm MINIMUM RANGE 6 meters RADAR TYPE Radome Electrical Features POWER INPUT 10-32 V DC POWER CONSUMPTION 4 W MAX POWER CONSUMPTION TRANSMITTING, POWER SAVE 24 W MAX POWER CONSUMPTION TRANSMITTING, NORMAL MODE 33 W TRANSITION POWER 50 W Radar Features DUAL RANGE SUPPORT Yes RADAR OVERLAY SUPPORT Yes DUAL RADAR Yes AUTOBIRD Yes DYNAMIC AUTO GAIN Dynamic MARPA TARGET TRACK Yes (Requires Heading Sensor, Sold Separately) ECHO TRAIL Yes MOTIONSCOPE Yes TARGET SIZE Yes SCAN Yes What's in the Box: GMR Fantom 18x - White Power cable (15 m/49.21 ft) Network cable (15 m/49.21 ft) Installation instructions Mounting hardware kit and template

Read more less
